GB/5 & FB/80 UPDATES #1
STEAM VALVE IMPROVED DESIGN
ANTI‐SUCTION VALVE
NO MILK SUCTION = NO CLOGGIN
LONGER VALVE LIFE
ON MACHINES FROM # 2487
ON LINEA & FB/70 IN YEAR 2010
PARTS KIT #: B.1.001.X (incl. pipes and drains in the next page)
RETROFITABLE
L171/X
AVAILABLE UPON REQUEST ON LINEA/FB70 : #
