- Page 1 kit.
- Page 2 safety first! BEFORE TO START, PLEASE MAKE SURE YOUR MACHINE IS DISCONNECTED FROM THE ELECTRICAL SUPPLY.
- Page 3 remove the cup tray and electronic box.
- Page 4 disconnect all connectors from the board. We recommend marking each wire before to remove it. ATTENTION: All high voltage wires are connected to the board with the green quick connector which is shown in the picture. This connector has a drop of glue to prevent from accidentaly disconnecting and may result difficult to separate.
- Page 5 board re-wiring. old electronic board. new electronic boards. (picture of the 220V version) ATTENTION: MAKE SURE THE SELECTORS ARE POSITIONED AS SHOWN 220V 110V...
- Page 6 place the new electronic box in the machine.
- Page 7 locate the QR-code on the electronic box. You should have found two QR-codes with the kit. Stick one of them on the electronic box and stick the other one in the inside of the black frame (alongside the water tank). Contact us to get the APP TECH if you don’t have it yet.
