Summary of Contents for Crestron Isys TPS-6000L

  • Page 3: Table Of Contents

    Crestron Isys™ TPS-6000L Contents 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L Description... 1 Functional Description ... 1 Physical Description... 4 Leading Specifications... 5 Installation/Setup ... 6 Identity Code ... 6 Recommended Cleaning... 6 Network Wiring... 6 Hardware Hookup ... 7 Configuring the Touchpanel ...

  • Page 5: Inch Lectern Touchpanel: Crestron Isys™ Tps-6000L

    Description Functional Description The Crestron Isys™ TPS-6000L is a 15-inch (38.1-cm) XGA (1024 x 768) display suitable for lectern or wall mount in any Crestron remote control system (herein referred to as the Cresnet system). The unit operates in a 16-bit graphics mode (65,536 colors);...

  • Page 6: Expansion Slots

    NOTE: The three cards are NOT interchangeable. Memory The TPS-6000L ships with 8MB of flash and 8MB of DRAM. Additional memory (purchased separately) can be installed in the field. The flash can be replaced with modules of up to 64MB. The DRAM module can be replaced with modules up to 32MB.
  • Page 7 RGB INPUT – These five connectors are made available with the purchase and installation of the TPS-XVGAL, a scan converter card. Consult the latest revision of the TPS-XVGAL Operations & Installation Guide (Doc. 5828) for details. 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L • 3...

  • Page 8: Physical Description

    Physical Description The 15-inch (38.1-cm) touch sensitive viewing screen is located on the front of the TPS-6000L touchpanel, shown after this paragraph. The electronic hardware is housed in a black metal enclosure. All audio, video, Ethernet, RS-232, and network connections are made at the rear of the unit. Two grills located on the front of the unit conceal four speakers and a microphone.

  • Page 9: Leading Specifications

    These control systems do not support loading of firmware or VT Pro-e files to the TPS-series panels through the RS-232 port of the control system. In order to load these files to the TPS-6000L when using these control systems, either use the RS-232 port on the TPS-6000L or use Ethernet direct to the panel (assuming the TPS-ENETL is installed).

  • Page 10: Installation/Setup

    15 Inch Lectern Touchpanel As of the date of manufacture, the touchpanel has been tested and found to comply with specifications for CE marking. NOTE: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 11: Hardware Hookup

    Direct Mounting The TPS-6000L is a low-voltage unit that can be installed directly into a mounting surface. Each touchpanel is provided with mounting hardware and accessories, as shown in the table after this paragraph.
  • Page 12 5/16" bit, and a #20 bit. Complete the following installation procedure in the order provided. Securing Two Plates to Top and Bottom Edges of Opening 8 • 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L ITEM PART NUMBER Large Metal Mounting Plate...
  • Page 13 14. Mate the four posts of the bezel with the holes drilled into the mounting surface and firmly press on the bezel over the touchpanel. COVER TOUCHPANEL WITH BEZEL NOTE: WIRING NOT SHOWN FOR CLARITY DRYWALL 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L • 9 15 Inch Lectern Touchpanel...

  • Page 14: Configuring The Touchpanel

    To configure the unit, it may be necessary to access a series of setup screens prior to viewing run-time screens that are loaded into the touchpanel for normal operation. The Main Menu for configuring the touchpanel appears when a finger is held to the touchscreen as power is applied. Remove your finger when the message "SETUP MODE"...

  • Page 15: Diagnostics Menu

    Diagnostics Menu The Diagnostics button from the Main Menu should only be used under supervision from a Crestron technical support representative during telephone support. Most of the options available from the Diagnostics Menu, shown after this paragraph, are numeric in nature and their interpretation is beyond the scope of this manual.
  • Page 16 STANDBY TIMEOUT, located in the middle of the Setup Menu, can turn off the touchpanel when it is inactive for a specified time frame (minutes, shown as XXX in the illustration). When the touchpanel is activated, the last screen to be displayed reappears.

  • Page 17: Interface Menu

    Crestron Isys™ TPS-6000L NOTE: IP settings are necessary only if the TPS-ENETL is installed. Serially connect a PC to the TPS-6000L via the RS-232 connector and refer to the details in the latest revision of the TPS-ENETL (Doc. 5829). Selection of the Ethernet button from the Setup Menu displays details such as the IP Address, Subnet Mask, Def(ault) Router, IP Table, etc.
  • Page 18 The four buttons in the upper right corner of the menu are available for selection. Crestron suggests that even if there is no intent to use the RS-232 port, the user should select one of the four RS-232 communication options. Crestron recommends the default, RS-232 Port for Console, if the port is not being used.

  • Page 19: Audio Menu

    The Play WAV File button appears beneath Audio Menu title block. Select this button to adjust the volume and balance as a pre-loaded WAV file plays. WAV file Operations Guide - DOC. 5825 15 Inch Lectern Touchpanel 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L • 15...
  • Page 20 Selection of the RGB button opens the RGB Menu from which the user can adjust RGB settings. The TPS-6000L can display a computer-generated video format. The type of format must be selected carefully or the video may appear unstable or noisy. Selecting the RGB button, located to the right on the top row of the Setup Menu, displays the RGB Menu, shown after this paragraph.
  • Page 21 Preset 16 is shown as an example. If there is no preset detected, the box shows 0 as the value. The touchpanel is capable of storing 16 VGA formats; the panel is factory set with the presets empty. To assign a format to a preset, complete the following steps: NOTE: The Center button only needs to be used if the sample disappears from the screen while making adjustments in step 3.

  • Page 22: Video Menu

    Selection of the Video button opens the Video Menu from which the user can adjust video settings. The TPS-6000L can display video from up to two different video sources. Both of these signals are automatically set up as NTSC or PAL, composite or S-Video.

  • Page 23: Visiontools™ Pro-E (Multi-Mode Objects)

    Crestron control system. This example is analogous to a traffic light that changes colors as well as controlling the text on a walk/don't walk sign.

  • Page 24: Programming With Simpl™ Windows

    SIMPL (Symbol Intensive Master Programming Language) is an easy-to-use programming language that is completely integrated and compatible with all Crestron system hardware. The objects that are used in SIMPL are called symbols. SIMPL Windows offers drag and drop functionality in a familiar Windows environment.

  • Page 25: How The Program Works

    CNMSX-PRO, which has a CNXRY-16 occupying slot 1. Assume that the TPS-6000L is used to control a lighting system via relays in two rooms. Each room can have up to eight scenes of lighting. A scene is engaged by latching a relay.

  • Page 26: Programming Manager

    Windows to select and configure all the devices that need to be included into the system. For this example, add a CNXRY-16 to slot #1 of the CNMSX-PRO. Also add a TPS-6000L to the system; its NET ID must be set to 03, shown after this paragraph.
  • Page 27 (alternatively CTRL+D or drag and drop into Detail View). Assign signals as shown after this paragraph. Detail View of a Interlocks (S-1 & S-2) in SIMPL Windows’ Programming Manager Operations Guide - DOC. 5825 15 Inch Lectern Touchpanel 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L • 23...

  • Page 28: Reserved Join Numbers

    XGA and Video Digital Reserved Join Numbers for TPS-6000L Touchpanels * Join numbers 17016 through 17031 corresponds to Preset 1 through Preset 16, sequentially.
  • Page 29 17606 RS-232 Port Baud Rate 17607 RS-232 Port Baud Rate 17608 RS-232 Port Baud Rate 17609 RS-232 Port Baud Rate 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L • 25 15 Inch Lectern Touchpanel VALUE Increase Decrease Increase Decrease Left Right...

  • Page 30: Problem Solving

    Analog Reserved Join Numbers for TPS-6000L Touchpanels Problem Solving Troubleshooting The table below and on the next page provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. TPS-6000L Touchpanel Toubleshooting TROUBLE...

  • Page 31: Further Inquiries

    Further Inquiries If after reviewing this Operations Guide for the TPS-6000L touchpanel, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team by calling: For local support from exclusive Crestron factory-trained personnel in New Zealand call Amber Technologies at +649-410-8382.

  • Page 32: Appendix A: Wav File Audio Messages

    Downloadable WAV Files Pre-recorded WAV files for voice prompts and responses are available from Crestron. These files can be stored into and programmed for use in the touchpanel directly or may be edited with the Sound Recorder. For example, the individual files can be combined to create custom messages.

  • Page 33: To Record A Wav File Message

    4. Proceed to "Set WAV File or Message Properties, Save, and Exit" on page 34. To record another file, follow that procedure to step 9. 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L • 29 button to stop...

  • Page 34: To Convert A Wav File

    To convert a WAV file, perform the following procedure: Open Sound Recorder Open WAV File to Convert 30 • 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L Crestron Isys™ TPS-6000L 1. At the Windows taskbar, select Start | Programs | Accessories. For Windows 95/NT, select Multimedia, for Windows 98, select Entertainment.

  • Page 35: To Create Wav Messages From Individual Files

    1. At the Windows taskbar, select Start | Programs | Accessories. For Windows 95/NT, select Multimedia, for Windows 98, select Entertainment. Select Sound Recorder and the Sound Recorder opens as shown below. 2. Select File | New as shown below. 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L • 31...
  • Page 36 15 Inch Lectern Touchpanel Insert First WAV File Open First WAV File 32 • 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L Crestron Isys™ TPS-6000L 3. Select Edit | Insert File as shown below. 4. From the insert file dialog box shown below, browse to the directory or folder that contains the first WAV file to be inserted, and open the file.
  • Page 37 8. Repeat the above three steps until all desired files have been inserted. 9. Proceed to "Set WAV File or Message Properties, Save, and Exit" on page 34. To create another message, follow that procedure to step 9. 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L • 33...

  • Page 38: Set Wav File Or Message Properties, Save, And Exit

    Access File Properties Access File Properties Conversion 34 • 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L Crestron Isys™ TPS-6000L 1. Select File | Properties as shown below. 2. When the Properties for Sound dialog box opens, click on Convert Now.
  • Page 39 PCM selected. If not, select it as shown below. 4. Make sure that the Attributes field has a suitable format (i.e., 8,000 Hz, 8 Bit, Mono) selected. If not, select it as shown below. 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L • 35...
  • Page 40 Set the File Properties Complete File Properties Conversion Save File 36 • 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L Crestron Isys™ TPS-6000L 5. Review the format and attributes then click the OK button. 6. To complete the file properties conversion, click OK.

  • Page 41: Vt Pro-E: Sound Manager

    “Button Properties” dialog. Crestron VT Pro-e (version 2.1.0 and later) contains an audio tool, Sound Manager, which permits the panel designer to attach WAV files to a touchpanel project. Sound Manager is available from the Tools pull-down menu and opens the “Sound...
  • Page 42 Sound Manager Guidelines There are three things to keep in mind when using Sound Manager. 38 • 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L Crestron Isys™ TPS-6000L 1. Each WAV file must be assigned a unique digital join number. The join number options include none, keyclick, or a number (1 through 4000).
  • Page 43 3. Select the Add button to transfer the WAV file to the Sound List table located below the browse field. The audio parameters of the file also appear to the right of the table. 4. Repeat steps 1 through 3 for each desired WAV file. 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L • 39...

  • Page 44: Appendix B: Rs-232 Protocol

    15 Inch Lectern Touchpanel Appendix B: RS-232 Protocol TPS-6000L touchpanels support panel operation via a host computer through the RS-232 port. Crestron recommends that the following serial data format is set. Suggested Serial Data Format These settings may be altered via the RS-232 Menu when configuring the touchpanel, however, doing so may prevent Crestron supplied software from operating with the touchpanel.
  • Page 45 2400 baud. Obviously, ramping several objects at once requires a baud rate several times as high. Indirect Text – TPS-6000L touchpanels support a feature that permits the text field in any user-defined button to be altered on the fly in RUN mode. This is accomplished by substituting a text pointer for the text in the button.

  • Page 46: Appendix C: Cutout Detail Of Supplied Template

    Appendix C: Cutout Detail of Supplied Template The actual cutout dimensions are 13.800 in. (35.052 cm) wide by 12.100 in. (30.734 cm) high. However, Crestron recommends that the supplied template be used to avoid any error. 42 • 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L Crestron Isys™...

  • Page 47: Software License Agreement

    This Agreement may only be modified by a writing signed by an authorized officer of Crestron. Updates may be licensed to You by Crestron with additional or different terms. This is the entire agreement between Crestron and You relating to the Software and it supersedes any prior representations, discussions, undertakings, communications or advertising relating to the Software.
  • Page 48 “applets” incorporated into the Software), the accompanying media and printed materials, and any copies of the Software are owned by Crestron or its suppliers. The Software is protected by copyright laws and international treaty provisions. Therefore, you must treat the Software like any other copyrighted material, subject to the provisions of this Agreement.

  • Page 49: Return And Warranty Policies

    CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures.
  • Page 50 15 Inch Lectern Touchpanel Crestron Isys™ TPS-6000L This page intentionally left blank. 46 • 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L Operations Guide - DOC. 5825...
  • Page 51 Crestron Isys™ TPS-6000L 15 Inch Lectern Touchpanel This page intentionally left blank. 15 Inch Lectern Touchpanel: Crestron Isys™ TPS-6000L • 47 Operations Guide - DOC. 5825...
