- Page 1 INSTALLATION AND OPERATION MANUAL XRS SERIES PASSIVE, POWERED AND OUTDOOR LOUDSPEAKERS XRS8 / XRS10 / XRS12 XRS8P / XRS10P / XRS12P XRS6ODV / XRS8ODV / XRS10ODV / XRS12ODV...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION READ these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. - Page 3 XRS Front Panel front-of-house to fold back, the dance floor to background XRS Rear Panel fill, the XRS series with passive and powered options are – Passive & Constant Voltage designed with flexibility and performance in mind. For outdoor applications there is also the ODV range. These...
-
Page 4: Front Panel
Passive crossover in the passive and outdoor XRS variants. XRS10 10” XRS6ODV 1” 12” XRS12 XRS8 1.5” XRS10 1.5” XRS12 2” Active crossover and power amp in XRS powered varients. XRS8P 50 W XRS10P 50 W XRS12P 100 W XRS SERIES INSTALLATION AND OPERATION MANUAL... -
Page 5: Rear Panel
2 core flying lead as input to the speaker. The flying lead wires are red (positive +) and black (negative -) and are used as an input to the speaker for both constant voltage and low impedance inputs. XRS SERIES INSTALLATION AND OPERATION MANUAL... -
Page 6: Powered Version
REAR PANEL Powered Version XRS8P 115V POWER: 100W+50W ACTIVE 2 WAY FULL RANGE SPEAKER WARNING ! 230V TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE XRS SERIES INSTALLATION AND OPERATION MANUAL... -
Page 7: Suspending With Eyebolts
IEC Mains Input Socket Green LED Signal Present indicator for the Line input. Indicates XRS series powered speakers use a standard IEC 3 pin mains signal is present at the input, it is not affected by the level control. socket. A standard IEC mains cable is provided. The fuse drawer contains the mains fuse and a spare. - Page 8 Winch up speaker stand XR10-12UB Universal bracket XRS12 PART DESCRIPTION XR10CVR Heavy duty cover AMISLSB2 Wall mount brackets ATC303 Tripod speaker stand ATC304 Heavy duty tripod speaker stand ATC305 Winch up speaker stand XR10-12UB Universal bracket XRS SERIES INSTALLATION AND OPERATION MANUAL...
-
Page 9: Specifications
(W X D X H) (per pair) NET WEIGHT 6.5 kg (14.3 lbs) 10 kg (22 lbs) 18 kg (39.7 lbs) (per single) SHIPPING WEIGHT 15 kg (33.1 lbs) 12 kg (26.5 lbs) 20 kg (44.1 lbs) (per pair) XRS SERIES INSTALLATION AND OPERATION MANUAL... - Page 10 (16.3” x 15.4” x 23.6”) (W X D X H) NET WEIGHT 8.6 kg (19 lbs) 10.5 kg (23.1 lbs) 23 kg (51 lbs) SHIPPING WEIGHT 10.1 kg (22.3 lbs) 11.8 kg (26 lbs) 25.2 kg (55.6 lbs) XRS SERIES INSTALLATION AND OPERATION MANUAL...
- Page 11 OUTDOOR MODELS XRS6ODV XRS8ODV IMPEDANCE 8 Ohms 8 Ohms (Bypass) POWER 7.5 W, 15 W, 30, 60 W 15 W, 37.5 W, 75 W (70 V, 100 V Tappings) POWER 80 W, 160 W 100 W, 200 W (Bypass Continuous / Program) SENSITIVITY 92 dB 92 dB...
- Page 12 ENGINEERED BY AUSTRALIAN MONITOR Address: Unit 1, 2 Daydream Street, Warriewood NSW 2102 Australia Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au ABN 86 003 231 187...
