- Page 1 INSTALLATION AND OPERATION MANUAL TXG SERIES WALL MOUNT SPEAKERS TXG10 TXG30 TXG50...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION PRÉCAUTIONS DURANT UTILISATION Read these instructions. LISEZ ces instructions. Keep these instructions. Tenez ces instructions. Heed all warnings. Notez tous les avertissements. Follow all instructions. Suivez toutes les avertissements. Do not use this apparatus near water. N’utilisez pas ce produit près de l’eau (la piscine, la plage, le lac, etc.). Clean only with dry cloth. -
Page 3: Introduction And Contents
MOUNTING mount brackets. SPECIFICATIONS The TXG series from Australian Monitor offer exceptional versatility, performance and value for money. Revision 1.0 June 2012 TXG SERIES INSTALLATION AND OPERATION MANUAL PAGE 3... -
Page 4: Front Panel
FRONT PANEL TXG50 shown here TXG10 shown here Full-range driver High Frequency Driver TXG10 TXG30 1 x 2.5” Full range 1 x 1” Tweeter TXG50 1 x 1” Tweeter Low Frequency Driver TXG30 1 x 4” Woofer TXG50 1 x 6.5” Woofer... -
Page 5: Rear Panel
6W 100V Input Speaker input is via a pair of colour coded binding The TXG10 provides a 6W 100V input via this pair post terminals. The black terminal is negative, the red of spring loaded push terminals. When using the terminal is positive. -
Page 6: Wall Mount Brackets
Fixings must be fitted in accordance with the makers’ instructions. Wall Mount Brackets The TXG speakers are supplied with wall mount brackets, the TXG10 with a multi angle wall bracket, the TXG30 & TXG50 with U brackets. TXG50... -
Page 7: Specifications
SPECIFICATIONS TXG10 TXG30 TXG50 Impedance 8 Ohm (Bypass) 8 Ohm (Bypass) 8 Ohm (Bypass) Power (Tappings) (100V) 30W-15W-7.5W-2.5W 50W-25W-12.5W-6.25W Sensitivty (1 W / 1 M) 88 dB 89 dB 90 dB Calculated Max SPL (Continuous, Peak) 96dB, 102dB 104dB, 110dB... - Page 8 ENGINEERED BY AUSTRALIAN MONITOR Address: 1 Clyde Street, Silverwater, Sydney NSW 2128 Australia. Private Bag 149, Silverwater NSW 1811 ACN 007 573 417 Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au DISTRIBUTED IN AUSTRALIA AND NEW ZEALAND BY HILLS SVL www.hillssvl.com.au P: 02 9647 1411...
