INSTALLATION AND OPERATION MANUAL
QF6WRC
WATER RESISTANT CEILING SPEAKER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QF6WRC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AUSTRALIAN MONITOR QF6WRC

Summary of Contents for AUSTRALIAN MONITOR QF6WRC

  • Page 1 INSTALLATION AND OPERATION MANUAL QF6WRC WATER RESISTANT CEILING SPEAKER...

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Only use attachments/accessories specified by the manufacturer.

  • Page 3: Introduction & Contents

    Mounting and wet areas. Dimensions The QF6WRC is rated at 12 Watts at 8 Ohms with 100V power tappings at 12, 9, 6, 3 and 1 Watts or 70V tappings at 6, 4.5, 3, 1.5 and 0.5 Specifications Watts and is perfect for speech or background music applications.

  • Page 4: Front Panel

    FRONT PANEL 6” FULL RANGE DRIVER FRONT GRILLE PLATE GRILLE GRILLE MOUNTING TABS QF6WRC INSTALLATION AND OPERATION MANUAL...

  • Page 5: Rear Panel

    MOUNTING TABS (Refer to Mounting Section) TAPPING 100 V 70 V IMPEDANCE Brown 12 W 833 Ω 4.5 W 1.11 kΩ Blue 1.67 kΩ Yellow 1.5 W 3.33 kΩ Green 0.5 W 10 kΩ White Direct 8 Ω Black Common QF6WRC INSTALLATION AND OPERATION MANUAL...

  • Page 6: Installation

    Isolate unused wires in the speaker input cable so that they do not contact each other or any other conductive object. NOTE that the QF6WRC has a supervisory capacitor inserted across all 100V tappings. QF6WRC INSTALLATION AND OPERATION MANUAL...

  • Page 7: Removing The Grille

    Once the panel is removed, the grille itself can be removed from the front panel by turning it anticlockwise until the small tabs that hold it in place are released. To reassemble, reinsert the grille following the reverse process and the front plate is simply pressed back into the speaker. QF6WRC INSTALLATION AND OPERATION MANUAL...
  • Page 8 DIMENSIONS ø 238.4 mm (9.4”) 137.5 mm (5.4”) 10.3 mm (0.4”) QF6WRC INSTALLATION AND OPERATION MANUAL...

  • Page 9: Specification

    238.4 X 137.5 mm (9.4” X 5.4”) NET WEIGHT (NO CARTON) 1.7 kg (3.75 lbs) SHIPPING DIMENSIONS (W X H X D) (CARTON) 270 X 270 X 215 mm (10.6” X 10.6” X 8.5”) SHIPPING WEIGHT (CARTON) 2.4 kgs (5.3 lbs) QF6WRC INSTALLATION AND OPERATION MANUAL...

  • Page 10: Frequency Response

    FREQUENCY RESPONSE QF6WRC INSTALLATION AND OPERATION MANUAL...
  • Page 11 NOTES...
  • Page 12 ENGINEERED BY AUSTRALIAN MONITOR Address: Unit 1, 2 Daydream Street, Warriewood NSW 2102 Australia Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au ABN 86 003 231 187...
