Summary of Contents for Redarc SPFP1120
- Page 1 Monocrystalline Folding Solar Panels SPFP1120, SPFP1120-K, SPFP1200 & SPFP1200-K...
-
Page 2: Monocrystalline Folding Solar Panels
MONOCRYSTALLINE FOLDING SOLAR PANELS REDARC folding solar panels are designed to provide a solar charging solution for your auxiliary battery. They feature the folding panel with 50 Amp Anderson Plug connection and a strong nylon carry bag. WARNING & SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS —... -
Page 3: Table Of Contents
CONTENTS Monocrystalline Folding Solar Panels �������������������������������������������������������������� Supplied Parts ���������������������������������������������������������������������������������������������� ������������������������������������������������������������������������������ The Folding Solar Module ���������������������������������������������������������� 120 Watt Monocrystalline Folding Panel 200 Watt Monocrystalline Folding Panel ���������������������������������������������������������� Solar Optimisation ���������������������������������������������������������������������������������������� ������������������������������������������������������������������������������������� Angle to the Sun System Wiring ���������������������������������������������������������������������������������������������� ������������������������������������������������������������������������������������ Installation Notes System Installation ���������������������������������������������������������������������������������������... -
Page 4: The Folding Solar Module
THE FOLDING SOLAR MODULE Anodized Ethylene Aluminium Frame Tetrafluoroethylene (ETFE) Coating Monocrystalline Solar Cells Protective End Caps Diode Protected Strong Junction Box Hinges Genuine Anderson Connector Updated Leg Design... -
Page 5: 120 Watt Monocrystalline Folding Panel
120 WATT MONOCRYSTALLINE FOLDING PANEL 1030 mm 515 mm 50 mm HX025-A 1000V HX025-B 1000V 25 mm SPECIFICATIONS Model SPFP1120 Conversion efficiency 20.6% Peak power 120 W (2 × 60 W) Operating temperature −40°C to +85°C Max system voltage 600 V DC Max power voltage 20.0 V... -
Page 6: 200 Watt Monocrystalline Folding Panel
200 WATT MONOCRYSTALLINE FOLDING PANEL 1370 mm 685 mm 50 mm HX025-A 1000V HX025-B 1000V 25 mm SPECIFICATIONS Model SPFP1200 Conversion efficiency 23.0% Peak power 200 W (2 × 100 W) Operating temperature −40°C to +85°C Max system voltage 600 V DC Max power voltage 20.0 V Cell construction Max power current... -
Page 7: Solar Optimisation
SOLAR OPTIMISATION ANGLE TO THE SUN REDARC solar panels will perform at their peak with the panel face angled directly towards the sun. In practice this is not always achievable, so REDARC recommends having your panels face NORTH at an angle of between 20° and 40° from the ground. This will ensure the best total output from your panel across the course of the day, no matter what season. -
Page 8: System Wiring
• Always ensure the connection at Anderson plug is clean, sound and is wired with the correct polarity. • REDARC recommends the regulator be installed as close as possible to the battery(s). If you need to use different cables ensure their length does not exceed 10 m from the panel to the regulator. -
Page 9: System Installation
SYSTEM INSTALLATION STANDARD SETUP 120 W OR 200 W Solar Panel Solar Regulator 1.5 m SRC0009 (kit only) 5 m Anderson-to-Anderson extension cable SRC0018 (kit only) - Page 10 1; and the claim is notified to REDARC in writing at the postal address or email any component of or accessory for any product in clause 1.1 address specified in clause 23 and includes: to 1.6 (inclusive) manufactured or supplied by REDARC.
- Page 11 20. The agents, officers and employees of any distributor or reseller of the proof of purchase documentation for the Solar Product from Solar Products and of REDARC are not authorised to vary or extend the an authorised distributor or reseller of REDARC, which clearly terms of this Warranty.
- Page 12 For free technical assistance please contact: REDARC Electronics 23 Brodie Road North, Lonsdale SA (08) 8322 4848 power@redarc.com.au www.redarc.com.au/solar Copyright © 2020 REDARC Electronics Pty Ltd. All rights reserved. This product is manufactured in China. INST65-1...
