QUEEN ANNE DRESSER & STOOL
ASSEMBLY INSTRUCTIONS
Thank you for purchasing the QUEEN ANNE DRESSER & STOOL. Please read the
instructions carefully to ensure safe operation of the product.
Size: W710 x D405 x H1270mm
Colour: BLACK,IVORY
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list. Do not destroy any of
the packaging until you are certain that you have all the necessary parts for the assembly.
CAUTION: There are small components used in the construction of this unit. These loose items should be kept away
from young children whilst assembling your unit to avoid the danger of choking hazards.
Tools Required
Batch No.:WMI14931
Page 1 of 10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for GFW QUEEN ANNE WMI14931
Summary of Contents for GFW QUEEN ANNE WMI14931
- Page 1 QUEEN ANNE DRESSER & STOOL ASSEMBLY INSTRUCTIONS Thank you for purchasing the QUEEN ANNE DRESSER & STOOL. Please read the instructions carefully to ensure safe operation of the product. Size: W710 x D405 x H1270mm Colour: BLACK,IVORY PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction. Carefully open the pack supplied and check the contents against the parts and fittings check list.
-
Page 2: Care Information
QUEEN ANNE DRESSER & STOOL ASSEMBLY INSTRUCTIONS IMPORTANT - READ CAREFULLY - RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. INFORMATION This product is intended for a maximum weight of 30 kg. Do not exceed this weight. Due to the size of this product we recommend that it is assembled in the room intended for use. ... - Page 3 QUEEN ANNE DRESSER & STOOL ASSEMBLY INSTRUCTIONS Please check the pack contents before assembling the product. If any components are missing, please contact your retailer. The fittings pack contains small items that should be kept away from small children. Batch No.:WMI14931 Page 3 of 10...
- Page 4 QUEEN ANNE DRESSER & STOOL ASSEMBLY INSTRUCTIONS Parts Description: Dresser Top Description: Dresser Leg Description: Mirror Description: Base Mirror Qty: 1 Qty: 4 Qty: 1 Support Carton No: 1 of 1 Carton No: 1 of 1 Carton No: 1 of 1 Qty: 1 Carton No: 1 of 1 Description: Mirror...
- Page 5 QUEEN ANNE DRESSER & STOOL ASSEMBLY INSTRUCTIONS Batch No.:WMI14931 Page 5 of 10...
-
Page 6: Hints And Tips
QUEEN ANNE DRESSER & STOOL ASSEMBLY INSTRUCTIONS Hints and Tips The Barrel nut must be inline with the bolt. After insertion the bolt will thread through the nut to secure. Layout Parts on Soft Surface Lay out all parts on a soft surface i.e. Rug, Carpet or Packaging Carton Batch No.:WMI14931 Page 6 of 10... - Page 7 QUEEN ANNE DRESSER & STOOL ASSEMBLY INSTRUCTIONS Parts Required STEP 1 1. Dresser Top x 1 2. Dresser Leg x 4 B. Large Bolt x 8 F. Large Washer x G. 4mm Allen Key x Parts Required STEP 2 4. Base Mirror Support x 1 5.
- Page 8 QUEEN ANNE DRESSER & STOOL ASSEMBLY INSTRUCTIONS Parts Required STEP 3 B. Large Bolt x 2 D. Barrel Nut x 2 E. Small Washer x G. 4mm Allen Key x Ensure the barrel nut is lined up with the bolt when fitting. Parts Required STEP 4 3.
- Page 9 QUEEN ANNE DRESSER & STOOL ASSEMBLY INSTRUCTIONS Parts Required STEP 5 6. Stool Top x 1 7. Stool Legs x 4 B. Bolt x 8 F. Large Washer x G.4mm Allen Key x Batch No.:WMI14931 Page 9 of 10...
-
Page 10: Complete Assembly
QUEEN ANNE DRESSER & STOOL ASSEMBLY INSTRUCTIONS Complete Assembly Your QUEEN ANNE DRESSER & STOOL is now completely assembled. Periodically check to ensure that the components are in their proper position, free from damage. Also, make sure the connectors are tight and secure. Keep instructions for future reference Batch No.:WMI14931 Page 10 of 10...
