Arjohuntleigh Sara Combilizer Quick Reference Manual page 3

Mattresses
Head mattress
Body mattress
Mattress attachment points
Attach mattress attachment strap
1
Insert attachment strap
through inner short slot.
ArjoHuntleigh AB
Hans Michelsensgatan 10
211 20 Malmö, Sweden
www.arjo.com
2
A
Turn slip lock (A).
Pull mattress to secure
attachment.
08.KC.06EN_1 • 05/2020 • Page 3/3
Mattress attachment straps
Head mattress has two (2) attachment straps.
Body mattress has eight (8) attachment straps.
The attachments straps have slip locks at the end.
Back support plate, head part (x2)
Back support plate, shoulder part (x2)
Back support plate, lower body part (x2)
Seat plate (x2)
Leg support plate (x2)
Remove mattress attachment strap
1
A
Push attachment strap
further into slot and turn
slip lock (A).
Slip lock
2
Pull attachment strap
out through slot.
