Arjohuntleigh Sara Combilizer Quick Reference Manual page 2

Adjust length
of foot support
B
Pull out spring lock (A).
Raise or lower foot support plate (B).
Release spring lock (A).
Push and pull to secure.
Adjust width
shoulder support
B
A
Pull out spring lock (A).
Position shoulder support (B).
Release the spring lock (A).
Push and pull to secure.
Fold up shoulder support
Lift up shoulder support until it
locks into place.
Push and pull to secure.
Adjust additional
length of foot support
A
A
B
Pull catch forward (A).
Raise or lower foot plate (B).
Release catch (A).
Push and pull to secure.
Fold down shoulder support
1
A
B
Push in spring lock on right side (A).
Shoulder support (B) folds down.
Battery
Battery is located on the back of
Sara Combilizer.
08.KC.06EN_1 • 05/2020 • Page 2/3
Remove foot support
A
Pull catch forward (A).
Remove foot plate (B).
Release catch (A).
2
A
B
Pull out spring lock on left side
(A).
Shoulder support (B) folds down.
Remove battery
Pull battery straight out.
B
