QUICK REFERENCE GUIDE - FUNCTIONS
Sara Combilizer
Apply and release brake
Apply brake
Attach armrest
1
Rotate armrest to
vertical position.
Adjust armrest width
1
A
Tilt the armrest slightly
backwards (A).
2
Slide armrest onto the connection rod (A).
Fold down armrest (B).
2
Grab the bar (B) and pull or
push the armrest to adjust
width. Fold down armrest.
08.KC.06EN_1 • 05/2020 • Page 1/3
Release brake
Adjust armrest height
B
A
Hold armrest, pull out and hold spring
lock knob (A). Raise or lower armrest (B).
Release spring lock knob (A).
Remove armrest
1
B
Adjust armrest in
outermost position (A)
B
2
A
Rotate armrest to
vertical position (B),
pull out and remove (C).
A
B
C
