Craftmade CL52 Specifications

MODEL #CL52BU B5/52S-TK7
DIMENSIONS
A-(2"DR)-21 1/2"
A-(6"DR)-25 1/2"
(DR-Down Rod)
This Craftmade fan is
shipped with two down rods,
a 2" for mounting close to the
ceiling, a 6" rod for
mounting farther away.
WARRANTY
Lifetime Warranty
Finish with Satin Teak Custom Wood Blades
SPECIFICATIONS
Blade Sweep – 52"
# of Blades – 5
Blade Pitch – 14°
Motor Size (MM) –
188 x 15
AMPS (HI Speed) – 0.5
Watts (HI Speed) – 60
RPM (HI/MED/LO) –
170/125/55
CFM (HI Speed) – 6300
Integrated Uplighting uses
3-60 watt medium based
bulbs
(Not Included)
Also Available in:
SL - Saddle Leather
Chalice
CL52BU with
B5/52S-TK7
Chalice in Burnt Sienna/Oiled Bronze
STANDARD
OPERATION
Chain pull
OPTIONAL TCS
CONTROL SYSTEM
®
