  • Page 1 User Manual P603T0001, valid for P-603 CBo, 1/11/2021 P-603 Inexpensive PiezoMove Linear Actuator Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws...
  • Page 2: Table Of Contents

    Cleaning the P-603 ..........................15 Customer Service Technical Data Specifications ............................. 16 Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 2 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws...
  • Page 3 Ambient Conditions and Classifications ..................... 18 Dimensions ............................19 Pin Assignment ........................... 20 Old Equipment Disposal Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 3 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws...
  • Page 4: About This Document

    Warning sign on the product that refers to detailed information in the documentation. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 4 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,...
  • Page 5: Other Applicable Documents

    Positioning of loads  Dynamic positioning  Vibration damping  Force generation  Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 5 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws...
  • Page 6: Safety Precautions

    The P-603 can only be used as intended in conjunction with suitable drive and control electronics (p. 10) available from PI. The electronics are not included in the scope of delivery of the P-603. The electronics must provide the required operating voltages. To ensure proper performance of the servo-control system (P-603.xSx only), the electronics must also be able to read out and...
  • Page 7  Set the piezo voltage to 0 V on the controller. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 7 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,...
  • Page 8: Mechanical Dangers

    The P-603 is operated near to its resonant frequency.   If you notice oscillations, stop the P-603 immediately. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 8 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,...
  • Page 9: Thermal Dangers

    Stranded wires P-603.5S1 500 µm Stranded wires P-603.5S2 500 µm LEMO Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 9 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws...
  • Page 10: Product View

    P-603.x01 (models without sensor)  To order, contact our customer service department (p. 15). Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 10 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,...
  • Page 11: Unpacking

    4. Keep all packaging materials in case the product needs to be returned. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 11 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,...
  • Page 12: Installation

    Figure 2: Mounting interface and moving part Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 12 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,...
  • Page 13: Startup And Operation

     Follow the instructions in the user manual for the electronics used for startup and operation of the P-603. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 13 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,...
  • Page 14: Discharging The P-603

    2. Short-circuit the stranded wires of the P-603 for at least a few seconds using a 10 kΩ discharge resistor. If the P-603 has a connector:  Connect the voltage connector of the P-603 to the switched off PI electronics, which have an internal discharge resistor, for at least a few seconds. Maintenance The P-603 is maintenance-free.
  • Page 15: Cleaning The P-603

    (e.g., isopropanol or ethanol). Customer Service For inquiries and orders, contact your PI sales engineer or send us an email (service@pi.de).  If you have any questions concerning your system, provide the following information: −...
  • Page 16: Technical Data

    S2 version: 0.04 S2 version: 0.05 S2 version: 0.06 Cable length as P-603.xS1 Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 16 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws...
  • Page 17: Maximum Ratings

    E-610, E-625 E-610, E-625 E-610, E-625 E-610, E-831 The resolution of the system is only limited by the noise of the amplifier and measuring technology because PI piezo actuators are free of friction. Ask about customized versions. Maximum Ratings P-603 PiezoMove linear flexure actuators are designed for the following operating data:...
  • Page 18: Ambient Conditions And Classifications

    The P-603 is intended for installation in devices that fulfil the following classifications: Protection class Degree of protection IP20 according to IEC 60529 Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 18 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws...
  • Page 19: Dimensions

    P-603.5S1 / .5S2 / .501 Figure 3: Dimensions of the P-603 (.x01 models without sensor) Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 19 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,...
  • Page 20: Pin Assignment

    PZT + (-20 to 120 V) Connector shell PZT - (GND) Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 20 / 21 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws...
  • Page 21: Old Equipment Disposal

    Dispose of your old equipment according to international, national, and local rules and regulations. In order to fulfil its responsibility as the product manufacturer, Physik Instrumente (PI) GmbH & Co. KG undertakes environmentally correct disposal of all old PI equipment made available on the market after 13 August 2005 without charge.
