Tyco Fire Product CENTRAL H Instruction Manual

5.6 k-factor standard response standard coverage recessed pendent fusible solder type sprinkler

Advertisement

Quick Links

CENTRAL
Model H Recessed
5.6 K-factor
Standard Response
Standard Coverage
Recessed Pendent Fusible Solder Type Sprinkler
Tyco Fire Products --- www.centralsprinkler.com
451 North Cannon Avenue, Lansdale, Pennsylvania 19446 --- USA
Customer Service/Sales: Tel: (215) 362-0700 / Fax: (215) 362-5385
Technical Services: Tel: (800) 381-9312 / Fax: (800) 791-5500
General
Description
The Central Model H, 5.6 K-factor
Recessed Pendent Sprinklers are
automatic sprinklers of the fusible solder
type. They are standard response -
standard orifice spray sprinklers
intended for use in fire sprinkler
systems designed in accordance with
the standard installation rules recog-
nized by the applicable Listing or
Approval agency (e.g., UL Listing is
based on NFPA 13 requirements).
The Central Model H Recessed
Pendent Sprinklers incorporate a center
strut mechanism with a special two-
piece recessed escutcheon assembly
permitting 1/2" of field-adjustment.
Unlike most other recessed sprinklers,
the upper escutcheon support piece is
factory installed on the base of the
sprinkler frame, assuring a Listed
Installation. The ceiling escutcheon
plate is easily installed after the
sprinkler is in place either by the
standard "push-on" escutcheon or the
special "thread-on" escutcheon. This
feature allows removal of ceiling panels
for easy access to ceiling equipment
without taking the system out of service
to remove the sprinkler.
Operation: A fusible alloy is sealed into
a bronze actuating rod (center strut) by
a stainless steel ball. When the alloy
melts at its rated temperature, the ball is
forced upward into the center strut,
releasing the two ejectors and operating
the sprinkler.
WARNING
The Model H Recessed Pendent
Sprinklers described herein must be
installed and maintained in compliance
with this document, as well as with the
applicable standards of the National
H
Fire Protection Association, in addition
to the standards of any other authorities
having jurisdiction. Failure to do so may
impair the integrity of these devices.
The owner is responsible for maintain-
ing their fire protection system and
devices in proper operating condition.
The installing contractor or sprinkler
manufacturer should be contacted
relative to any questions.
Technical
Data
Sprinkler Identification Number
SIN C3711
Approvals
UL & ULC Listed. FM & NYC Approved
(Refer to Table 1. The approvals apply
only to the service conditions indicated
in the Design Criteria Section)
Maximum Working Pressure
175 psi (12,1 bar)
250 psi (17,3 bar) UL & ULC
Pipe Thread Connection
1/2 inch NPT
Discharge Coefficient
K = 5.6 GPM/psi
1/2
(80,6 LPM/bar
Temperature Ratings
165°F/74°C or 212°F/100°C
Finishes
Sprinkler: White Polyester, Chrome
Plated, or Natural Brass
Recessed Escutcheon: White Coated,
Chrome Plated, or Brass Plated
Physical Characteristics
The Model H Recessed Pendent
Sprinklers utilize a dezincification resistant
(DZR) bronze frame and a brass deflector.
The waterway is sealed with copper seal
disk, and the fusible assembly is con-
structed of bronze and stainless steel
components.
Standard Spray
Recessed
Pendent
Sprinklers
1/2
)
2-01
No. 1-3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CENTRAL H and is the answer not in the manual?

Questions and answers

Summary of Contents for Tyco Fire Product CENTRAL H

  • Page 1 2-01 CENTRAL Model H Recessed 5.6 K-factor Standard Response Standard Coverage Recessed Pendent Fusible Solder Type Sprinkler Tyco Fire Products --- www.centralsprinkler.com 451 North Cannon Avenue, Lansdale, Pennsylvania 19446 --- USA Customer Service/Sales: Tel: (215) 362-0700 / Fax: (215) 362-5385 Technical Services: Tel: (800) 381-9312 / Fax: (800) 791-5500 Fire Protection Association, in addition General...
  • Page 2 Figure 1 - Model H Recessed Sprinkler Figure 2 - Model H Recessed Sprinkler with Push-on Escutcheon with Threaded Escutcheon FACE OF SPRINKLER 2-3/4"(69,9 mm) Max. FACE OF SPRINKLER 2-3/4"(69,9 mm) Max. FITTING 2-1/2" (63,5 mm)Min. FITTING 2-1/2" (63,5 mm)Min. WRENCH FLAT WRENCH...
  • Page 3 Design Criteria The Model H Recessed Pendent Sprinklers are UL, ULC Listed and MEA Approved for use in accordance with current NFPA standards. The Recessed Pendent Sprinklers are only listed with the Series A/H Recessed Escutcheon Assemblies. The Model H Recessed Pendent Sprinklers are FM Approved for use in accordance with the FM Loss Prevention Data Sheets.
  • Page 4 Limited Care & Ordering Warranty Maintenance Information Products manufactured by Tyco Fire The Model H Recessed Pendent Ordering Information: When Products are warranted solely to the placing an order, indicate the full Sprinklers must be maintained and original Buyer for ten (10) years serviced in accordance with the product name.
