Contemporary Research VCC Dimensions

3.35
Video Out
1.125
UNLESS OTHERWISE SPECIFIED:
DECIMAL DIMENSIONS INCLUDING HOLES
FRACTIONAL DIMENSIONS INCLUDING HOLES
ANGLES
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
ALL DIMENSIONS IN INCHES.
DO NOT SCALE THIS DRAWING.
5.50
Contemporary
Research
CR System Tools
CC
VCC
Closed Caption Decoder
Caption/Control Control Port
Video In Settings 5 4 3
TOP VIEW
1 2 3 4
SYM
DRAWN
RSH
XX .010
CHECKED
.005
XXX
1/64 APPROVED
1
RELEASED
DIR
12 VDC Pwr In
100 mA max
Pwr
2 1 LED ( ) ( )
( ) ( )
ECO NO. DESCRIPTION
**** REVISIONS ****
DATE
Contemporary
09/28/04
Research
DATE
TITLE PRODUCT DRAWING
CST-VCC
DATE
CLOSED CAPTION DECODER
SCALE DWG. NO.
NONE
DATE
SHT OF
1 1
FILE
CST-VSCC_PD.DWG
TOP
DATE APPR.
950-5053
