Connections – ICW ...4 Internal Closures ...5 Includes ...5 Installation ... 6 AC Power and Smart TV control...6 RF Coax and iCC-Net Operation (ICC2, ICC1)...6 iCW-Net Connection (ICW)...6 Using the IC-RC Remote for On-Screen Menus...6 On-Screen Setup Menus...7 RS-232 Control Protocol ... 8 Overview ...8...
ICC and ICW Smart TV Controllers. The ICC2 TV Controller communicates bi-directionally over the same RF coax that carries the CATV channels, while the ICC1 TV Controller receives commands over RF. The ICW TV Controllers connects over a twisted-pair network using Category 5 or Category 3 wiring and connectors.
‘F’, female, 75 ohm impedance, RF from CATV system iCC-Net: Carried over the same RF coax connection as TV channels Receive: (ICC2, ICC1) Mid-band VHF, 74.7MHz, sent from ICC-HE Head-End Network Controller -25 to +35 dBmV signal level Transmit: (ICC2 only) Sub-band, 5.6MHz sent to Head-End Network Controller ±80 KHz max carrier deviation...
Closure 2 - Pins 1 & 3 for dry contact to external power relay, AMX PC1 or similar Includes Smart TV data link cable Mounting hardware RF Loop Cable (ICC models only) 12 VDC Power Supply (Not included for international shipments or if powered by TV) Contemporary Research Corporation ICC/ICW Smart TV Controller...
4. The TV/COM LED will be off before inserting the cable, switches to on when communication is established, flashes when a button is pressed on the TV or IR remote. RF Coax and iCC-Net Operation (ICC2, ICC1) 1. Connect the CATV RF Coax cable into the RF In jack.
ICC2 unit’s RF output. Press Enter to stop transmitting, or the unit will automatically stop after 50 seconds. 65481 Display ICC2 transmitter frequency control voltage – should be 2000 - 3150. 65483 Display DF transmitter frequency deviation – should be 245 - 300. Contemporary Research Corporation ICC/ICW Smart TV Controller...
RS-232 control for up to 4000 TV Controllers is provided through an iC-series Head-End Network Controller. The ICC-HE Head-End manages iC-Net communication over RF Coax to ICC1 (1-way) and ICC2 (2-Way) TV Controllers as well as ICW TV Controllers over twisted-pair Cat3/5 wiring. The ICW-HE Head-End operates on the twisted-pair network only.
Same special-function channels as in the T Channel Select section above Select Q Channel “$A5,<dh>,<dl>,2,’QT’,<channel>” (7 bytes) – Tunes channel if included in TR Contemporary Research Corporation Selects TV frequency tuning mode, 0=CATV, 1=Broadcast/Antenna 0 = Mute ICC/ICW Smart TV Controller...
Page 10
SP "$A5,0,0,3,'SP'" (6 bytes) Queries the Head-End for the number of devices present on the network and the number of devices expected. Contemporary Research Corporation order End, so the system will know the user is trying to change channels. In response, the system could change channels on a media sources, like a VCR or satellite.
Page 11
Ex1: “$A5,<dh>,<dl>,10,‘DM’, 2,7,0,0,1,0,’TEST’ ” displays the word TEST on the second line, white text, inserted over video, small size with drop shadow, and timing out after 15 seconds. Ex2: “$A5,<dh>,<dl>,2,‘DM’ ” clears on-screen display, also clears persistent text Contemporary Research Corporation ICC/ICW Smart TV Controller...
Sent when unit receives a new function command is pressed (1-8) or released (0) from the IR remote. 0 = Release 1 = Play 2 = Stop 3 = Pause 4 = Fast Forward 5 = Rewind 8 = Record Contemporary Research Corporation ICC/ICW Smart TV Controller...
Page 13
Tip: If the number of present and expected devices match, the green Net LED on the HE will blink once per second. If the two numbers do not agree, the LED blinks twice per second. Contemporary Research Corporation 105 = Media Menu 106 = Cursor Right...
You've probably figured out that you never want to assign a virtual device number to an actual device in the system. If you assigned #1536 to a device, all the TV controllers in Zone 6 would respond every time you sent a command to that one device.
One of the key tasks for iC-Net integrators is to create a logical System Map, assigning device numbers to TV controllers so they fall into logical zones. The device mapping could be sorted by type or location; whichever suits the application.
Typical RF and ICC-Net Signal Flow The diagram below shows the structure of a typical Contemporary Research media retrieval system. One of the key aspects for iCC-Net communication is to provide a forward and return (sub-channel) path for data if you’re using ICC2 2-way TV Controllers.
Make sure you minimize blockage of any vent slots in the process hood. • Drill pilot holes (#36 0.106” or 7/64 0.109”), between 6 ¾ to 6 9/16 apart • Attach TV Controller using the two #6 self-tapping screws (included) Contemporary Research Corporation ICC/ICW Smart TV Controller...
Article 820-40 of the National Electrical Code (Section 54 of Canadian Electrical Code, Part I), that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as possible. Contemporary Research Corporation ICC/ICW Smart TV Controller...
Limited Warranty and Disclaimer Contemporary Research Corporation (CR) warrants this product to be free from defects in material and workmanship under normal use for a period of two years from the date of purchase from CR. Should such a defect occur CR will repair or replace, at their option, the defective product at no cost for parts or labor.
