Summary of Contents for Walker Edison BR3DBENNS
- Page 1 BR3DBENNS Assembly Instructions Please visit our website for the most current instructions, assembly tips, to report damage or request parts. www.walkeredson.com Revised 01/2021...
- Page 3 Description Description Part# Part# Top panel Back Panel 01 pcs 01 pcs Left side panel Front Drawer 01 pcs 03 pcs Drawer Right Side Right side panel 03 pcs 01 pcs 03 pcs Drawer Left Side 02 pcs Small Front crossbeam 03 pcs 06 pcs Drawer bottom...
- Page 4 Ø8*30mm Wooden dowel Ø3,5*30mm Screw Ø3,5*14mm Screw Ø4,0*25mm Screw Ø8*20mm Wooden dowel Ø10*10 Nail Corner Handle m4*22mm Screw Hammer recommended for assembly (not included)
- Page 5 Step 1 Ø8*30mm Ø8*20mm Insert Wooden dowel (E) into part (5). Insert Wooden dowel (A) into part (4), (6), (10) and (11). Step 2 Ø8*30mm Ø4*25mm Insert Wooden dowel (A) into part (2) and (3). Secure part secure part (5) to part (2) and (3) with screw (D).
- Page 6 Step 3 Step 4 Ø3,5*30mm Ø3,5*30mm Secure part (4) to part (2) with screw (B). Secure part (4) to part (3) with screw (B). Step 5 Ø3,5*30mm Secure part (1) to part (2) and (3) with screw (B).
- Page 7 Step 6 Ø4*25mm Secure part (6) to part (2) and (03) with screw (D). Step 7 Ø3,5*14mm Secure part (7) to part (6) with hardware (G) and screw (C).
- Page 8 Step 8 Ø4*25mm Secure part (5) to part (2) and (3) with screw (D). Step 9 Ø8*30mm Insert Wooden dowel (A) into part (5).
- Page 9 Step 10 90° Ø10*10mm Secure back panel (8) to body with nails (F) Step 11 Ø3,5*30mm Secure part (10) and (11) to part (9) with screw (B). Insert part (12) between parts (10) and (11) Secure part (13) with screw (B).
- Page 10 Step 12 ØM4*22mm Secure hardware (H) part (9) with screw (J). Step 13 Drawer Stop Insert wood dowel (A) on the inside of all drawers while drawer is inside the unit. Make sure dowel is flush with panel. Ø8*30mm P.10...
- Page 11 Step 14 Assembly Complete! Maintenance Guide To maintain long term performance and easy gliding of your solid wood drawers, we recommend applying wax to the wooden guide rails. 1. Bee's wax is recommended or Paraffin wax from a standard candle can be used. 2.
