Page 2
and hammmer VII. Maintenance Guide To maintain long term performance and easy gliding of your solid wood drawers, we recommend applying wax to the wooden guide rails. 1. Bee's wax is recommended or Paraffin wax from a standard candle can be used. 2.
The side drawer with WARNING LABEL, should be mounted in highest drawer. Part# Description Part# Description Anti-tipping Right crossbeam foot Base Left crossbeam foot Back panel Drawer runner Right side panel Foot Large drawer front Drawer back Large drawer back Drawer bottom Small drawer front Right drawer side...
Page 5
Attention to the Step 1 dowel length: ø10*20mm Insert wood dowel (B) into part 27. Ø10*20mm Step 2 Ø8*30mm Insert Wooden dowel (A) into parts (5), (6),(19), (20), (22), (28), (32), (37), (38), and (41). Step 3 Ø4*25mm Secure part (27) to part (22) an to part (28) with screw (C) and Phillips head screwdriver.
Page 6
Step 4 Ø3,5*30mm Secure part (20) to part (22) and part (28) with screw (D) and Phillips head screwdriver. Step 5 Ø4,0*40mm Secure part (24) to part (22) and (28) with screw (E) and Phillips head screwdriver. Step 6 Ø3,5*30mm Secure part (8) to part (5) and to part (6), with screw (D) and Phillips head screwdriver.
Page 7
Step 7 Ø4,0*40mm Attach assembled leg to the body. Secure feet to the body from inside the unit with bolt (G) Ø7*60mm and hex key (H). Secure assembled leg and part (19) with screw (E) and Phillips head screwdriver. Step 8 Ø3,5*30mm Secure parts (21) to part (22) and (28) with screw (D) and Phillips head screwdriver.
Page 8
Step 9 Please assemble on a clean soft surface to avoid damage. Ø3,5*30mm Ø3,5*16mm Secure anti-tipping (23) with screw (D) and screw (N) and Phillips head screwdriver. Step 10 Name and address of the supplier and date of production. Please assemble on a clean soft surface to avoid damage.
Page 9
Step 11 FRONT Ø4*25mm Secure part (27) to part (22) an to part (28) with screw (C) and Phillips head screwdriver. Step 12 FRONT Insert Wooden dowel (A) into part (27). Ø8*30mm...
Page 10
Step 13 Ø3,5*30mm Secure part (32) and (41) to part (15) with screw (D) and Phillips head screwdriver. Insert part (13) between parts (32) and (41). Attach part (29) to parts (32) and (41) with screws(D) and Phillips head screwdriver. Step 14 Ø3,5*30mm Secure part (37) and (38) to part (10) with screw (D) and Phillips head screwdriver.
Page 11
Step 16 Attach part (K) with screw (N) and washer (L), in the frame of superior panel unit using Phillips head screwdriver. With drilling machine make one hole in the wall, insert part (M) in the hole. Secure part (K) with screw (E) and washer (L) in the wall using a Phillips head screwdriver.
