- Page 1 16" RAPIDO SERIES USER MANUAL/PANDUAN PENGGUNA/ 用户手册 型号 MODEL / MODEL / ROF-RAPIDO16-3B...
- Page 2 CEILING FAN/ KIPAS SILING/吊扇 SUPPLIED PARTS / BAHAGIAN YANG DIBEKALKAN/ 提供零件 PARTS QUANTITY PARTS QUANTITY BAHAGIAN KUANTITI BAHAGIAN KUANTITI 零件 数量 零件 数量 BRACKET ASSEMBLY / KURUNGAN BLADE NUT / NAT BILAH / PERHIMPUNAN/ 吊架组件 风叶螺母 REMOTE CONTROL HOLDER / TOP CANOPY / PEMEGANG ALAT KAWALAN JAUH/ SENGKUAP ATAS/ 吊盅...
- Page 3 WARNING TO ENSURE YOUR PERSONAL SAFETY, PLEASE READ THROUGH THE INSTRUCTION MANUAL BEFORE OPERATING THE PRODUCT. • Do not bend the blade during installation, blades balancing or fan cleaning. • To prevent accidents, power switch must be OFF and electrical wiring must be disconnected before ceiling fan installation, dismantling, maintenance or cleaning.
- Page 4 SAFETY GUIDELINES • Please do not install the ceiling fan at high humidity areas. • Distance between fan blades and ground must be at least 2.5 meter and above. • Do not touch the ceiling fan while it is operating. •...
- Page 5 INSTALLATION PROCEDURES / TATACARA PEMASANGAN / 安装步骤 STEP 1.a Secure bracket assembly to ceiling joist or suitable piece of timber inserted between the ceiling joist. The placement direction of the bracket assembly should follow the “Oscillator Centre Hole Direction & Facing Out as Label Indication”...
- Page 6 Diagram 1.b / Gambar 1.b / 图1.b STEP 1.b Concrete Ceiling – According to the length if expansion screws bore holes by percussive drill with ø8mm. After that, fix the bracket assembly on ceiling by expansion screws. (Refer diagram 1.b) LANGKAH 1.b Siling berkonkrit –...
- Page 7 STEP 3 （Refer diagram 3) Connect quick connectors as figure showed. Insert the RF Remote Receiver into bracket assembly. LANGKAH 3 (Rujuk gambar 3) Sambung wayar peyambung mengikut kadar bacaan yang ditunjukkan. Pasang dan masukkan alat kawalan Penerima RF ke dalam kurungan perhimpunan. 步骤...
- Page 8 STEP 4（Refer diagram 4) Screw 2 screws halfway into the bracket assembly, install top canopy’s keyhole slots around the screws and twist clockwise, and then tighten all 4 screws. LANGKAH 4 (Rujuk gambar 4) Pasangkan 2 skru separuh ke dalam kurungan perhimpunan, pasangkan sengkuap atas ikut slots lubang kunci sekeliling skru dan putaran mengikut arah jam serta ketatkan kesemua 4 skru.
- Page 9 STEP 5（Refer diagram 5) Connect both wire connector plug from RF Receiver wire connector and from motor assembly’s wire connector as below diagram shown. Align the U-hanger coupler holes in thread with hanging tube and then tighten all 4 screws firmly without over tightening. LANGKAH 5 (Rujuk gambar 5) Sambungkan kedua-dua penyambung dawai wayar dari penyambung wayar Penerima RF enyambung wayar motor perhimpunan seperti gambar rajah yang ditunjukkan di bawah.
- Page 10 STEP 6（Refer diagram 6) Insert the blade into the motor shaft, assure blade’s slot into the shaft’s pin, and then twist blade nut counter-clockwise to lock the blade in place. LANGKAH 6 (Rujuk gambar 6) Masukkan bilah ke dalam aci motor, pastikan slot bilah ke dalam pin aci motor, dan putarkan nat bilah mengikut arah lawan jam untuk menguncinya.
- Page 11 STEP 7（Refer diagram 7) Loosen the hinge knob to adjust the fan up-down angle, and then tighten the hinge knob to lock the fan at your desire position. LANGKAH 7 (Rujuk gambar 7) Longgarkan tombol engsel untuk menyesuailkan kipas ke atas/bawah, dan kemudian ketatkan tombol engsel untuk mengunci kipas di kedudukan keinginan anda.
- Page 12 RF TRANSMITTER / PEMANCAR RF / 射频发射器 Function of Transmitter / Fungsi Pemancar/ 发射器功能 ① POWER ② ③ TURBO LED Indicator Light / Lampu Penunjuk LED / LED 指示灯 LED Indicator Light / Lampu Penunjuk LED / LED 指示灯 Switch off the ceiling fan. Switch off the ceiling fan.
- Page 13 Note – In the event of Transmitter (Remote Control)/Receiver cannot be control, please follow the “Remote Control Pairing Procedure” as below :- • Insert 2 units of AAA battery into the remote control. • Switch on the ceiling fan (Power Supply). •...
- Page 14 IMPORTANT / PERKARA PENTING / 重要事项 DO NOT CONNECT THIS CEILING FAN REMOTE CONTROL TO DIMMER SWITCH OR WALL REGULATOR. JANGAN SAMBUNGKAN KAWALAN JAUH KIPAS SILING INI KEPADA SUIS DIMMER ATAU PENGAWAL DINDING. 请勿将此吊扇遥控器连接至调光器开关或墙壁调节器。 Ceil ing must mounted above 2.5m from the floor and 0.5m from the wall to the blade.
- Page 15 UNTUK MOTOR KIDAS SAHAJA 仅 限于风扇电机 UNTUK ALAT PENERIMA SAHAJA 仅 限于遥控接收 器 UNTUK SEMUA BAHAGIAN KIPAS KECUALI AKSESORI 所 有产品（不包 括 配 件 ）...
