  • Page 1 Operating Instructions Sandblasting Cabinet SSK 2.5 SSK 2.5...
  • Page 2: Table Of Contents

    Passing on as well as copying of this document, the use and distribution of its content are prohibited if not explic- itly permitted. Contraventions are liable to compensa- tion. Subject to technical modifications and error. SSK 2.5 | Version 1.08...
  • Page 3: Intorduction

    WARNING! This combination of symbol and signal words indi- cates a possibly dangerous situation which may lead to death or severe injuries if they are not avoided. SSK 2.5 | Version 1.08...
  • Page 4: Obligations Of The Operating Company

    The qualifications of the personnel for the different tasks working conditions at the place of use sandblasting are mentioned below: cabinet. She must implement these in form of oper- ating manuals for the operation of the sandblasting cabinet. SSK 2.5 | Version 1.08...
  • Page 5: Personal Protective Equipment

    The industrial helmet protects the head against falling objects and hitting on fixed objects. Respiratory protection The respiratory protection protects the respiratory tract against the ingress of dust and small foreign bodies. Fig. 1: Safety markings on the sandblasting cabinet SSK 2.5 SSK 2.5 | Version 1.08...
  • Page 6: Intended Use

    Intended use Intended use Technical Data The sandblasting cabinet SSK 2.5 must only be used to Model SSK 2.5 Rust removal and cleaning of metal surfaces with air Volumen work cabine 310 Liters tools using sandblasting with grain size of 0,12 mm - 0,25 mm.The working pressure may be max.
  • Page 7: Transport, Packaging, Storage

    For transport, the sand blasting cabin is on a pallet. The pallet must be secured in the loading area in accordance with the regulations. Fig. 3: Sandblasting cabinet SSK 2.5 To protect against moisture and dirt, all bare metal parts are greased.
  • Page 8: Assembly And Connecting

    Remove the hood cover on the cab, insert the ves and line! pipe and seal with sealant. hen secure the corner with the suction tube again. Step 11: Tighten all screws and nuts. SSK 2.5 | Version 1.08...
  • Page 9: Commissioning

    Adjustment of the amount of blast feed The amount of blasting material feed, consisting of the negative pressure flowing through the screw [Pos. 38] air and the blasting agent used, is adjustable on the mete- ring valve [Pos. 13]. SSK 2.5 | Version 1.08...
  • Page 10: Care, Maintenance And Overhaul

    Maintenance and repair work may only be car- ried out by qualified personnel. - too deeply screwed in component [pos. 7] (small di- stance inside to the nozzle): too little negative pressure and thus also little abrasive SSK 2.5 | Version 1.08...
  • Page 11: Care By Cleaning

    All plastic parts and painted surfaces should be cleaned with a soft, damp cloth and some neutral detergent. Fig. 7: Filter of the sandblasting cabin SSK 2.5 Keep the tool clean and dry. Dust filter specification 9.2 Maintenance and repair...
  • Page 12: Troubleshooting

    Step 2: If necessary, dismantle the devices into mana- geable and usable assemblies and compo- nents. Step 3: The device components and operating materi- als must be routed to the appropriate disposal routes. SSK 2.5 | Version 1.08...
  • Page 13: Spare Parts

    The filter for the suction device of the sandblasting cabin DANGER! must be ordered. Risk of injury through use - Type of device: Sandblasting cabin SSK 2.5 wrong spare parts! The use of incorrect or faulty replacement parts can - Item number: 6204003...
  • Page 14: Spare Parts Drawing

    In case of service, the following drawing shall help to identify the necessary spare parts. If necessary, send a copy of the parts drawing with the marked components to your authorised dealer. Fig. 8: Spare parts drawing SSK 2.5 SSK 2.5 | Version 1.08...
  • Page 15: Electrical Wiring Diagram

    Electrical wiring diagram 13 Electrical wiring diagram Fig. 9: Electric wiring diagram SSK 2.5 SSK 2.5 | Version 1.08...
  • Page 16: Ec Declaration Of Conformity

    <= 16 A per conductor,which are not subject to any special connection conditions. Person responsible for the documentation: Kilian Stürmer, Stürmer Maschinen GmbH, Dr.-Robert-Pfleger-Str. 26, D-96103 Hallstadt Hallstadt, 08.11.2017 ______________________ Kilian Stürmer Manager SSK 2.5 | Version 1.08...
  • Page 17: Attachment

    The gloves where manufactured and checked in accordance with the directive 89/686/EWG. Following standards where used: EN 388:2003 and EN 420:2003 + A1:2009. This leaflet has to be supplied with every protection glove listed in this brochure. The leaflet can therefore be copied without any restrictions. SSK 2.5 | Version 1.08...
