DEMO MANUAL DC2016A

performance summary

PARAMETER
Minimum Input Voltage, V
IN
Maximum Input Voltage, V
IN
Maximum Output Current, I
OUT
Input Turn-On Voltage, V
IN
Input Turn-Off Voltage, V
IN
Output Voltage, V
OUT
Efficiency
Switching Frequency
Output Current Limit
2
Specifications are at T = 25°C
A
CONDITIONS
12V < V < 35V, CTL = OPEN
IN
V = 6V, CTL = OPEN
IN
R10 = 332k, R11 = 121k, V Rising
IN
R10 = 332k, R11 = 121k, V Falling
IN
100mA < I < 3A (See Figure 2), R2 = 11k
OUT
1%, R3 = 100k 1%, R4 = 0.015Ω
V = 24V, I = 3A
IN OUT
R1 = 36.5k
R4 = 0.015Ω
MIN TYP MAX UNITS
6
35
3
1.8
5.5
4.5
11.7 12.5
92
600
3.6
dc2016af
V
V
A
A
V
V
V
%
kHz
A
