4.1.2 Keypad Functions for Display Mode

Measurements screens may be stepped through manually by pushing the up and down arrow
keys. Pushing the Toggle (Exit) key turns the scroll function off and on. When the scroll
function is activated, the measurement screens will automatically step through the user-
defined screens. Auto scroll state (ON/OFF) is stored in non-volatile memory. Pressing the
Home (Enter) key will bring up the home screen. The factory default home screen will be
Amps A, B, C for M350 A3. If a user enables or disables screens via the front display buttons
from Setup Mode -
enabled screen. The home screen can be setup as any one of the enabled screens by
simultaneously pressing the Home (Enter) and Toggle (Exit) buttons when on the desired
screen and can also be done through the web server Settings tab.
Table 1 – Button Functions
Button
Up Arrow
Down Arrow
Home (Enter)
Enter
Toggle (Exit)
EXIT
Combination Up and
Exit keys
Combination Up and
Down Keys
Combination Home
(Enter) and Toggle
(Exit) keys
Resets are found in setup menu.
ML0038
1.6
Scrn Ena, then the home screen will automatically become the 1
Display Mode Function
Next measurement/value
Previous
measurement/value
Scroll to designated home
screen
Toggle Auto Scroll On/Off
Enter Setup Mode
(Resets and configuration
setting are done in the
setup menu)
Resets Demand Values
Designate the displayed
screen as "Home Screen"
September 27, 2017
Setup Mode Function
Next menu item
Previous menu item
or
Y (Yes) when prompted
Enter selected submenu (or
configuration item), or
increments the highlighted
digit when entering number,
or IP address, or
N (No) when prompted
Exits current menu
selection and moves up to
next higher menu level.
Returns to display mode on
exit from main setup menu
