DISPLAY SCREENS
Format
A3
1. 00000 Phase A Amperes
00000 Phase B Amperes
00000 Phase C Amperes
Amps
2. 000.00 Phase A Amps Demand
000.00 Phase B Amps Demand
000.00 Phase C Amps Demand
Amps (LED to right of the middle line will light up the AVG legend)
3. 00000 Phase A Maximum Amperes Demand
00000 Phase B Maximum Amperes Demand
00000 Phase C Maximum Amperes Demand
Amps (LED to right of the top line will light up the MAX legend)
V3
1. 00000 Phase A Volts
00000 Phase B Volts
00000 Phase C Volts
X Volts
2. 00000 Phase A-B Volts
00000 Phase B-C Volts
00000 Phase C-A Volts
X Volts
3. 000.00 Phase A Average Voltage
000.00 Phase B Average Voltage
000.00 Phase C Average Voltage
X Volts (LED to right of the middle line will light up the AVG legend)
4. 00000 Phase A Maximum Average Volts
00000 Phase B Maximum Average Volts
00000 Phase C Maximum Average Volts
X Volts (LED to right of the top line will light up the MAX legend)
5. 00000 Phase A-B Maximum Average Volts
00000 Phase B-C Maximum Average Volts
00000 Phase C-A Maximum Average Volts
X Volts (LED to right of the top line will light up the MAX legend)
ML0038 September 27, 2017
Quantity
1
2
1
1
2
