You can also download the latest manual from official website. MIMAKI ENGINEERING CO., LTD. https://mimaki.com/ D203494-10 Original instructions...
TABLE OF CONTENTS Introduction .................. 3 For safe use.................. 5 About symbol mark ................ 5 Usage Precautions ................ 6 Ink or any Other Liquid Used with the Product ....... 9 Restrictions of the Product.............. 10 Installation Precautions.............. 11 Installation Space ................ 12 Relocating the Product ...............
Page 4
Use of this product in residential areas may cause harmful interference. If so, the user is responsible for rectifying such interference. • Use only the cables recommended by Mimaki Engineering when connecting to this product. Use of other cables may cause the product to exceed the restrictions stipulated by FCC regulations.
For safe use About symbol mark This document uses symbols to indicate operating precautions. To ensure safe and correct use of the machine, make sure you fully understand the meaning of each symbol. Details Warning Indicates a potentially hazardous situation in which disregarding the instructions may result in death or serious injury.
Usage Precautions l In the event of abnormal conditions • In the event of abnormal conditions such as smoke or unusual odor, turn off the main power immediately and unplug the power cable. Continuing to use the product under these conditions may result in failure, electric shock, or fire.
Page 7
• Connect the power cable plug to a grounded (earthed) polarity outlet. Disregarding this precaution may result in machine failure, electric shock, or fire. • When installing electrical outlets, perform grounding work to prevent electric shock. All electrical work must be done by a licensed electrician. •...
Page 8
l Precautions for ultraviolet (UV) light and the UV-LED unit • Do not place combustible materials underneath the UV-LED unit. Disregarding this precaution may result in fire or smoldering. • Do not cover the UV-LED unit with paper or cloth. Disregarding this precaution may result in fire or smoldering.
Some constituents are toxic to aquatic life. • Be sure to read the safety data sheet (SDS) before use. https://mimaki.com/supply/sds/ • Always wear safety glasses, gloves, and the mask provided when handling ink, maintenance cleaning solution, waste ink, or other solutions used in this machine. Failure to do so may result in ink or other liquids splashing and coming into contact with the skin, eyes, or mouth.
• Ink chips corresponding to different types will not function. • Ink bottles mounted in the product may become indented. This will not affect operation. Restrictions of the Product The ink expiration date is indicated on the Ink bottle. Expired ink may cause print defects or alter the color tone.
Installation Precautions • Do not install this machine in environments where flammable substances (e.g., gasoline, flammable spray, alcohol, thinner, lacquer, powder) are present. This machine is not explosion- proof. There is a risk of explosion. • Do not install this machine in locations where open flames are present. Disregarding this precaution may result in ink ignition.
Installation Space Provide the following space around the machine to allow safe and proper replacement of ink and media: Item UJV100-160 At least 3,775 mm Width (2,775 mm) At least 2,700 mm (700 mm) Depth *1, *2 (1,392 mm) Height...
Safety Interlocks This product is equipped with interlocks to ensure safety during use. Printing will abort if you open the covers while printing is underway. If so, you will need to resend the RIP data. • Safety interlock locations...
Warning Labels Make sure you fully understand the details indicated on the various warning labels. If any of the warning labels becomes dirty and illegible or peel off, contact your local dealer or our service office to request new warning labels. Around the carriage When the maintenance cover is open...
Page 15
Order code Label Details M910931 Beware of opening and closing parts. Injury may result if hands become trapped. M907833 Indicates dangerous moving parts. M903330 Wear safety glasses and gloves while working. M903405 Beware of the cutter. M907935 Indicates dangerous live parts. M905811 Indicates dangerous moving parts.
