www.sawo.com
info@sawo.com
Subject to change without notice.
STS45-1
STS60-1
STS45-3
STS60-3
Congratulations on your purchase of a SAWO Steam Generator.
Please read the manual carefully before using the steam generator.
STEAMBATH
GENERATOR
SYSTEMS
MANUAL
STS75-1
STS90-1
STS120-3
STS75-3
STS90-3
STS150-3HZZZ
Advertisement
Related Manuals for Sawo STS45-1
Summary of Contents for Sawo STS45-1
- Page 1 MANUAL STS45-1 STS60-1 STS75-1 STS90-1 STS120-3 STS45-3 STS60-3 STS75-3 STS90-3 STS150-3HZZZ Congratulations on your purchase of a SAWO Steam Generator. Please read the manual carefully before using the steam generator. STEAMBATH GENERATOR SYSTEMS www.sawo.com Subject to change without notice. info@sawo.com...
- Page 2 Steam Room to prevent slipping that may result to injury. The Steam Room floor and other surfaces could become slippery as a result of condensation and moisture. IMPORTANT! Read the manual provided for use and safety information. SAWO www.sawo.com SAWO, Inc. SAWO Building Mactan Export Processing Zone 2 Cebu, Philippines 6015...
- Page 3 Limit the Steam Room ceiling to a height of 2.5 meters. Exceeding 2.5m will require a higher-rated steam generator. SAWO strongly recommends for the “WARNING” (when to or not to use the Steam Room) to be posted in a conspicuous place near the Steam Room.
- Page 4 Use only water with mild soap SAWO controls can be located inside the steam room or on the outside of the steam room. and a non-abrasive sponge. IMPORTANT: Consult with supplier of acrylic, NOTE: SAWO Generators are CE compliant.
- Page 5 Water Inlet Power Wiring - See page 8 "Field Power Wiring" diagrams. Check power voltage. Use 220-240V to connect a single phase SAWO steambath generator. Use 380-430V to connect a 3 phase SAWO steambath generator. Steam Use minimum 90ºC / 600V rated insulated copper conductors only, sized in accordance with Outlet National Electrical Code and local electrical code for the Amps in Ampere Chart.
- Page 6 Field Power Wiring Wiring Diagrams L E G E N D Diagrams SINGLE PHASE STS45-1, STS60-1, FIELD Models STS45-1, STS-60-1, STS75-1 and STS90-1 WIRING STS75-1, STS90-1 FACTORY WIRING Earth Lug 220-240 Volts Earth SINGLE PHASE WIRING DIAGRAM TRANSFORMER GROUND L, N, Earth...
- Page 7 Draining immediately after a steam cycle may expose PVC and other piping to high temperature water. Check local requirements. The unit will refill automatically when the control is activated again. In areas of very hard water, a SAWO automatic drain system is recommended for generator longevity.
- Page 8 Use aroma oils with caution. Steam emission slot Place the drops into the SAWO steamhead recess prior to turning on the CAUTION steambath. Do not place drops in a hot steamhead as SERIOUS INJURY CAN RESULT IF YOU DO NOT FOLLOW THIS WARNING.
- Page 9 Installing the Remote Temperature Probe for SAWO Controls CAUTION The Remote Temperature Probe is for use with SAWO Control only. Do not use Earth any other controls. Do not use any other temperature probe with the SAWO control. Noncompatible products may result in an inoperative control and a hazardous condition.
- Page 10 Insure a minimum of 6mm of the temperature Determine the desired installation location of the control. bulb is exposed to the air. Failure to do so may result in an The SAWO control is designed to be installed inside or 25 mm 25 mm inoperative control and a hazardous condition.
- Page 11 Step 5 Remove & discard peel-off paper to expose adhesive liner as shown. Step 6 Display Run a bead of Keys silicone (provided) as shown to the C shaped groove as Wall On/Off Key shown. • ON/OFF Key is used to turn the steam generator on/off. IMPORTANT: •...
- Page 12 Preventive Maintenance Connection of SAWO Control and Temperature Connection of SAWO Control and Temperature Sensor to PCB. Sensor to PCB. Performing preventive maintenance on the Steam Generator Screw Blue Blue wire wire Screw Washer Heating element cover SAWO Control SAWO Control...
