  • Page 1 INSTRUCTION MANUAL PCM 5.0 THC3 PORSCHE / AUDI / VOLKSWAGEN HDMI INTERFACE 2021.05.17 DATA. WEBSITE https://kaptrader.com kap@kaptrader.com SHOP https://www.car4play.kr sales@car4play.kr...
  • Page 2 INSTRUCTION MANUAL CAR COMPATIBILITY SHEET BRAND MODEL SCREEN YEAR Cayenne 12" 2019~ Macan 12" 2019~ PORSCHE 12" 2019~ Panamera 12" 2018~ 10.1" / 8.8" 2020~ AUDI A4/A5 10.1" 2020~ VOLKSWAGEN Passat 9.2" 2019...

  • Page 3: Power Cable

    INSTRUCTION MANUAL COMPONENT INTERFACE POWER CABLE LVDS CABLE OPTION A/V CABLE RGB NAVI CABLE OSD BOARD ▶ Warning ▶ Warning Please contact your dealer if any component is missing. Please contact your dealer if any component is missing.  ...
  • Page 4 INSTRUCTION MANUAL INTERFACE SPEC INPUT • HDMI In X 1 • Analog RGB In (7pin) X 1 • CVBS Audio/Video In X 2 • CVBS Front Cam In X 1 • CVBS Rear Cam In X 1 • LVDS In Command System X 1 OUTPUT •...
  • Page 5 INSTRUCTION MANUAL EXTERNAL DEVICE SPECIFICATIONS LVDS OUT LVDS IN DIP SWITCH IMAGE PROGRAM  OSD connection  Interface error check POWER/CAN RESISTIVE TOUCH HDMI ALNALOG RGB  4PIN Touch AUDIO/VIDEO  REAR CAMERA IN  FRONT CAMERA IN  DVB-T or DVD IN ...

  • Page 6: Connector Pin Assignment

    INSTRUCTION MANUAL CONNECTOR PIN ASSIGNMENT PORT INFORMATION Color Signal Assignment Color Signal Assignment POWER Brown REAR DET Blue FRONT DET /CAN White CAN LOW Purple CAN HIGH Blue CAN LOW CAN HIGH Green CAN LOW Orange CAN HIGH REAR VCC FRONT VCC Black Color...

  • Page 7: Dip Switch Setting

    INSTRUCTION MANUAL DIP SWITCH SETTING INFORMATION FUNCTION ▲ OFF ▼ ON NAVIGATION Do not use AV1 (DVB-T) Do not use AV2 (DVD) Do not use HDMI Do not use PORSCHE (2019~) Cayenne / 911 - 12" PORSCHE (2019~) Macan - 12" AUDI (2020~) A1 –...

  • Page 8: Button Control

    INSTRUCTION MANUAL BUTTON CONTROL CHANGE MODE TO INTERFACE SCREEN HOME or NAV BUTTON OPERATION FUNCTION OEM screen to interface screen HOME or NAV LONG PRESS Interface screen to the OEM screen Other Buttons PRESS Return OEM Dispaly ▶ Warning You can choose "HOME" or "NAV" button on OSD menu ...
  • Page 9 INSTRUCTION MANUAL BUTTON CONTROL CHANGE MODE TO INTERFACE SCREEN BUTTON OPERATION FUNCTION OEM screen to interface screen LONG PRESS Interface screen to the OEM screen Option PRESS Changing the screen ratio in AV1 and AV2 modes ▶ Warning To use a Return button, You need to enable the NAV in the button selection in the OSD ...
  • Page 10 INSTRUCTION MANUAL BUTTON CONTROL CHANGE MODE TO INTERFACE SCREEN RETURN BUTTON OPERATION FUNCTION OEM screen to interface screen RETURN LONG PRESS Interface screen to the OEM screen ▶ Warning To use a Return button, You need to enable the RET in the button selection in the OSD ...
  • Page 11 INSTRUCTION MANUAL BUTTON CONTROL CHANGE MODE TO INTERFACE SCREEN RETURN BUTTON OPERATION FUNCTION OEM screen to interface screen RETURN LONG PRESS Interface screen to the OEM screen ▶ Warning To use a Return button, You need to enable the RET in the button selection in the OSD ...
  • Page 12 INSTRUCTION MANUAL BUTTON CONTROL CHANGE MODE TO INTERFACE SCREEN MENU SCROLL BUTTON OPERATION FUNCTION OEM screen to interface screen MENU SCROLL LONG PRESS Interface screen to the OEM screen ▶ Warning To use a Return button, You need to enable the RET in the button selection in the OSD ...
  • Page 13 INSTRUCTION MANUAL PARKING CONTROL FrontCam Rcv Option FrontCam-RcvOpt : ON (1 - 30s) MENU Option NAVI Config FronrCam-RcvOpt Displays the front camera screen for the set time Option (1 - 30second) Image Screen Parking REAR FRONT OEM or OEM or Camera Camera Interface...
  • Page 14 INSTRUCTION MANUAL INSTALL MANUAL DVB-T / DVD REMOTE CONTROL CONNECTION DIP switch No.2, 3 is OFF PROGRAM IMAGE DIP_S/W LVDS-IN LVDS-OUT PCM5.0-THC3 VIDEO INTERFACE POWER/CAN TOUCH HDMI NAVI DVB-T 6PIN 7PIN DVB-T DVD DVB-T-IR DVD-IR DVB-T (DMB)
  • Page 15 INSTRUCTION MANUAL INSTALL MANUAL EXTERNAL REAR CAMERA PROGRAM IMAGE DIP_S/W LVDS-IN LVDS-OUT PCM5.0-THC3 VIDEO INTERFACE POWER/CAN TOUCH HDMI NAVI 12. REAR VCC 3. REAR CAMERA DETECT...
  • Page 16 INSTRUCTION MANUAL INSTALL MANUAL EXTERNAL FRONT CAMERA PROGRAM IMAGE DIP_S/W LVDS-IN LVDS-OUT PCM5.0-THC3 VIDEO INTERFACE POWER/CAN TOUCH HDMI NAVI 13. FRONT VCC 4. FRONT CAMERA DETECT...
  • Page 17 INSTRUCTION MANUAL INSTALL MANUAL INSTALLATION LVDS CONNECTION PROGRAM IMAGE DIP_S/W LVDS-IN LVDS-OUT PCM5.0-THC3 VIDEO INTERFACE POWER/CAN TOUCH HDMI NAVI Screen HeadUnit (Commander)
  • Page 18 INSTRUCTION MANUAL INSTALL MANUAL Choose one of two methods INSTALLATION LVDS CONNECTION – PANAMERA / A1,Q3 / PASSAT OEM Headunit Ours LVDS LVDS Common connection method Method 1 Cut the pin of the LVDS cable, turn it over and connect it Method 2 Cut and connect the connector of INTERFACE...
  • Page 19 INSTRUCTION MANUAL INSTALL MANUAL INSTALLATION CAN CONNECTION Remove the original Check the gray area gray connector. Be careful of the Be careful of the protruding part, protruding part, connect the connect the connector connector...

  • Page 20: Osd Control

    INSTRUCTION MANUAL OSD CONTROL Basic information MENU Option NAVI Config RearCam-Type ExtDevice Option RearCam-Power Auto Image RearCam-Det GEAR Screen AV Mode Parking FrontCam-Type ExtDevide OSD(On Screen Display) Menu MENU Mode State Interface Status First Menu Second Menu Third Menu OSD(On Screen Display) Board Control •...
  • Page 21 INSTRUCTION MANUAL OSD CONTROL Config First Menu Second Menu Third Menu Description DIGITAL Config NAVI-RGB ： Setting the Connected NAVI Model ： Default DVB-T(DMB) Setting the Connected DVB-T Model ： ： Default Setting the Connected DVD Model ： ： Default RearCam Setting the Connected RearCam Model ：...
  • Page 22 INSTRUCTION MANUAL OSD CONTROL Option First Menu Second Menu Third Menu Description Option FINE Set up manufacturer of woodworking device for UART Touch use NAVI COM Disable feature Original Camera RearCam-Type ExtDevice Equipped with external camera + 12V continuous supply RearCam-Power AUTO + 12V supply only in Rear camera mode...
  • Page 23 INSTRUCTION MANUAL OSD CONTROL Option First Menu Second Menu Third Menu Description Original Camera Option FrontCam-Type ExtDevice Equipped with external camera + 12V continuous supply FrontCam-Power Auto + 12V supply only in Rear camera mode Disable feature FrontCam-Det ExtDevice Detected by Front-Det Wire The time (1-30 seconds) that FrontCam is displayed before returning to the FrontCam- previous state in RearCam...
  • Page 24 INSTRUCTION MANUAL OSD CONTROL Option First Menu Second Menu Third Menu Description Original Camera SteeringWheel Option Disable feature HOME Set the mode change button to HOME NAVI Set the mode change button to NAVI Mode Button Set the mode change button to RETURN Disable feature Short Short press the NAV button to switch screens...

  • Page 25: Image Brightness

    INSTRUCTION MANUAL OSD CONTROL Image First Menu Second Menu Third Menu Description Brightness Adjust the value of brightness Image Contrast Adjust the value of contrast [AV / REAR / FRONT / DVD / DVBT MENU] Saturation Adjust the value of Saturation [AV / REAR / FRONT / DVD / DVBT MENU] Adjust the value of Hue [AV / REAR / FRONT / DVD / DVBT MENU]...
  • Page 26 INSTRUCTION MANUAL OSD CONTROL Screen First Menu Second Menu Third Menu Description Horizontal Output screen horizontal movement Screen Vertical Output screen vertical movement Scale X Up Reduce / increase output screen width Scale X Down Scale Y Up Reduce / Increase Output Screen Height Scale Y Down Reset Screen menu all reset...
  • Page 27 INSTRUCTION MANUAL OSD CONTROL Parking First Menu Second Menu Third Menu Description Show OPS Parking OPS Display Do not show OPS Show parking line Line Display Do not show parking lines Warnings Lang Set warning text language Horizontal Moving a parking line horizontally Vertical Moving a parking line vertically Transparency...
  • Page 28 INSTRUCTION MANUAL OSD CONTROL First Menu Second Menu Third Menu Description Horizontal value OSD Menu Horizontal Shift Vertical value OSD menu vertical Shift Display Time value OSD Menu Display Time (in seconds) Transparency value OSD menu transparency Language OSD menu display language Reset Execute Initialize OSD settings...
  • Page 29 INSTRUCTION MANUAL OSD CONTROL IR-Ctrl First Menu Second Menu Third Menu Description IR-Ctrl DVB-T(DMB) Learn Cancel Learn Cancel Notice In order to work with the IR learning function, a separate IR cable is required. 1. In DVB-T / DVD menu, select User in Sys (OSD list) or User (learned contents). 2.
  • Page 30 INSTRUCTION MANUAL OSD CONTROL PROGRAM OSD CABLE 9 10 10 - IR 7 - OSD(RED) 6 - OSD(BLACK) / GND 5 - 5V Example Image IR Cable OSD Cable IR Cable Create an IR cable - Modify the OSD cable as shown above. 1.
  • Page 31 INSTRUCTION MANUAL OSD CONTROL Utility First Menu Second Menu Third Menu Description Factory Reset Execute Initialize all settings Utility P5D300KRX-200534 Version (Check for future upgrades) Hardware Special Software Software Software Motor Model PIP Model National Version Version Year Month Version FD=FORD S3=Sync3 CN=CHINA...

  • Page 32: Question And Answer

    INSTRUCTION MANUAL Question and Answer If there is a problem with the interface • First, check the LED - Green LED blinking: No problem - Red LED: Bad interface - No LED: Check power and CAN connection If the screen is black •...
