- Page 1 INSTRUCTION MANUAL VIDEO INTERFACE JEEP 2014 DIGITAL RGB JEEP INTERFACE DATA. 2020.05.08 CONTACT W kaptrader.com E kap@kaptrader.com A (05854) A-912 RM Tera-tower2, 201 Songpa-Dearo, Songpa-gu, Seoul, Korea F (+82) 6204 - 0913...
- Page 2 INSTRUCTION MANUAL CAR COMPATIBILITY SHEET BRAND MODEL YEAR Cherokee 2014~2017 JEEP Grand Cherokee 2014~2017 CHRYSLER 300C 2016~2017 DODGE 2014~2017...
- Page 3 INSTRUCTION MANUAL COMPONENT BOARD SUB BOARD POWER CABLE FPC CABLE RGB NAVI CABLE LVDS CABLE OSD BOARD ▶ Warning ▶ Warning Please contact your dealer if any component is missing. Please contact your dealer if any component is missing. ...
- Page 4 INSTRUCTION MANUAL INTERFACE SPEC INPUT • 1 x DIGITAL RGB IN (HDMI PORT) • 1 x ANALOG RGB IN (7PIN) • 1 x CVBS FRONT CAM IN • 1 x CVBS REAR CAM IN • 1 x LVDS IN CAMMAND SYSTEM OUTPUT •...
- Page 5 INSTRUCTION MANUAL EXTERNAL DEVICE SPECIFICATIONS LCD OUT PROGRAM DIP SWICH IMAGE OSD connection POWER/CAN DIGITAL RGB ALNALOG RGB FRONT FRONT CAMERA IN REAR RESISTIVE TOUCH REAR CAMERA IN 4PIN Touch...
-
Page 6: Dip Switch Setting
INSTRUCTION MANUAL DIP SWITCH SETTING INFORMATION FUNCTION ▲ OFF ▼ ON NAVIGATION Do not use No function JEEP - Grand Cherokee (WK) (2016) CHRYSLER - 300C JEEP - Cherokee (KL) Car Type DODGE - RAM (2014) DODGE - RAM (2015) -
Page 7: Connector Pin Assignment
INSTRUCTION MANUAL CONNECTOR PIN ASSIGNMENT PORT INFORMATION Color Signal Assignment Color Signal Assignment Yellow BATTERY Yellow BATTERY POWER Green CAN LOW Orange CAN HIGH /CAN Blue CAN LOW CAN HIGH REAR VCC FRONT VCC Black Black Color Signal Assignment R DATA Green G DATA NAVI... -
Page 8: Button Control
INSTRUCTION MANUAL BUTTON CONTROL Change Mode to Interface Screen RIGHT SWITCH BUTTON PRESS FUNCTION OEM screen to interface screen Long press STEERING WHEEL Interface screen to the OEM screen RIGHT SWITCH ▶ Screen change sequence : OEM > NAVI > OEM ▶... - Page 9 INSTRUCTION MANUAL BUTTON CONTROL Change Mode to Interface Screen BACK BUTTON PRESS FUNCTION OEM screen to interface screen Short press Interface screen to the OEM screen BACK ▶ Screen change sequence : OEM > NAVI > OEM ▶ Warning To use the back button, “Back Button" must be "ON" in the OSD menu ...
- Page 10 INSTRUCTION MANUAL BUTTON CONTROL FrontCam Manual Mode BUTTON PRESS FUNCTION On the OEM screen or NAVI screen, the FRONT CAM screen is Short press displayed for 15 seconds OEM or FRONT OEM or INTERFACE CAMERA INTERFACE SCREEN SCREEN SCREEN 15sec ▶...
- Page 11 INSTRUCTION MANUAL PARKING CONTROL FrontCam Rcv Option FrontCam-RcvOpt : ON (1 - 30s) MENU Option NAVI Config FronrCam-RcvOpt Displays the front camera screen for the set time Option (1 - 30second) Image Screen Parking OEM or REAR FRONT OEM or INTERFACE CAMERA CAMERA...
- Page 12 INSTRUCTION MANUAL INSTALL MANUAL RGB NAVI Connection DIP switch No.1 is OFF IMAGE DIP_S/W PROGRAM LCD-OUT CJ2014 - D VIDEO INTERFACE POWER/CAN NAVI FRONT REAR TOUCH DIGITAL Analog Resistive Touch NAVIGATION...
- Page 13 INSTRUCTION MANUAL INSTALL MANUAL EXTERNAL REAR CAMERA IMAGE DIP_S/W PROGRAM LCD-OUT CJ2014 - D VIDEO INTERFACE POWER/CAN NAVI FRONT REAR TOUCH DIGITAL REAR POWER REAR CAMERA DETECT +12v...
- Page 14 INSTRUCTION MANUAL INSTALL MANUAL EXTERNAL FRONT CAMERA IMAGE DIP_S/W PROGRAM LCD-OUT CJ2014 - D VIDEO INTERFACE POWER/CAN NAVI FRONT REAR TOUCH DIGITAL FRONT POWER FRONT CAMERA DETECT...
- Page 15 INSTRUCTION MANUAL INSTALL MANUAL CONNECTION Removing Front Cover 7mm bolt removal Bolt removal Bolt removal Removing the Back Cover OEM BOARD Removal...
- Page 16 INSTRUCTION MANUAL INSTALL MANUAL CONNECTION OEM FPC CABLE Removal Removing the Back Cover Install the supplied FPC CABLE OEM FPC CABLE Installation Assembly Fix the SUB BOARD to the body...
- Page 17 INSTRUCTION MANUAL INSTALL MANUAL CONNECTION FPC Cable LVDS Cable Connecting FPC Cable and LVDS Cable to SUB BOARD...
-
Page 18: Osd Control
INSTRUCTION MANUAL OSD CONTROL Basic information MENU Option NAVI Config RearCam-Type ExtDevice Option RearCam-Power Auto Image RearCam-Det GEAR Screen AV Mode Parking FrontCam-Type ExtDevide OSD(On Screen Display) Menu MENU Mode State Interface Status First Menu Second Menu Third Menu OSD(On Screen Display) Board Control •... -
Page 19: Config Menu
INSTRUCTION MANUAL OSD CONTROL Config Menu First Menu Second Menu Third Menu Description DIGITAL Config NAVI-RGB ： Setting the Connected NAVI Model ： Execute Reset Reset to default value of Config menu Cancel... -
Page 20: Option Menu
INSTRUCTION MANUAL OSD CONTROL Option Menu First Menu Second Menu Third Menu Description Original Camera Option RearCam-Type ExtDevice Equipped with external camera + 12V continuous supply RearCam-Power AUTO + 12V supply only in Rear camera mode + 12V off GEAR Detected by CAN RearCam-Det WIRE... -
Page 21: Image Menu
INSTRUCTION MANUAL OSD CONTROL Image Menu First Menu Second Menu Third Menu Description Brightness Adjust the value of brightness Image Contrast Adjust the value of contrast [AV / REAR / FRONT / DVD / DVBT MENU] Saturation Adjust the value of Saturation [AV / REAR / FRONT / DVD / DVBT MENU] Adjust the value of Hue [AV / REAR / FRONT / DVD / DVBT MENU]... -
Page 22: Screen Menu
INSTRUCTION MANUAL OSD CONTROL Screen Menu First Menu Second Menu Third Menu Description Horizontal Output screen horizontal movement Screen Vertical Output screen vertical movement Scale X Up Reduce / increase output screen width Scale X Down Scale Y Up Reduce / Increase Output Screen Height Scale Y Down Reset Screen menu all reset... - Page 23 INSTRUCTION MANUAL OSD CONTROL Parking Menu First Menu Second Menu Third Menu Description Show parking line (Not moving) Parking Line Display Do not show parking lines Please do not use it OPS Display Do not show OPS Warnings Lang Set warning text language Horizontal Moving a parking line horizontally Vertical...
- Page 24 INSTRUCTION MANUAL OSD CONTROL OSD Menu First Menu Second Menu Third Menu Description Horizontal value OSD Menu Horizontal Shift value Vertical OSD menu vertical Shift value Display Time OSD Menu Display Time (in seconds) value Transparency OSD menu transparency Language OSD menu display language Reset Execute...
-
Page 25: Utility Menu
INSTRUCTION MANUAL OSD CONTROL Utility Menu First Menu Second Menu Third Menu Description Factory Reset Execute Initialize all settings Utility FDSYOOKRX-180209 Version (Check for future upgrades) Hardware Special Software Software Software Motor Model PIP Model National Version Version Year Month Version FD=FORD S3=Sync3... - Page 26 A-912 Rm Tera-tower2, 201 Songpa-daero, Songpa-gu, Seoul, Korea F. (+82) 6204-0913 E. kap@kaptrader.com...
