- Page 1 360 Fusion Calibration Guide © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2...
- Page 2 — THIS PAGE LEFT INTENTIONALLY BLANK — © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2...
-
Page 3: Table Of Contents
Setting pixel pitch for NT or ST Mode..18 Setting pixel pitch for ST(FFT) Mode..18 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... -
Page 4: Introduction
Before taking on the calibration process, all components should already be installed in the vehicle. For more information on how to install the components, please see the inView 360 Fusion Installation Guide on the Seon Community (https://community.seon.com/360-fusion/360-fusion-resources/). For access to the community website, please contact the Seon Service Team to get a username and password (email service@seon.com, or call toll-free... - Page 5 Reposition calibration 360° image good? (no pads or cameras and distortion, can clearly see repeat process calibration pads in image) Calibration is complete p. 5 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2...
-
Page 6: Preparation
Cut & Paste files from one directory to another Processor: Intel or AMD x86 Extract files from a zip folder Disk Space: 3.5 GB free RAM: 1024MB (2048 MB recommended) p. 6 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... -
Page 7: Physical Environment
The folder will contain several sub folders and files. Ensure that your folders look like the ones in this example: p. 7 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... -
Page 8: Placing Calibration Pads
Use a square ruler to ensure that measuring tape perpendicular with tapes & . The following values will help you determine where to place your calibration pads. p. 8 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... - Page 9 5. Place the calibration pads a distance of “H” in front and to the left or right of the vehicle. This is your Horizontal distance p. 9 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2...
-
Page 10: About Horizontal And Vertical Values
Image A would need to be re-calibrated. In image B, you see that the image has no distortion and the pads can be made out clearly in the image. p. 10 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... -
Page 11: Setting The System For Calibration
1. Insert the SD card (with USB adapter, if required) into the PC. 2. Navigate to the SD card location. Cut the following 4 files: • FRONT.bin • RIGHT.bin • LEFT.bin • REAR.bin p. 11 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... -
Page 12: Launching The Calibration Tool
To launch the calibration tool, double-click the application icon (AVM_calibration.exe) located in the calibration tool root folder. The application displays the Vehicle Selection screen. p. 12 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... -
Page 13: Selecting Vehicle And Entering Pattern Info
3. In the Pattern Location area, choose your unit of measure (in or mm) 4. Enter the dimensions of your calibration pads. 5. Enter the measurements used for your vertical and horizontal pad placement p. 13 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... -
Page 14: Understanding Pixel Pitch
Think of pixel pitch as the vehicle’s “zoom level” when looking at the vehicle from above. A higher pixel pitch means you can see more of the area around a vehicle. A lower pixel pitch means you see less. p. 14 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... - Page 15 As mentioned, a low pixel pitch value shows less area around the vehicle. A higher value shows more. p. 15 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2...
-
Page 16: About View Modes
Notice also that there is a View Mode selector. In the selector you have the option of choosing NT, ST or ST(FFT) view modes. But what is view mode and how does it affect the calibration procedure? p. 16 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... - Page 17 When you launch the calibration tool, the view mode will be set to NT, which is the default. To switch view modes, click the drop-down menu and select the mode you want to calibrate for. p. 17 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2...
-
Page 18: Setting Pixel Pitch For Nt Or St Mode
2. In the FFT Pixel Pitch field, enter a value between the min and max range, as calculated by the application. 3. Click Confirm. A preview of the pixel pitch will appear in the window below. p. 18 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... -
Page 19: Performing Avm Calibration
OUTPUT folder, and click Select Folder. The front camera image will display on the screen. Notice that the FRONT.bin image is selected. p. 19 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... - Page 20 7. Click Get CtrlPoint to save your marking. You’ll be taken to the next image (REAR.bin), and a check mark will appear indicating that front image was marked. p. 20 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2...
-
Page 21: Viewing Changes In Pixel Pitch
3. Click Calibration & Save. Your 360° image should change to reflect the increase/decrease in pixel pitch. 4. Change your View Mode to view ST or ST(FFT) modes. p. 21 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... -
Page 22: Tuning Cameras
Once calibration is complete, the tuned images will appear on the in-cab monitor in both NT and ST modes. The driver can switch between each individual camera view by using the AVM push button installed on the dash. p. 22 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... -
Page 23: Adjusting Parking Lines And Saving
Right moves both lines to the right • Right Side moves the right line outwards (towards the right) 4. Click Save when done. p. 23 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... - Page 24 If no files appear on the card, attempt to save again or contact Seon for help. 9. Remove SD card and transfer it back to the ECU in the vehicle. p. 24 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2...
-
Page 25: Verifying Calibration
4. Select Manual Calibration then click OK (). The ECU will begin to load the files from the SD card. 5. Wait until the calibration process is complete. When you see the following screen, then the process is complete. p. 25 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... -
Page 26: Calibration Image Test
Either adjust the camera positions, or move the pads, then repeat the calibration procedure. If this does not solve your problem, please contact Seon Support for assistance. p. 26 © Safe Fleet | May 2018 | All rights reserved | Part #: 700-1111 R2... -
Page 27: Support Information
Please show the RMA number on the outside of the package. ANY RETURNED PRODUCT WITHOUT AN RMA NUMBER MAY BE REFUSED. Product Information For product information and documentation related to the 360 Fusion system, please visit the Safe Fleet Community’s 360 Fusion product page: •...
