ADJUSTABLE FEATURES
TRANSISTOR PUMP CONTROLS
This function allows for the adjustment of the speed limit
(maximum battery volts to the motor) when the SL2 limit
switch input signal is received by the control card. SL2
limit switch is a normally open switch connected to battery
negative, the switch closing enables speed limit.
Range 0% to 100% battery volts
Setting 0 to 255
Resolution 0.375 volts per set unit
Example: Setting of 50=18.75 volts
FUNCTION 50 MODE 1 – TILT SPEED LIMIT (SL3)
(Push CONT 3)
This function allows for the adjustment of the speed limit
(maximum battery volts to the motor) when the SL3 limit
switch input signal is received by the control card. SL3
limit switch is a normally open switch connected to battery
negative, the switch closing enables speed limit.
Range 0% to 100% battery volts
Setting 0 to 255
Resolution 0.375 volts per set unit
Example: Setting of 50=18.75 volts
FUNCTION 51 MODE 1 – LIFT 2 SPEED LIMIT (SL4)
(Push CONT 2)
This function allows for the adjustment of the speed limit
(maximum battery volts to the motor) when the SL4 limit
switch input signal is received by the control card. SL4
limit switch is a normally open switch connected to battery
negative, the switch closing enables speed limit.
Range 0% to 100% battery volts
Setting 0 to 255
Resolution 0.375 volts per set unit
Example: Setting of 50=18.75 volts
FUNCTION 52: MODE 2 - CONTROLLED ACCELERATION
(Push CONT 5)
Same as function 48.
FUNCTION 53: MODE 2 - – LIFT 1 SPEED LIMIT (SL2)
(Push CONT 6)
Same as Function 49.
FUNCTION 54 MODE 2 – TILT SPEED LIMIT (SL3)
(Push CONT 7)
Same as Function 50.
FUNCTION 55 MODE 2 – LIFT 2 SPEED LIMIT (SL4)
(Push CONT 8)
Same as Function 51.
FUNCTION 56 MODE 3 - CONTROLLED ACCELERATION
(Push CONT 9)
Same as function 48.
FUNCTION 57 MODE 3 – LIFT 1 SPEED LIMIT (SL2)
(Push CONT 10)
Same as Function 49.
FUNCTION 58 MODE 3 – TILT SPEED LIMIT (SL3)
(Push CONT 11)
Same as Function 50.
FUNCTION 59 MODE 3 – LIFT 2 SPEED LIMIT (SL4)
(Push CONT 12)
Same as Function 51.
FUNCTION 60 MODE 4 - CONTROLLED ACCELERATION
(Push CONT 13)
Same as function 48.
FUNCTION 61 MODE 4 – LIFT 1SPEED LIMIT (SL2)
(Push CONT 14)
Same as Function 49.
FUNCTION 62 MODE 4 – TILT SPEED LIMIT 3 (SL3)
(Push CONT 15)
Same as Function 50.
FUNCTION 63 MODE 4 – LIFT 2 SPEED LIMIT (SL4)
(Push CONT 16)
Same as Function 51.
