CAUTION!
Driving with a hot engine cooling system
could damage your vehicle.
temperature gauge reads "H" pull over and
stop the vehicle. Idle the vehicle with the air
conditioner turned off until the pointer
drops back into the normal range. If the
pointer remains on the "H", turn the engine
off immediately and call an authorized
dealer for service.

3. Instrument Cluster Display

• The instrument cluster display features
a driver interactive display Ú page 69.
4. Fuel Gauge
• The digital bar gauge shows the amount
of fuel in the tank.
• The fuel reserve/limited range
warning light turns on, a message is
displayed and there is an acoustic
signal when about 2.4 gallons (9 liters)
of fuel are left in the tank.
• The fuel pump symbol points to the
side of the vehicle where the fuel door is
located.
• Proceeding further, the second white
notch will go off and the last one will
become red, together with the indica-
tion "E" present at the bottom of the
tank.
If the
Fuel Level Gauge
NOTE:
If the low fuel warning light switches on, refuel
at the earliest opportunity.
5. Speedometer
• Indicates vehicle speed.
www.inhauto.com
NOTE:
The hard telltales will illuminate for a bulb
check when the ignition is first cycled.
INSTRUMENT CLUSTER
DISPLAY

Instrument Cluster Display Description

This vehicle is equipped with a driver interac-
tive display that is located in the instrument
cluster.
When one or more of the doors have been
opened or closed and the ignition is in the OFF
position, the instrument cluster will display the
vehicle mileage for a few seconds.

Reconfigurable Instrument Cluster Display

During operation, the instrument cluster
display is divided into multiple sections which
show driving data, warnings, and failure indi-
cations.
Instrument Cluster Display

Reconfigurable Display Items

1. External Lights (Low Beam/High Beam)
Display
2. Front, Side Anti-Collision Systems,
Cruise Control Change Information
3. Speed Limiter Display
4. Driving Assistance Systems (FCW, LDW,
HAS) Information Display
5. Active Cruise Control (ACC) /
Cruise Control (CC) Information Display
6. Traffic Sign Recognition (TSR) /
Speed Limiter Information Display
