QUICK GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stelvio and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alfa Romeo Stelvio

Summary of Contents for Alfa Romeo Stelvio

  • Page 1 QUICK GUIDE...

  • Page 3: Table Of Contents

    CONTENTS KEYS ..........................2 DOORS..........................4 SEATS..........................8 ELECTRIC SEATS AND REAR VIEW MIRRORS .........10 STARTING ........................12 LIGHTS ...........................14 CONTROLS ON TUNNEL ..................16 CLIMATE CONTROL SYSTEM ................18 STEERING WHEEL ....................20 AUTOMATIC TRANSMISSION ................26 ALFA DNA™ SELECTOR ..................28 CONNECT SYSTEM CONTROLS ..............30 STEERING WHEEL CONNECT CONTROLS ..........34 CONNECT SYSTEM ....................36 PARK SENSORS SYSTEM ..................47 REFUELLING .......................48...

  • Page 4: Keys

    KEYS...
  • Page 5 KEYS 1. CLOSING: Locks the car doors 3. OPENING: Unlocks the car doors 2. TAILGATE: Opening/closing the tailgate...

  • Page 6: Doors

    DOORS...
  • Page 7 DOORS 1. OPENING: Grab the handle and pull it in Systems the indicated direction The electronic key is provided with Keyless Start system and may be provided, on demand, with Passive Entry system. In both cases, the car can detect the presence of the key in the proximity and enable starting the engine and opening the locks without needing any actual interaction.
  • Page 8 DOORS...
  • Page 9 DOORS Closing the tailgate from outside 4. Button: Press to close the tailgate You can close the tailgate by pressing one of the two buttons on its interior trim. WARNING You can stop the tailgate movement by operating any of the closing buttons. 5.

  • Page 10: Seats

    SEATS...
  • Page 11 SEATS MANUAL ADJUSTMENT 3. Seat longitudinal 1. Backrest angle adjustment adjustment 2. Seat height adjustment ELECTRIC ADJUSTMENT 1. Backrest width adjustment 4. Backrest angle adjustment 2. Lumbar adjustment 3. Longitudinal, height and inclination adjustment of the seat...

  • Page 12: Electric Seats And Rear View Mirrors

    ELECTRIC SEATS AND REAR VIEW MIRRORS...
  • Page 13 ELECTRIC SEATS AND REAR VIEW MIRRORS MIRROR ADJUSTMENT Select the mirror (right/left) by rotating control 1, then regulate the position of the mirror using the 2. Seat position store buttons same control. MIRROR FOLDING With the device in position "0" move it backwards. 1.

  • Page 14: Starting

    STARTING...
  • Page 15 • if the engine doesn't start within a few seconds, you need to repeat the procedure. you need to repeat the procedure. If the problem persists, contact an Alfa Romeo If the problem persists, contact an Alfa Romeo Dealership. Dealership.

  • Page 16: Lights

    LIGHTS...
  • Page 17 LIGHTS 5. Light switch Switch positions: – side lights and dipped headlights on – automatic light operation 1. Ring for adjusting the headlight alignment (where provided) – parking lights on 2. Ring for adjusting the brightness of 4. Fog lights button the instrument panel and the lights (where provided) on the controls...

  • Page 18: Controls On Tunnel

    CONTROLS ON TUNNEL...
  • Page 19 CONTROLS ON TUNNEL 8. Connect system display 7. Hazard warning lights button 6. Automatic climate control system dashboard 5. Shift lever ON/OFF control and Volume 4. Alfa DNA™ selector 3. EPB: electric park brake 2. Rotary Pad Parking brake EPB Releasing the electric parking brake manually In order to manually release the parking brake, the ignition device should be in the ON position.

  • Page 20: Climate Control System

    CLIMATE CONTROL SYSTEM...
  • Page 21 CLIMATE CONTROL SYSTEM 1. Rear window heating 15. MAXDEF function 2. Air distribution at passenger side 14. Air distribution at driver side 3. Temperature adjustment knob 13. Temperature adjustment knob 4. AUTO function 12. AUTO function 5. SYNC function 11. Internal air recirculation 6.

  • Page 22: Steering Wheel

    STEERING WHEEL...
  • Page 23 STEERING WHEEL Adjusting the steering wheel: – Lower the adjustment lever – Adjust the steering wheel to the indicated directions – Put the lever back in the lock position. Steering lock (where provided): The steering lock engages automatically upon opening the driver door if the ignition device is in the STOP position.
  • Page 24 STEERING WHEEL...
  • Page 25 STEERING WHEEL 1. ACC (distance setting button) 2. Cruise Control / Active Cruise Control (ACC) 3. Resume Cruise Control 4. Setting the Cruise Control Speed: use the ring to change the speed 5. HDC: Hill Descent Control...
  • Page 26 STEERING WHEEL 1. Direction indicators: – Press the lever up or down to activate the direction indicators – “Lane Change” function: press the lever up or down until the fi rst click (about half stroke). 2. Fixed main beams: press the lever in the direction of the arrow 3.
  • Page 27 STEERING WHEEL 5. MIST function Wiper engagement: press the lever upwards to activate the temporary wiper action. 6. Rearscreen washer: push the lever forward 7. Display screens navigation on instrument panel: press the indicated button to scroll through the screens on the instrument panel display.

  • Page 28: Automatic Transmission

    AUTOMATIC TRANSMISSION...
  • Page 29 AUTOMATIC TRANSMISSION The transmission is operated by means of the control lever which can be used to select the following operating modes: 2. P (Park) button • P = Parking mode (activated by pushing the P (Parking) 2 button); • R = Reverse (to engage, press the brake pedal and press the lever movement button 1);...

  • Page 30: Alfa Dna™ Selector

    ALFA DNA™ SELECTOR...
  • Page 31 ALFA DNA™ SELECTOR This device allows, using the selector (on the central tunnel), different car response modes to be selected according to driving style and road conditions: • d: Dynamic (sports driving mode); • n: Normal (driving mode for normal conditions); •...

  • Page 32: Connect System Controls

    CONNECT SYSTEM CONTROLS...
  • Page 33 CONNECT SYSTEM CONTROLS ON/OFF control and Volume LONG PRESS: switches the Connect system on and off; ROTATION: clockwise to increase the volume, counter-clockwise to decrease the volume. In Radio mode SHORT PRESS: activates/deactivates the Mute function; MOVING THE KNOB: to the right, selects the next radio station, to the left, selects the previous radio station.
  • Page 34 CONNECT SYSTEM CONTROLS...
  • Page 35 CONNECT SYSTEM CONTROLS Rotary Pad AUX input Inside the glove compartment in the central tunnel. Within the Menus MENU button – ROTATION: scrolls the menu items; – PRESSING: confi rms the selection. Opens the main menu. – BRIEF MOVEMENT TO THE RIGHT: accesses to Option button the submenu of the selected function.

  • Page 36: Steering Wheel Connect Controls

    STEERING WHEEL CONNECT CONTROLS...
  • Page 37 STEERING WHEEL CONNECT CONTROLS There is a series of controls on the steering wheel which may be used to activate some of the system's main functions. key: In Radio mode: SHORT PRESS: selects the next radio station; LONG PRESS: scans higher frequencies until released. In Media mode: SHORT PRESS: selects the next track;...

  • Page 38: Connect System

    CONNECT SYSTEM MAIN MENU RADIO Press the menu key to access the main menu. Store a Radio station To activate Radio mode, proceed as follows: press The modes displayed are: the MENU button to activate the main menu, turn To store the current radio station on one of the –...
  • Page 39 CONNECT SYSTEM MEDIA (USB AND AUX INPUTS) To access the function, from the main menu select The following menu items can be found here: After having inserted a USB/iPod device while the the following functions in sequence by turning and system is on, activate “Media”...
  • Page 40 CONNECT SYSTEM PHONE NOTE You can browse the menus using the Rotary • select the “Bluetooth®” device; • when requested by the audio device, enter the Pad. PIN code shown on the system display or confi rm • select “Add device”; on the device the PIN displayed;...
  • Page 41 CONNECT SYSTEM The following menu will appear on the screen once With the Phone connected, the following command During a call, the following options are enabled: the phone or device is connected to the system via bar is shown on the left of the display: Transfer to device.
  • Page 42 CONNECT SYSTEM NAVIGATION (where provided) The screen offers the following items: • Enter the address by selecting “Country”; – Country: • On the circular keypad, turn and press the Rotary NOTE You can browse the menus using the Pad to select the characters to compose the Rotary Pad.
  • Page 43 CONNECT SYSTEM Repeat the same procedure to complete the other When navigation starts, the following command bar The following information is also shown on the entries (City, Street and House Number); is shown on the left of the display: navigation page: on the bottom: name of the current road and current position;...
  • Page 44 CONNECT SYSTEM Tyre pressure monitoring system Checking the engine oil level (TPMS) The oil level is displayed before each time the engine is started and it can be checked via the The TPMS signals the driver a possible insuffi cient Connect system, in order to do that, proceed as pressure if this falls below the warning limit for any follows:...
  • Page 45 CONNECT SYSTEM In order to see which tyre has insuffi cient pressure Infl ation pressure on the Connect system display, proceed as follows: The tyre pressure values can be found in the • from the main menu (MENU button), select the “Owner Handbook”...
  • Page 46 CONNECT SYSTEM SETTINGS Lights Clock & Date To access the user-programmable functions, open the main menu by pressing the MENU button, then Use the Rotary Pad to access the “Lights” function To access the “Clock & Date” function, select it by select “SETTINGS”...
  • Page 47 CONNECT SYSTEM Forward Collision Warning You can see the airbag status via the LED next to Reversing Camera (where provided) the status icon on the front ceiling light. Allows you to select the intervention readiness for This function can be used to carry out the following the anti-collision system.
  • Page 48 CONNECT SYSTEM Doors & Locks Cluster Infotainment To access the “Doors & Locks” function, select it by To access the “Cluster” function, select it by To access the “Infotainment” function, select it by turning the Rotary Pad and press the Rotary Pad turning the Rotary Pad and press the Rotary Pad turning the Rotary Pad and press the Rotary Pad to activate.

  • Page 49: Park Sensors System

    PARK SENSORS SYSTEM Parking with the aid of the Exiting from the Park Sensors screen Disabling the Park Sensors system Park Sensors system on the display You can disable the Park Sensors system by pressing the button to the left of the light The Park Sensors System is enabled when you Press the Rotary Pad to exit from the Park Sensors switch.

  • Page 50: Refuelling

    REFUELLING To refuel proceed as follows: Petrol engines • open the fuel cap by pressing on its rear edge; It is advisable to use unleaded petrol, with an • remove the closing cap of the dispenser; octane number (RON) 98 for the best performance. •...
  • Page 52 ENGLISH...
