Thermokon LCF02 Touch 3AO2DO Datasheet page 9

Issue Date: 22.01.2020
266 0x010A
Read-write
267 0x010B Read-write
268 0x010C
Read-write
269 0x010D Read-write
270 0x010E Read-write
Set point settings
Address
271 0x010F Read-write
272 0x0110
Read-write
273 0x0111
Read-write
274 0x0112
Read-write
275 0x0113 Read-write
276 0x0114 Read-write
Thermokon Sensortechnik GmbH, Platanenweg 1, 35756 Mittenaar, Deutschland · tel: 02778/6960-0 · fax: -400 ·
External temperature (limiter) sensor high limit
(338=3, for limiter)
-200..+1000 = -20,0...+100,0 °C
External temperature (limiter) sensor low limit
(338=3, for limiter)
-200..+1000 = -20,0...+100,0 °C
Power failure
0=keep off after power-on-reset
1=return to last stFate after power failure
2=switch on after power-on-reset
Key-lock
0x00=unlocked
0x01=lock on/off
0x02=lock mode
0x04=lock clock
0x08=lock fan speed
0x10=lock temp setting
0x1F=lock all keystrokes
Once a locked key is pressed the LOCK symbol shall be
displayed and blink twice.
Display Settings
0b00000001= show Setpoint (if no setpoint is shown the
setpoint keys are locked = 0x010D = 0x10=lock temp
setting)
0b00000010= show Room temperature
0b00000100 = show valve symbol
0b00001000 = show PI-Loop percentage
0bxxx10000 = show Room temperature from Register
0x205
(if only room temp or setpoint is shown, then in big
numbers)
Access Description
Default Setpoint after Power On Reset
0..500 = 0...50,0 °C
Setpoint temperature lower limit
0..500 = 0..50,0 °C
Setpoint temperature upper limit
0..500 = 0..50,0 °C
Setpoint increment/decrement value
1..100 = 0,1...10,0 °C
ECO mode temperature setpoint cooling
250..450 = +25,0..+45,0 °C
ECO mode temperature setpoint heating
120..240 = +12,0..+24,0 °C
LCF02-Touch_3AO2DO_Datasheet_en.docx © 2020
Page 9 / 15
0.1 °C/°F
0.1 °C/°F
Resolution / Unit
0.1 °C/°F
0.1 °C/°F
0.1 °C/°F
0.1 °C/°F
0.1 °C/°F
0.1 °C/°F
www.thermokon.de · email@thermokon.de
40°C
0°C
1
0
15
Default
210
160
300
5
300
190
