Thermokon LCF02 Touch 3AO2DO Datasheet page 11

Issue Date: 22.01.2020
300 0x012C
301 0x012D
Read-write
302 0x012E
Read-write
303 0x012F
Read-write
304 0x0130
Inputs
Address
336 0x0150
337 0x0151
338 0x0152
339 0x0153
340 0x0154
Timer
Address
Read-write
400 0x0190
Thermokon Sensortechnik GmbH, Platanenweg 1, 35756 Mittenaar, Deutschland · tel: 02778/6960-0 · fax: -400 ·
Change-Over Temperature Threshold for Cooling
Read-write
0..500 = 0..+50,0 °C
In case temperature is in between both thresholds the
last state will be maintained
Electrical Heater Stage 1 Threshold control variable
0..100%
Electrical Heater Stage 2 Threshold control variable
0..100%
Electrical Heater Stage 3 Threshold control variable
0..100%
Read-write Valve type selection
4= proportional (0V = 0% ..10V = 100%)
5=invers proportional (0V = 100% ..10V = 0%)
6=proportional Belimo 6 way
7=proportional Sauter 6 way with Ø15mm
8=proportional Sauter 6 way with Ø20mm
9=proportional Belimo 6 way, counter direction
10=proportional Sauter 6 way with Ø15mm, counter
direction
11=proportional Sauter 6 way with Ø20mm, counter
direction
12=no valve
Access Description
Read-write Configuration external input 1
0 = No function
1 = Occupancy sensor (Open = Occupied)
2 = Occupancy sensor (Closed =Occupied)
3 = Window contact (Open = Window Open)
4 = Window contact (Closed = Window Open)
5 = Disable heating (Open = Heating disabled)
6 = Disable heating (Closed = Heating Disabled)
7 = Disable cooling (Open = Disable Cooling)
8 = Disable cooling (Closed = Disable Cooling)
9 = Dew Point Sensor (Open = Dewpoint crossed,
disable cooling)
10 = Dew Point Sensor (Closed = Dewpoint crossed,
disable cooling)
Read-write Configuration external input 2
0 = No function
1 = Occupancy sensor (Open = Occupied)
2= Occupancy sensor (Closed =Occupied)
3 = Window contact (Open = Window Open)
4 = Window contact (Closed = Window Open)
5 = Disable heating (Open = Heating disabled)
6 = Disable heating (Closed = Heating Disabled)
7 = Disable cooling (Open = Disable Cooling)
8 = Disable cooling (Closed = Disable Cooling)
9 = Dew Point Sensor (Open = Dewpoint crossed,
disable cooling)
10 = Dew Point Sensor (Closed = Dewpoint crossed,
disable cooling)
Read-write Configuration Sensor Input
0= none
1 = Change Over Temp sensor (NTC10K)
2 = Ext. Temp sensor (NTC10K)
3 = Temperature Limiter
Read-write ESI (Energy Savings Input) - ON delay
ON delay for ESI. Delays Energy stop by n seconds
Read-write OCC input - OFF delay
0...65535 -> 0...65535 seconds
Access Description
Clock mode configuration
0=Don't show time in LCD
1=Show time 12h mode
2=show time 24h mode
LCF02-Touch_3AO2DO_Datasheet_en.docx © 2020
Page 11 / 15
0.1 °C/°F
1.0 %
1.0 %
1.0 %
Resolution / Unit
1.0 s
1.0 s
Resolution / Unit
www.thermokon.de · email@thermokon.de
190
65
80
90
4
Default
0
0
0
0
1800
Default
2
