Thermokon LCF02 Touch 3AO2DO Datasheet page 8

Page 8 / 15
Input Register
Address Access
0 0x0000
1 0x0001
2 0x0002
3 0x0003
4 0x0004
5 0x0005
6 0x0006
7 0x0007
8 0x0008
9 0x0009
10 0x000A
11 0x000B
Holding Register
General settings
Address
256 0x0100 Read-write
257 0x0101
Read-write
258 0x0102 Read-write
259 0x0103
Read-write
260 0x0104
Read-write
261 0x0105 Read-write
262 0x0106 Read-write
263 0x0107 Read-write
264 0x0108 Read-write
265 0x0109 Read-write
