OWNER'S MANUAL
TRINITY PRO 84" x 19" WOOD TOP
Model # TSNLNA-7299
Important / Important / Importante
FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS
Directives intelligentes
POUR DES DIRECTIVES D'ASSEMBLAGE 3D RAPIDES ET FACILES
Instrucciones Inteligentes
PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D
DOWNLOAD THE FREE APP | TÉLÉCHARGER L'APPLICATION GRATUITE | DESCARGUE LA APLICACIÓN GRATUITA
Advertisement
Table of Contents
Related Manuals for Bilt TRINITY PRO TSNLNA-7299
Summary of Contents for Bilt TRINITY PRO TSNLNA-7299
- Page 1 OWNER’S MANUAL TRINITY PRO 84” x 19” WOOD TOP Model # TSNLNA-7299 Important / Important / Importante FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS Directives intelligentes POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES Instrucciones Inteligentes PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D DOWNLOAD THE FREE APP | TÉLÉCHARGER L’APPLICATION GRATUITE | DESCARGUE LA APLICACIÓN GRATUITA...
-
Page 2: Parts List
PARTS LIST Your TRINITY PRO 84“ x 19“ Wood Top can be mounted on top of the TRINITY PRO Base Cabinet. To install it requires one of the following parts kit for assembly which are included in your TRINITY PRO Base Cabinet hardware package. - Page 3 ASSEMBLY INSTRUCTIONS Option 1 (Installation across 2 Base Cabinets) Step 1 Base Wood Move (2) assembled TRINITY PRO Base Cabinets to your desired Cabinet (2) Top (1) location, and space them as shown below. With 2 people, position a TRINITY PRO 84”x 19” WOOD TOP on the Base Cabinets, making sure that the ends are flush with the outside edge of each Base Cabinet.
- Page 4 ASSEMBLY INSTRUCTIONS Option 1 (Installation across 2 Base Cabinets) Step 2 Open doors of each Base Cabinet as shown below. A (8) Electric screwdriver (Phillips head) Insert WOOD SCREW (A) into each hole on base cabinet top and tighten them fully to wood top with an electric screwdriver (Phillips head).
- Page 5 ASSEMBLY INSTRUCTIONS Option 2 (Installation with Wood Top Overhang) Step 1 If you want to attach your Wood Top with 2 Base Cabinets Wood next to each other and have overhang of the Wood Top on Base Top (1) Cabinet (2) either side, please follow the below instructions.
- Page 6 ASSEMBLY INSTRUCTIONS Option 2 (Installation with Wood Top Overhang) Step 2 Open doors of each Base Cabinet as shown. A (8) Electric screwdriver (Phillips head) Insert WOOD SCREW (A) into each hole on base cabinet top and tighten them fully to wood top with an electric screwdriver (Phillips head).
- Page 7 ASSEMBLY INSTRUCTIONS Option 2 (Installation with Wood Top Overhang) Step 3 Place two WALL BRACKETS (B) to overhang Wood Top bottom as shown. Make sure that one side of WALL BRACKETS (B) attach to Wood Top bottom and the other side attach to wall. A (4) B (2) C (4)
- Page 8 ASSEMBLY INSTRUCTIONS Option 3 (Installation with 4 Base Cabinets) Step 1 Move (4) assembled TRINITY PRO Base Cabinets to your desired location, and space them as shown below. Wood Base Cabinet Base Cabinet With 2 people, position a TRINITY PRO 84”x 19” WOOD Top (1) w/Doors (1) w/Drawers (3)
- Page 9 ASSEMBLY INSTRUCTIONS Option 3 (Installation with 4 Base Cabinets) Step 2 Remove top three drawers of each Base Cabinet as shown below. Open doors of Base Cabinet as shown below. DRAWER REMOVAL: Pull drawer out so that it is almost fully extended. On RIGHT side, push black release lever DOWN.
- Page 10 ASSEMBLY INSTRUCTIONS Option 3 (Installation with 4 Base Cabinets) Step 3 Insert WOOD SCREW (A) into each hole on base cabinet top and tighten them fully to wood top with an electric screwdriver A (16) Electric screwdriver (Phillips head) (Phillips head). ©...
- Page 11 ASSEMBLY INSTRUCTIONS Option 3 (Installation with 4 Base Cabinets) Step 4 DRAWER REPLACEMENT : To replace drawer, pull slides out completely. Insert brackets on each side of Drawer Slides into corresponding slots on Cabinet Slides, making sure they are properly positioned.
-
Page 12: Service Parts List
SERVICE PARTS LIST TRINITY Customer Service provides the following replacement parts: Part Number Description PBK-02-011-0020 Wood Top Mounting Hardware Kit (x8) (x2) (x4) (x4) © 2021 TRINITY - 800.985.5506... -
Page 13: Care And Maintenance
WARNINGS Read and understand all instructions. Failure to follow all instructions may result in injury and/or damage. The warnings, cautions, and instructions discussed in this manual cannot cover all possible conditions or situations that may occur. The user must always be aware of their environment and ensure that they use the product in a safe and responsible manner. -
Page 14: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY PRO 84” x 19” Wood Top. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. -
Page 15: Year Limited Warranty
1 YEAR LIMITED WARRANTY TRINITY PRO 84” x 19” Wood Top Model # TSNLNA-7299 Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the TRINITY PRO 84” x 19” Wood Top (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase. - Page 16 CONTACT US QUESTIONS? NEED PARTS? WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com...
