OWNER'S MANUAL
TRINITY 72" x 19" Wood Top Work Table
Model # TSM-7202
TRINITY 72" x 24" Wood Top Work Table
Model # TSM-7203
Important / Important / Importante
FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS
Direct ives int elligent es
POUR DES DIRECTIVES D'ASSEMBLAGE 3D RAPIDES ET FACILES
Inst rucciones Int eligent es
PARA INSTRUCCIONES DE ENSAMBLAJE RAPIDAS Y SENCILLAS EN 3D
DOWNLOAD THE FREE APP | TÉLÉCHARGER L'APPLICATION GRATUITE | DESCARGUE LA APLICACIÓN GRATUITA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Trinity TSM-7202 and is the answer not in the manual?

Questions and answers

Related Manuals for Bilt Trinity TSM-7202

Summary of Contents for Bilt Trinity TSM-7202

  • Page 1 OWNER’S MANUAL TRINITY 72” x 19” Wood Top Work Table Model # TSM-7202 TRINITY 72” x 24” Wood Top Work Table Model # TSM-7203 Important / Important / Importante FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS Direct ives int elligent es POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES Inst rucciones Int eligent es PARA INSTRUCCIONES DE ENSAMBLAJE RAPIDAS Y SENCILLAS EN 3D...
  • Page 2 PARTS LIST Your TRINITY 72” Wood Top Work Table should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com.
  • Page 3 ASSEMBLY INSTRUCTIONS STEP 1 Lay RIGHT (D) and LEFT (E) SIDE FRAMES on a flat F (4) G (8) H (8) D (1) E (1) smooth surface on the ground. Take ADJUSTABLE LEG (F) and orient insert nuts toward mounting holes on Side Frames.
  • Page 4 ASSEMBLY INSTRUCTIONS STEP 3 Take RIGHT (D) and LEFT (E) SIDE FRAMES and orient parts as shown. G (8) H (8) For proper installation, please make sure screw holes of TOP CROSS BEAMS (B) and screw holes of RIGHT (D) and LEFT (E) SIDE FRAMES align with each other. Hand tighten (2) LARGE BOLTS (G) through (2) LARGE WASHERS (H) and TOP CROSS BEAM (B) onto RIGHT SIDE FRAME (D).
  • Page 5 ASSEMBLY INSTRUCTIONS STEP 4 Take BOTTOM CROSS BEAM (C) and align it to RIGHT (D) and LEFT (E) SIDE C (1) G (4) H (4) FRAMES. Hand tighten LARGE BOLTS (G) through LARGE WASHERS (H) and BOTTOM CROSS BEAM (C) onto RIGHT (D) and LEFT (E) SIDE FRAMES. Only hand tighten LARGE BOLTS (G).
  • Page 6 ASSEMBLY INSTRUCTIONS STEP 6 Tighten all LARGE BOLTS (G) by WRENCH (K) or screw driver. K (1) Carefully turn Table onto its upright position. © 2019 TRINITY - 800.985.5506...

  • Page 7: Usage Instructions

    USAGE INSTRUCTIONS HEIGHT OPTION K (1) ADJUST HEIGHT 1. With Table upside down, remove LARGE BOLTS (G) and LARGE WASHERS (H) from Table legs. 2. Adjust to desired height. Make sure height adjustment allows for (2) LARGE BOLTS (G) to be inserted into each Table leg.

  • Page 8: Service Parts List

    SERVICE PARTS LIST – TSM-7202 / TSM-7203 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description LNA-06-002-7219 Wood Top-72”x19” ZBK-01-038-0820 Large Bolt LNA-06-002-7224 Wood Top-72”x24” ZBK-01-007-0816 Large Washer PBK-13-002-6750 Top Cross Beam PBK-14-002-1729 Left Side Frame PBK-14-003-1729 Right Side Frame PBK-13-001-6750...

  • Page 9: Care And Maintenance

    WARNINGS 1. Read and understand all instructions. Failure to follow all instructions may result in injury and/or damage. 2. The warnings, cautions, and instructions discussed in this manual cannot cover all possible conditions or situations that may occur. The user must always be aware of their environment and ensure that they use the product in a safe and responsible manner.

  • Page 10: Product Registration

    PRODUCT REGISTRATION Thank you for purchasing a TRINITY 72” Wood Top Work Table. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com.

  • Page 11: Year Limited Warranty

    1 YEAR LIMITED WARRANTY TRINITY 72” Wood Top Work Table Model # TSM-7202 / TSM-7203 Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the TRINITY 72” Wood Top Work Table (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase.
  • Page 12 CONTACT US QUESTIONS? NEED PARTS? WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com...

This manual is also suitable for:

Trinity tsm-7203
