- Page 1 AVP-EN2K-101 AVP-DE2K-101 1080P HDMI over IP Encoder/Decoder USER MANUAL Version: 201006V1.1...
- Page 2 Important Safety Instructions 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth. splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. 7. Unplug this apparatus 2.
- Page 3 Warnings of FCC This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 4: Table Of Contents
Table of Contents Features ....................2 Package Contents ..................4 Encoder ..................... 4 Decoder ..................... 4 Specifications .................... 5 Encoder ..................... 5 Decoder ..................... 6 Panel Description ..................7 Encoder ..................... 7 Decoder ..................... 9 Installation ....................10 Applications .................... 11 IP Matrix .................... -
Page 5: Features
Introduction aegis 1080P over IP includes H.264 IP encoder (AVP-EN2K-101) and decoder (AVP-DE2K-101) can work together to provide complete end-to-end streaming systems. Video, audio, IR, USB and RS232 signals can be routed together or separately throughout the matrix system. They can also function video wall up to the dimensions of 16 x 16 with input and output HDMI resolutions supported up to 1920 x 1080@60Hz. - Page 6 (HDMIoverIPConsole) and AGS-i Touch on iPad. Support audio de-embedding output. Support RS232 pass-through between encoder and decoder, or between IP control box and encoder/decoder. Support IR pass-through between encoder and decoder, as well as IR pass-through from IP control box to encoder/decoder in global cache IR format.
-
Page 7: Package Contents
Package Contents Encoder 1 x AVP-EN2K-101 Encoder 1 x Power Adapter (12 VDC 1A) 1 x Exchangeable US Plug 2 x Phoenix Male Connectors (3.5 mm, 3 Pins) 2 x Mounting Ears (with Screws) ... -
Page 8: Specifications
Specifications Encoder Video Input Video Port 1 x HDMI Input Video Type HDMI 1.3, HDCP 1.4 640 x 480@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 800 x 600@60Hz, 1024 x 768@60Hz, 720p@50Hz, 720p@60Hz, 1280 x 800@60Hz, 1280 x 1024@60Hz, 1360 x 768@60Hz, Input Resolution 1366 x 768@60Hz, 1400 x 1050@60Hz, 1440 x 900@60Hz, 1680 x 1050@60Hz, 1920 x 540@60Hz, 1080i@50Hz, 1080i@60Hz,... -
Page 9: Decoder
1366 x 768@60Hz, 1440 x 900@60Hz, 1680 x 1050@60Hz, 1920 x 540@60Hz, 1080p@24Hz, 1080p@25Hz, 1080p@30Hz, 1080p@50Hz, 1080p@60Hz, 1920 x 1200@60Hz 100 Ω Video Impendence When works with AVP-EN2K-101 encoder: End-to-End Time About 80 ms (Low latency mode, from TX to RX) Latency ... -
Page 10: Panel Description
General +32°F ~ +113°F (0°C ~ +45°C) Operating Temperature 10% ~ 90%, non-condensing -4°F ~ 140°F (-20°C ~ +70°C) Storage Temperature 10% ~ 90%, non-condensing Human body model: ESD Protection ±8kV (air-gap discharge) ±4kV (contact discharge) Surge Protection Voltage: ±1 kV Power Supply 12 V 1 A DC... - Page 11 Rear Panel Name Description DC 12V Connect to the power adapter provided. Connect to an audio decoder such as an amplifier for audio Audio Out de-embedding output from HDMI source. HDMI In Connect to an HDMI source device. Connect this port to a RS232 device such as a computer to RS232 bi-directionally communicate with a RS232 device at the IP control box or decoder side.
-
Page 12: Decoder
Decoder Front Panel Name Description Power On: The device is powered on. Off: The device is powered off. On: The device is receiving IP stream. Status Blinking: The device doesn’t receive IP stream. Off: The device is powered off or in the boot process. USB 1-2 Connect to USB devices (e.g. -
Page 13: Installation
Name Description device control. Note: The encoder and decoder can be powered by either a PoE-enabled network switch via this port or power adapters. Reset LED Use a pointed stylus to press and hold this key for more than five seconds until the Reset LED lights up, release Reset Key this key, the device reboots and restores to its factory default. -
Page 14: Applications
Applications IP Matrix Video Wall You can use encoders and decoders to build a M x N video wall with PC configurator and IP control box. M, N is an integer ranging from 1 to 16. -
Page 15: Hardware Installation
Hardware Installation Note: • Before the installation, disconnect the power supplies from all the devices. • If the switch doesn’t support PoE function or is unable to provide enough power, connect encoder and decoder to power supplies. -
Page 16: Device Control
Device Control encoder decoder allow configurator (HDMIoverIPConsole), AGS-i Touch and IP control box for controlling them. This section briefly introduces how to route the video from source to the display using these tools. By default, audio, video, IR and RS232 signals are routed together.
