Assembly of Evelo Aurora Hub
The focus of this document is to assist with the assembly of your new EVELO Delta X.
The scope is intentionally narrow – The "User Guide" that was included with your bike
covers a much broader spectrum of topics: fit adjustments, battery care, controls etc.
Our Team is here to help 7 days a week!
Watch the Assembly
contact@evelo.com | 877-991-7272
Instructions Video
Feel Free to reach out!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aurora Hub and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Evelo Aurora Hub

Summary of Contents for Evelo Aurora Hub

  • Page 1 Assembly of Evelo Aurora Hub The focus of this document is to assist with the assembly of your new EVELO Delta X. The scope is intentionally narrow – The “User Guide” that was included with your bike covers a much broader spectrum of topics: fit adjustments, battery care, controls etc.
  • Page 2 Carefully remove all packing material from Tools and User Guides will be in the small bike, avoid using sharp objects as to protect black Evelo box. The Pedals will be in a the paint. small cardboard box. ASSEMBLY OF EVELO AURORA HUB...

  • Page 3: Install Front Wheel

    Install Front Wheel Remove black Axle from front fork. Put Front Wheel into place. Lower the kickstand. Replace black Axle and tighten. ASSEMBLY OF EVELO AURORA HUB...

  • Page 4: Install Handlebars

    Loosen the screw on top of the fork and remove cover. Remove cap and put aside. Keep track of this cap. Loosen bolts on sides of handlebar stem Place handlebars on stem and align with center ASSEMBLY OF EVELO AURORA HUB...
  • Page 5 Install Headlight Tighten top bolt first, then the side bolts. Replace cap. Attach headlight to cable. Remove screw on back side of Fork. Hold headlight behind Fork and replace screw. ASSEMBLY OF EVELO AURORA HUB...

  • Page 6: Install Pedals

    There is an L and an R stamped into the end of each pedal for reference. Screw pedals into crank arms. It is important to note that the pedals are threaded differently. The right pedal screws in clockwise and the left pedal screws in counter-clockwise. right pedal left pedal ASSEMBLY OF EVELO AURORA HUB...

  • Page 7: Use Of Battery

    Use of Battery Click Battery into place. Power up and you’re ready to ride! ASSEMBLY OF EVELO AURORA HUB...

  • Page 8: Serial Number Location

    Serial Number Location To register your bike on our website, you will need to record the serial number. It is located on the headtube of your bike, just above the front fork. ASSEMBLY OF EVELO AURORA HUB...
  • Page 9 There is considerable additional information in your “User Guide”. Of course, if you ever have questions, our team is ready to help! Our Team is here to help 7 days a week! contact@evelo.com | 877-991-7272 Feel Free to reach out!
