I N S T A L L A T I O N I N S T R U C T I O N S
This device complies with part 15 of the FCC rules. Operation is subject to the following 2 conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio or television
communications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
•
Reorient or relocate the receiving antenna
•
Increase the separation between the equipment and receiver
•
Connect the equipment to an outlet on a circuit other than that to which the receiver is connected
Consult the dealer or and experienced radio/TV technician for help
Automated Flat Panel Ceiling Lift
CM2C40

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM2C40U and is the answer not in the manual?

Questions and answers

Related Manuals for CHIEF CM2C40U

Summary of Contents for CHIEF CM2C40U

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Automated Flat Panel Ceiling Lift This device complies with part 15 of the FCC rules. Operation is subject to the following 2 conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 2 CM2C40 Installation Instructions Milestone AV Technologies, and its affiliated corporations and subsidiaries (collectively, "Milestone"), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product.

  • Page 3: Table Of Contents

    Installation Instructions CM2C40 CONTENTS INSTALLATION REQUIREMENTS ......................5 Power Requirements and Wiring ....................... 5 INSTALLATION ............................5 Pre-Installation Configuration and Adjustments ..................5 Configuring the Mount for the Display ....................5 Install Display ............................7 Shelf Height Adjustment ......................... 8 Determining Minimum I.D.
  • Page 4 CM2C40 Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación Perforar...

  • Page 5: Installation Requirements

    Installation Instructions CM2C40 INSTALLATION REQUIREMENTS Install interface bracket or mounting buttons to display following the instructions provided with bracket. The CM2C40 has been designed to be mounted either hanging Measure the distance from the center of a bottom mounting from an overhead structure or mounted to existing stud wall button to the lowest point of the display.
  • Page 6 CM2C40 Installation Instructions Figure 5 10. Using the remote control, lower the lift until it stops. (See figure 3) If more than 2" of faceplate adjustment is required: 11. Raise lift following instructions in step 6. (See figure 3) 12. Loosen four nuts securing faceplate mounting bracket to Figure 3 frame.

  • Page 7: Install Display

    Installation Instructions CM2C40 15. Align studs in faceplate with appropriate holes in faceplate mounting bracket and hang faceplate on bracket with studs. 16. Secure faceplate to faceplate mounting bracket using two locknuts. (See figure 7) Figure 7 Cable Installation and Routing The CM2C40 has an integrated cable management system that allows cables to be automatically "fed out"...

  • Page 8: Shelf Height Adjustment

    CM2C40 Installation Instructions From Display Figure 10...
  • Page 9 Installation Instructions CM2C40 Route cable(s) down through opening at rear of middle 13. Slide cable guide side cover over cable guide making cable clamp mounting bracket. (See figure 10) and certain lip on back cover plate is fully seated in groove in (See figure 11) cable guide side cover.

  • Page 10: Determining Minimum I.d. Of Furniture

    CM2C40 Installation Instructions Mount Installation of travel must be considered when location the mount and a stop bar must be installed along the top edge of The CM2C40 has been designed to be mounted either hanging the opening in the ceiling. The stop bar must span the from an overhead structure or mounted to existing stud wall entire width of the front and back openings, and structures.
  • Page 11 Installation Instructions CM2C40 While maintaining dimensions referenced in figure 15, mark Display Installation base plate mounting hole locations. (See figure 16) Drill pilot holes at marked locations. WARNING: EXCEEDING MAXIMUM WEIGHT CAPACITY Mark four side bracket mounting hole locations if applicable.
  • Page 12 CM2C40 Installation Instructions NOTE: Holes are provided in the faceplate for use with a padlock or similar locking device, if desired. In addition, WARNING: IMPROPER INSTALLATION CAN LEAD TO the pin and nut may be removed from the upper holes SEVERE PERSONAL INJURY OR DAMAGE TO and moved to the lower holes for use as a more EQUIPMENT! Make sure all four nuts are tight before...
  • Page 13 Installation Instructions CM2C40 Bottom Cover Installation If the dimension identified during step 1 above is equal to or less than the thickness of the bottom cover being installed, After the CM2C40 has been properly configured for the display the display travel limits must be adjusted before continuing and the display installed, the bottom cover height must be to aviod a collision scenario between the bottom cover and adjusted to ensure proper fit into ceiling.

  • Page 14: Mount Installation

    CM2C40 Installation Instructions Assemble bottom cover to cover mounting plate using There is an upward travel limit adjustment screw and a #10-24 screws a minimum of 1/4" plus the thickness of the downward travel limit adjustment screw located on the top right cover material long.

  • Page 15: Adjustments

    Installation Instructions CM2C40 Lift Column Bearing Adjustment The upper and lower lift columns are aligned using two lift bearings, one upper and one lower. Bearing adjustment is pre-set at the factory, however, there may be times when it is required to make slight adjustments in bearing tightness to eliminate excess play in lift columns or noise.

  • Page 16: Extended Programming Capabilities

    CM2C40 Installation Instructions Extended Programming Capabilities Normal Operating Mode The CM2C40 allows for extended programming to make the FUNCTION REQUIRED ACTION mount compatible with other devices such as a Universal MOVE DISPLAY TO HOME PRESS ONCE Remote or other control devices through a serial connection. RETRACT DISPLAY PRESS ONCE Setting or changing the configuration of the CM2C40 is done...
  • Page 17 Installation Instructions CM2C40 NEC Protocol: Table 1-1: IR System Code The modulated carrier is usually derived from 455kHz and is 1/12 of the frequency with 1/3 duty cycle. Switch # 2 Switch # 1 Switch # 3 Custom Code When data are transmitted repeatedly, the frame cycle is 107.9ms or 186 period.

  • Page 18: Ir-Se15 Programming

    CM2C40 Installation Instructions IR-SE15 Programming IR-SE15 Control Features: • Carrier Frequency:38KHz • Protocol:NEC - Full Repeat • System Code(s):6E (Default) - Multiple Codes Selected via Key-Press (see below) Table 1-2: IR-SE15 Control Codes Key Number Key Name Hex Code HOME SAVE LEFT STOP...

  • Page 19: Ir-Sc33A Programming

    Installation Instructions CM2C40 IR-SC33a Programming IR-SC33a Control Features • Carrier Frequency: 38KHz • Protocol: NEC - Full Repeat • System Code: 6E Table 1-4: Key Number Key Name Hex Code HOME RETRACT LEFT RIGHT EXTEND PRESET 1 PRESET 2 PRESET 3 SAVE 19 20...

  • Page 20: Serial Communications

    CM2C40 Installation Instructions Serial Communications NOTE: Check with the appropriate automation system vendor for available drivers and/or software for any external devices. Notes: [PR] = Product ID (CM2C40 = 02) [AD] = Address (see address description & table) [CR] = ASCII Carriage Return [CH] = Check Code [ST] = Status (see status table) Connecctions to be made to 9 pin connector as follows:...
  • Page 21 Installation Instructions CM2C40 Address Description: Multiple Chief devices can be used on the same network by setting each device to a different address. Note: All units ship with a default address of 0 Address Table: (See figure 31) Addresses are set using dipswitches located next to power inlet on mount.

  • Page 22: Cm2 Hardware Reference

    CM2C40 Installation Instructions CM2C40 Hardware Reference Motor Control Hardware Information (See figure 31) RS485 Network Programmable Paramaters and Status Bit Assignments RS485 Network Programmable Parameters Parameter Name Range Factory Default Units Identifier 0 Custom Code 1-32687 1 Maximum Movement Time 100-6000 3100 0.01 sec...
  • Page 23 Installation Instructions CM2C40 1st Position of switch array 1st Position of connector array 1st Position of connector array Figure 31 CM2C40 Connectors and Switches...

  • Page 24: Cm2 Interface Board Hardware Information

    CM2C40 Installation Instructions CM2C40 Interface Board Hardware Information (See figure 31) Dry Contact Closures The unit provides dry contact outputs for system feedback, or to control other devices. To complete circuits to external devices: Connect the common wire from your switch to terminal 7. (See figure 32) Connect the 'up' wire from your switch to terminal 5.

  • Page 25: Other Dry Contact Options

    Units are shipped with error contacts "Normally Open". To set unit to respond to "Normally Closed" error contacts contact a Chief Technical Support representative by calling 1-800-582-6480, or by visiting www.chiefmfg.com. When unit receives an Extend error signal during an extend operation, the unit will immediately stop and reverse direction.
  • Page 26 Units are shipped with error contacts "Normally Open". To set unit to respond to "Normally Closed" error contacts contact a Chief Technical Support representative by calling 1-800-582-6480, or by visiting www.chiefmfg.com. When unit receives a Retract error signal during a Retract operation, the unit will immediately stop and reverse direction.

  • Page 27: Connector And Switch Assignments

    Installation Instructions CM2C40 Connector and Switch Assignments All Dipswitches are in the "OFF" position when shipped from factory. Switch 1 Switch 2 Switch 3 Switch 4 Not Used Switch 5 Not Used Switch 6 485 Address Switch 7 485 Address Switch 8 485 Address IR System Code Select Logic...
  • Page 28 CM2C40 Installation Instructions Figure 40...
  • Page 29 Installation Instructions CM2C40 Troubleshooting SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION Lift does not respond • No Power to Mount Verify Power to Mount • 12V trigger option being Normal Operation used See "Low Voltage Sensing" section • Overheated motor Allow motor to cool for 10 to 15 minutes...
