Clarion PU-2426A-A Service Manual

SPECIFICATIONS
CD section
Disc: Compact disc (8 cm / 12 cm)
Separation: More than 60 dB (at 20 kHz LPF)
S/N ratio: More than 70 dB (at 20 kHz LPF JIS-A)
Distortion: Less than 0.05 % (at 20 kHz LPF)
General
Optical output power: -10 to -1.5 dBm
Power supply voltage: DC13.5 V
Negative ground
Current consumption: Less than 5A
Dimensions(mm): 179 (W) x 51.5 (H) x 180.7 (D)
NOTE
We cannot supply PWB with component parts in principle.
When a circuit on PWB has failure , please repair it by com-
ponent parts base. Parts which are not mentioned in ser-
vice manual are not supplied.
Specifications and design arevsubject to change without
notice for further improvement.
COMPONENTS
PU-2426A-A
CAUTIONS
Use of controls,adjustment or performance of procedures
other than those specified herein,may result in hazardous
radiation exposure.
The COMPACT DISC player should not be adjusted or
repaired by anyone except properly qualified service per-
sonnel.
This appliance contains a laser system and is classified as
a "CLASS 1 LASER PRODUCT".
To use this model properly,read this Owner's Manual care-
fully and kep this manual for your future reference.
Clarion Co., Ltd.
50 Kamitoda, Toda-shi, Saitama 335-8511 Japan
Service Dept.: 5-66 Azuma , Kitamoto-shi, Saitama 364-0007 Japan
Tel: +81-48-541-2335 / 2432 FAX: +81-48-541-2703
Service Manual
- 1 -
SAAB Automobile Genuine
6-Disc CD Changer
PU-2426A-A
Model
(Genuine No.12799475)
In case of any trouble with this player,please contact your
nearest"AUTHORIZED service station".To prevent direct
exposure to the laser beam,do not to open the enclosure.
1 2 7 9 9 4 7 5
C L A S S 1 L A S E R P R O D U C T
H / W 1 2 7 9 9 4 8 7
S / W 1 2 7 9 9 4 8 8
1 2 V N E G . G N D .
T HI S DEVI CE COMPL I ES WI T H PART 1 5 OF T HE F CC RUL ES OPE RAT I ON I S SUBJ ECT T O T HE F OL L OW I NG T WO
CONDI T I ONS: ( 1 ) T HI S DEVI CE MAY NOT CAUSE HARMF UL I NT ERF ERENCE, AND ( 2 )
ANY I NT ERF ERENCE RECEI VE D, ANY I NT ERF ERENCE RECEI VE D, I NCL UDI NG I NT ERF E RENCE I NCL UDI NG I NT ERF E RENCE T HAT MAY CAUSE UNDESI RED OPERAT I ON.
T HI S PRODUCT I ON COMPL I ES W I T H DHHS RUL ES
2 1 CF R SUBCHAPT ER J APPL I CABL E AT DAT E OF
MANUF ACT URE.
CL ARI ON CO. , L T D.
5 0 KAMI T ODA. T ODA- SHI . SAI T AMA- KEN. J APAN
Y S 9 4 7 5
MANUF ACT URED:
M A D E I N J A P A N P U - 2 4 2 6 A
To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow the
instructions so that customers and Engineers in
charge of repair or inspection can avoid suffering
any risk or injury.
1. Use specified parts.
The system uses parts with special safety features against
fire and voltage. Use only parts with equivalent character-
istics when replacing them.
The use of unspecified parts shall be regarded as remod-
eling for which we shall not be liable. The onus of product
liability (PL) shall not be our responsibility in cases where
an accident or failure is as a result of unspecified parts
being used.
2. Place the parts and wiring back in their original positions
after replacement or re-wiring.
For proper circuit construction, use of insulation tubes,
bonding, gaps to PWB, etc, is involved. The wiring con-
nection and routing to the PWB are specially planned us-
ing clamps to keep away from heated and high voltage
parts. Ensure that they are placed back in their original
positions after repair or inspection.
If extended damage is caused due to negligence during
repair, the legal responsibility shall be with the repairing
company.
Published by Service Dept.
298-6033-00 Dec.2002 P
Printed in Japan
