- Page 3 PC Card Interface for E6000 and E8000 Emulators User’s Manual ADE-702-324 Rev. 1.0 07/08/02 Hitachi, Ltd. HS6000EIP01HE(A)
- Page 4 Cautions 1. Hitachi neither warrants nor grants licenses of any rights of Hitachi’s or any third party’s patent, copyright, trademark, or other intellectual property rights for information contained in this document. Hitachi bears no responsibility for problems that may arise with third party’s rights, including intellectual property rights, in connection with use of the information contained in this document.
- Page 5 IMPORTANT INFORMATION READ FIRST • READ this user's manual before using this emulator product. • KEEP the user's manual handy for future reference. Do not attempt to use the emulator product until you fully understand its mechanism. Emulator Product: Throughout this document, the term "emulator product" shall be defined as the following products produced only by Hitachi, Ltd.
- Page 6 LIMITED WARRANTY Hitachi warrants its emulator products to be manufactured in accordance with published specifications and free from defects in material and/or workmanship. Hitachi, at its option, will repair or replace any emulator products returned intact to the factory, transportation charges prepaid, which Hitachi, upon inspection, shall determine to be defective in material and/or workmanship.
- Page 7 State Law: Some states do not allow the exclusion or limitation of implied warranties or liability for incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may have other rights which may vary from state to state.
- Page 8 SAFETY PAGE READ FIRST • READ this user's manual before using this emulator product. • KEEP the user's manual handy for future reference. Do not attempt to use the emulator product until you fully understand its mechanism. DEFINITION OF SIGNAL WORDS DANGER indicates an imminently hazardous situation which, if not avoided, will result in DEATH or SERIOUS INJURY to you or other people.
- Page 9 Notice When using this document, keep the following in mind: 1. This document may, wholly or partially, be subject to change without notice. 2. All rights are reserved: No one is permitted to reproduce or duplicate, in any form, the whole or part of this document without Hitachi’s permission.
- Page 10 Thank you for purchasing the PC card interface (HS6000EIP01H) for the E6000 and E8000 emulators. The PC card interface for the E6000 and E8000 emulators (hereafter called the PC card interface) connects the E6000 or E8000 emulator (hereafter called the emulator) to the host computer that has an interface conforming to the PC card specification TYPE II.
-
Page 11: Table Of Contents
Section 3 Preparation before Use ..............3 Connecting to Host Computer................... 3 Connecting to the Emulator ....................4 3.2.1 Connecting to the E6000 Emulator..............4 3.2.2 Connecting to the E8000 Emulator..............5 Section 4 Start Up....................6 Section 5 Notes on Use..................8... -
Page 12: Section 1 Specifications
Microsoft Windows operating system version 3.1) Emulator Hitachi E6000 emulator or E8000 emulator series External dimensions PC card: 54 mm x 85.5 mm x 4.6 mm Weight PC card: 29 g Temperature Operating: 10°C to 35°C Storage: –10°C to 50°C... -
Page 13: Section 2 Components
Section 2 Components Table 2 lists the PC card interface components. Table 2 Components Quan- Item Product Name Configuration tity Remarks Hardware PC card interface — Interface cable Cable length: 1.5 m Manual User's manual HS6000EIP01HE (this manual) -
Page 14: Section 3 Preparation Before Use
Section 3 Preparation before Use Connecting to Host Computer WARNING Always switch OFF the emulator and host computer, and make sure that the PC card interface is correctly oriented in the direction of before connecting or disconnecting the PC Insert CARD INTERFACE. -
Page 15: Connecting To The Emulator
3.2.1 Connecting to the E6000 Emulator When using the E6000 emulator, use the interface cable supplied together with the PC card interface, and connect the PC card interface to the E6000 emulator station through the interface cable as shown in figure 2. -
Page 16: Connecting To The E8000 Emulator
3.2.2 Connecting to the E8000 Emulator When using the E8000 emulator, use the interface cable supplied together with the PC card interface, and connect the PC card interface to the E8000 emulator through the interface cable as shown in figure 3. Figure 3 Connecting to E8000 Emulator... -
Page 17: Section 4 Start Up
1. Install the Hitachi debugging interface (HDI) as the emulator control software in the host computer. Insert the HDI installation disk into the floppy disk drive of the host computer, and execute the SETUP file to install the HDI. For details, refer to the E6000 Emulator User's Manual. - Page 18 6. Turn on the emulator and double-click the HDI icon to initiate the HDI. When the HDI has been initiated successfully, the dialog box shown in figure 5 will be displayed. Figure 5 Dialog Box at HDI Start-up 7. Select the PCMCIA on the dialog box, and click OK. The Link up is displayed on the status bar, which shows that the HDI start-up procedure has been completed successfully.
-
Page 19: Section 5 Notes On Use
Section 5 Notes on Use 1. This PC card interface is only for use with the Hitachi E6000 or E8000 emulator. Do not use with any other emulator together with the PC card interface. 2. Protect the PC card interface from excessive impacts and stresses. Keep out of direct sunlight, heat, and high humidity.
