2965 SERIES
RESWEEP
OPERATOR'S MANUAL
PARTS IDENTIFICATION
2565-985 06/2021

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2965 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Yetter 2965 Series

  • Page 1 2965 SERIES RESWEEP OPERATOR’S MANUAL PARTS IDENTIFICATION 2565-985 06/2021 2965-028, 2965-028-LA, 2965-040, 2965-052, 2965-053, 2965-057 YETTER MANUFACTURING CO. Founded 1930 Colchester, IL 62326 Toll free: (800)447-5777. Fax: (309)776-3222 Website: yetterco.com E-mail: info@yetterco.com...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS BOLT TORQUE................2 FOREWORD……………………………………………………….…....3 SAFETY………………………………………………………………....4 INSTALLATION………………………………………………....5-8 OPERATION………………………………………………….……....9 PARTS IDENTIFICATION…………………………………….....10-14 BOLT TORQUE Important: Over-tightening hardware can cause just as much damage as under-tightening. Tightening hardware beyond the recommended range can reduce its shock load capacity. All hardware is either Grade 5 unless otherwise noted. Grade 5 cap screws are marked with three radial lines on the head.
  • Page 3: Foreword

    Important will apply to the same information as specified by note only of an immediate and Yetter Manufacturing warrants all products manufactured and sold by it against defects in material. This urgent nature. warranty being expressly limited to replacement at the factory of such parts or products as shall appear to be defective after inspection.
  • Page 4: Safety

    BE ALERT! YOUR SAFETY IS INVOLVED WATCH FOR THIS SYMBOL. IT POINTS OUT IMPORTANT SAFETY PRECAUTIONS. IT MEANS “ATTENTION – BE ALERT!” It is your responsibility as an owner, operator, or supervision to know and instruct everyone using this machine at the time of initial assignment and at least annually thereafter, of the proper operation, precautions, and work hazards which exist in the operation of the machine in accordance with OSHA regulations.
  • Page 5: Installation

    INSTALLATION INSTRUCTIONS 2965-028, 2965-028-LA Pin Adjust Kits STEP 1: Take any existing faceplate mounted row cleaners or coulters off of the row unit. STEP 2: Install the mount bracket assembly to the faceplate using the provided ½”x1-1/2” bolts. Do not tighten bolts yet.
  • Page 6 INSTALLATION INSTRUCTIONS 2965-052, 2965-053, 2965-057 Screw Adjust Kits STEP 1: Take any existing faceplate mounted coulter or row cleaner off the row unit STEP 2: For Case row unit (2965-053), attach to the row unit using the provided ½” bolt and lock nuts. This may require taking off one or both of the gauge wheel arms.
  • Page 7 INSTALLATION INSTRUCTIONS Air Adjust Kit 2965-040 STEP 1: Take the snake head off the residue manager stem by removing the two 3/8” bolts and lock nuts. This is easier if the residue manager wheels are taken off first. STEP 2: Using the provided 3/8” bolts and lock nuts attach the Resweep shank to the square stem of the residue manager.
  • Page 8: Operation

    OPERATION A good starting point for depth is ¾”. Scouting behind the planter is critical for proper performance. If the unit is run to shallow it will not sufficiently take out the old crop stand. If it is run to deep it can leave a furrow over the seed zone.
  • Page 9 PART IDENTIFICATION 2965-028...
  • Page 10: Parts Identification

    PART IDENTIFICATION 2965-028-LA...
  • Page 11 PART IDENTIFICATION 2965-040...
  • Page 12 PART IDENTIFICATION 2965 -052...
  • Page 13 PART IDENTIFICATION 2965-053...
  • Page 14 PART IDENTIFICATION 2965-057...
  • Page 15 NOTES:...
  • Page 16 2565-985 – 06/2021...
