Step 9 - Temperature Settings - Warmup WHS-M-S3-Series Installation Manual

Step 9 -
Temperature Settings
Floor Construction
Screed Floors
Timber Floors
All other Floors
Limiting temperature control adjustment
1
• Remove the cap from the
thermostatic head, using a flat
blade screwdriver.
Remove only the first
adjustment wheel.
Locking temperature control adjustment
1
• Remove the cap from the
thermostatic head, using a flat
blade screwdriver. Remove
only the first adjustment
wheel.
Maximum Recommended
Temperature
55 °C
60 °C
See manufactures specifications
2
• Rotate the thermostatic head
to the maximum permitted
temperature. Place the
adjustment back as shown.
Replace cap.
2
• Rotate the thermostatic head
to the required temperature.
Place the adjustment back as
shown. Replace cap.
27
