Page 1: User Manual
Snapshot Arena Hazer™ OK on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle USER MANUAL Chauvet, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ALUES SETTING THE STARTING ADDRESS...11 DMX Quick Reference Chart ...12 ...13 ENERAL ROUBLESHOOTING ...14 ECHNICAL UPPORT 5. APPENDIX...14 DMX P ...14 RIMER ...15 ENERAL AINTENANCE ...15 ETURNS ROCEDURE ...15 LAIMS ...16 ECHNICAL PECIFICATIONS Arena Hazer User Manual ... 9 2007-05-29/16:06... -
Page 3: Before You Begin
1. B EFORE What is included 1 x Arena Hazer™ Road Case and Blower Timer Remote Power Cord Warranty Card User Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. -
Page 4: Safety Instructions
Never disconnect the power cord by pulling or tugging on the cord. Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. Arena Hazer User Manual 2007-05-29/16:06... -
Page 5: Maintenance
WARNING! Note: All fog machines are prone to clogging due to the thick consistency of fog liquid and the high temperature at which it vaporizes. However, a properly maintained fog machine should provide years of reliable use. Cleaning your fog machine regularly will help reduce costly replacement and repair charges. -
Page 6: Introduction
Output: 20,000cfm (haze) • 1.4 quart tank capacity • Wired multi-function remote included • Water-based hazer DMX Channel Summary HANNEL UNCTION Haze Blower Product Overview Haze output Carrying handle Squirrel-cage blower Arena Hazer User Manual Fluid tank access Fluid level indicator 2007-05-29/16:06... -
Page 7: Product Overview Continued
Product Overview Continued Remote input Address Power Switch IEC Power Connector DMX In Dipswitches Hazer Power Cable IEC Power Connecto r Arena Hazer User Manual Rear of hazer Inside flight case Power Switch and Fan Speed Control Knob Fuse 2007-05-29/16:06... -
Page 8: Setup
Maximum recommended number of fixtures on a serial data link: 32 fixtures Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET-certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 9: Cable Connectors
3-PIN TO 5- PIN CON VE R SION CHAR T If you use a controller with a 5 Note! CHAUVET Model No: DMX5M, or DMX5F. The chart below details a proper cable conversion: IN TO ONVERSION Ground/Shield... -
Page 10: Operating Instructions
Use the knob on the inner control , and without a DMX controller. the first X represents the desired fog output, d of the DMX link, or use a DMX splitter (Chauvet e blower to the desired value using the dipswitches. UNCTION... -
Page 11: Setting The Starting Address
Resolving address using simple math. Address 233 Arena Hazer User Manual 233 – (128) = 105, Turn ON Dip # 8 105 – (64) = 41, Turn ON Dip # 7 41 – (32) = 9, Turn ON Dip # 6 9 –... -
Page 12: Dmx Quick Reference Chart
30 62 94 126 158 190 222 254 286 318 350 382 414 446 478 510 1 1 1 1 1 31 63 95 127 159 191 223 255 287 319 351 383 415 447 479 511 Dip Switch Posit Arena Hazer User Manual Dip Switch Position DMX Add ress... -
Page 13: General Troubleshooting
If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on the next page. Arena Hazer User Manual... -
Page 14: Technical Support
Connect fixtures XLR male to female connectors. The pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET pliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX signe d in y mann er. -
Page 15: General Maintenance
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the caus for the return. -
Page 16: Technical Specifications
Data pin configuration ...pin 1 shield, pin 2 (-), pin 3 (+ Protocols... DMX-512 USITT DMX Channels ...2 ORDERING INFORMATION Arena Hazer ...Arena WARRANTY INFORMATION Warranty ... 2-year limited warranty Arena Hazer User Manual locking 3-pin XLR male socket V 50 Hz .20,000 cfm (haze) w Blow Blow or 3...
