Summary of Contents for Chauvet FlexFog 1500
-
Page 1: User Manual
FlexFog™ 1500 Snapshot OK on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle USER MANUAL 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ABLE OF ONTENTS 1. BEFORE YOU BEGIN ... 3 ... 3 HAT IS INCLUDED ... 3 NPACKING NSTRUCTIONS AC P ... 3 OWER ... 3 ONTACT ... 4 AFETY NSTRUCTIONS ... 5 AINTENANCE ... 5 TORAGE 2. INTRODUCTION ... 6 ... -
Page 3: Before You Begin
All fixtures must be connected to circuits with a suitable Earth Ground. Contact Us W o r l d W i d e General Information Technical Support World Wide Web FlexFog™ 1500 EGIN CHAUVET 3000 North 29 Court Hollywood, FL 33020 voice: 954.929.1115 fax: 954.929.5560 toll free: 800.762.1084... -
Page 4: Safety Instructions
Never disconnect the power cord by pulling or tugging on the cord. Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. FlexFog™ 1500 1/10/2008 12:59 PM... -
Page 5: Maintenance
WARNING! Note: All fog machines are prone to clogging due to the thick consistency of fog liquid and the high temperature at which it vaporizes. However, a properly maintained fog machine should provide years of reliable use. Cleaning your fog machine regularly will help reduce costly replacement and repair charges. -
Page 6: Introduction
2. I NTRODUCTION Features • 1-channel DMX-512 flexible fog machine • 1,500-watt heater • Output: 25,000cfm Ad d i t i o n a l F e a t u r e s • Manually adjustable output angles (180º) • Wired timer remote included •... -
Page 7: Product Overview
Product Overview Carrying handle Wired remote DMX connections (on back) Fluid Reservoir Ready indicator Dipswitches DMX input DMX output Remote input FlexFog™ 1500 Hanging bracket Angle adjustment knob Manual fog button On/Off power switch Head adjustment handle Fog output nozzle Led Indicators Included timer remote Remote input... -
Page 8: Setup
Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET-certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 9: Cable Connectors
If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter. Note! Note! CHAUVET Model No: DMX5M, or DMX5F. CHAUVET Model No: DMX5M, or DMX5F. The chart below details a proper cable conversion:... -
Page 10: Master/Slave Fixture Linking
Master/Slave Fixture Linking 1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of the first fixture. 2. Connect the end of the cable coming from the first fixture which will have a (female) 3 pin connector to the input connector of the next fixture consisting of a (male) 3 pin connector. -
Page 11: Master/Slave Mode
4. O PERATING Master/Slave Mode: This mode will allow you to link up to 32 units together without a controller. Use standard DMX cables to daisy chain your units together via the DMX connector on the rear of the units. For longer cable runs we suggest a terminator at the last fixture. For more information about terminators, see page 9. -
Page 12: Setting The Starting Address
SETTING TH E STARTIN G ADDR ESS This DMX mode enables the use of a universal DMX controller device. Each fixture requires a "start address" from 1 to 512. A fixture requiring one or more channels for control begins to read the data on the channel indicated by the start address. -
Page 13: Dmx Quick Reference Chart
D MX QU ICK R EFER ENC E CHART DMX Address Quick Reference Chart DMX DIP #9 0 0 0 SWITCH SET 0=OFF #8 0 0 0 1=ON #7 0 0 1 X=OFF or ON #6 0 1 0 #1 #2 #3 #4 #5 0 0 0 0 0 32 64 96 128 160 192 224 256 288 320 352 384 416 448 480 1 0 0 0 0... -
Page 14: General Troubleshooting
If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on the next page. FlexFog™ 1500... -
Page 15: Technical Support
XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) FlexFog™... -
Page 16: General Maintenance
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 17: Technical Specifications
Technical Specifications WEIGHT & DIMENSIONS Length... 21 in (533 mm) Width ... 9.5 in (241 mm) Height ...9 in (229 mm) Weight ...28.8 lbs (13.1 kg) POWER Input Voltage ...120V 60Hz AC or 230V 50Hz Fuse... 15A 250V Power and Current ... 1543W (13.1A) max at 120V Inrush Current...
