- Page 1 Instructions for use Fridge freezer Gorenje for iPod...
- Page 2 “Made for iPod” means that an electronic accessory has been designed to connect specifi cally to iPod and has been certifi ed by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.
-
Page 3: Table Of Contents
Thank you for your confi dence in buying our appliance and congratulations on the excellent choice. We hope it will successfully serve its purpose for many years. Fridge freezer Gorenje for iPod (hereinafter: the appliance) is combined from two parts: top part is refrigerator and bottom part is upright freezer. -
Page 4: Before Fi Rst Operation
Before fi rst operation • The appliance is manufactured in compliance with all relevant safety standards; however, it is recommended that persons with impaired physical, motional, or mental abilities, or persons with inadequate experience and knowledge, do not use the appliance without due supervision. The same recommendation applies to minors using the appliance. - Page 5 The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of thisproduct.
-
Page 6: Description Of The Appliance
Description of the appliance A Refrigerator 1 Control panel 2 Interior illumination light 3 Fan 4 Bottle rack 5 Shelf (adjustable height) 6 Foldable egg tray (closed 6, open 12 eggs) 7 COOL´N´FRESH pan 8 Crisp tray 9 Refrigerator door tray (max. 6 kg) 10 Deep shelf removable tray with lid READY’N’SERVE... -
Page 7: Installation And Connection
Installation and connection Selecting the location Selecting the location • Place the appliance in dry and well aired room. The appliance operates best at temperature ranges indicated in the chart below. Relevant class of the appliance is indicated on the rating plate. - Page 8 Connecting to power Connecting to power • Use the power cord to connect the appliance to the mains supply supply power. Wall outlet must be fi tted with ground terminal (safety socket). Nominal voltage and frequency are indicated on the relevant label or rating plate of the appliance.
-
Page 9: Changing The Door Opening Direction
Changing the door opening direction Required tools: socket spanner nr. 8, screwdriver, torx 25. Caution! After unscrewing of before fi xing hinges, hold the door to prevent it from falling and damaging. 1. Remove upper hinge cover (save it for eventual later use), remove also the cover on the opposite side of the upper hinge cover (on the opposite side you will insert the attached cover during the assembly), and remove the cover on the opposite... -
Page 10: Control Panel
Control panel A Temperature selector and ON/OFF button B Green LED: illuminated when the appliance is in operation C Freezer alarm off button D Red LED: fl ashing with freezer alarm E Fast freeze button F Orange LED: on during fast freezing procedure The ON/OFF button The ON/OFF button The appliance is switched on by turning the button A towards... - Page 11 Rapid freeze function Rapid freeze function • Use this setting after switching on the appliance for the fi rst time, and when inserting large quantities of unfrozen food (see “Freezing procedure”). - press the E key (orange LED F will light up). The setting is automatically deactivated after approximately two days.
-
Page 12: Installation And Use Of The Device (Ipod Touch)
Installation and use of the device (iPod touch) Purpose of use Purpose of use The docking station on the appliance door enables connecting an iPod touch device, allowing charging the device and audio playback. Mounting the device Mounting the device •... -
Page 13: Recommended Distribution Of Food
Playback volume setting Playback volume setting Use the keys installed immediately below the device to set the playback volume: - press the right (B) key to increase the volume; - press the left (A) key to decrease the volume; - To turn off the amplifi er, press the (A) and (B) buttons simultaneously and hold them for at least two seconds. -
Page 14: Storing Fresh Food
Freezer parts: door area: packed vegetables, ice cream, ice, etc. other areas: freezing, storing frozen food (see “Freezing and storing frozen food”). Storing fresh food Important precautions Important precautions Proper use of the appliance, adequately packed food, for storing fresh food for storing fresh food correct temperature and hygienic precautions have substantial impact on the quality of stored food. - Page 15 Unpleasant odour inside the refrigerator is a sign that something is wrong with food or that your refrigerator needs cleaning (see chapter on Cleaning). If you are away for a lengthy time, please remove all perishables beforehand. Interior accessories and Interior accessories and Equipment depends on the model space distribution...
-
Page 16: Storage Of Food In The Cool´n´fresh
Storage time of fresh Storage time of fresh Approximate storage time of fresh foods foods foods Food Period eggs, marinades, smoked meat up to 10 days cheese up to 10 days carrots, etc. up to 8 days butter up to 7 days cake, fruit, TV-dinner dishes, raw up to 2 days chunks of meat... -
Page 17: Freezing And Storage Of Frozen Food
Freezing and storage of frozen food Freezing procedure Freezing procedure • 24 hours before freezing fresh food, activate the rapid freezing function (freeze boost): - press the E key. After this period place fresh food in the freezing compartment. Do not let the already frozen packages touch the fresh ones. •... - Page 18 Take care that packages don’t start to thaw during transport to your home. Temperature rise shortens the storage time and affects the quality of commercially frozen foods. Approximate storage Approximate storage Food Storage Period time of frozen foods time of frozen foods Fruit, beef from 10 to12 months Vegetables, veal, poultry...
-
Page 19: Defrosting The Appliance
Defrosting the appliance Automatic defrosting of Automatic defrosting of The appliance needs no special defrosting procedure, because the refrigerator the refrigerator ice deposited at the inner back wall is defrosted automatically. Ice deposited on the inner back wall during the compressor operation is defrosted when the compressor stops operating, and condensed water drops are drained through the outlet in the inner back wall into the drain pan situated above the compressor... -
Page 20: Cleaning
Cleaning Prior to any cleaning. Please disconnect the appliance from the mains (turn the thermostat button to the position and pull the power cord from the mains outlet). A special antibacterial protection in the upper layer of interior walls prevents multiplication of bacteria, thus contributing to better appliance hygiene. -
Page 21: Troubleshooting Guide
Troubleshooting guide Fault: Cause/Remedy The appliance does not operate • Check if there is power in the socket and if the appliance is after connection to the mains: switched on. Cooling system operates • Ambient temperature too high. continuously without intermittent •... - Page 22 Fault: Cause/Remedy Bulb replacement: • Before replacing the light bulb, disconnect the appliance form the power supply. Using the screwdriver remove the cover, replace the bulb with a new one (E 14, max. same voltage as the factory one and fi t back the cover. •...
-
Page 23: Noise Level
Noise level Cooling of refrigerator-freezer appliances is provided by compressor cooling system (for certain appliances also the fan). Operation of this system results in certain noise, the intensity of which depends upon the installation, correct use, and age of the appliance. - Page 24 COMBI CLA,PRE iP 273214/en (11-09)
