REPAIR PARTS

Rail Assembly Parts

1

Installation Parts

1
5
8
13
12
4
6
4
2
3
6
10
11
9
2
3
KEY
NO.
1
2
3
4
5
6
KEY PART
NO. NO.
1 41C494-2
2 953D
3 10A20
7
4 29B137
5 41A2828
6 41B4494-1
7 41A5047-1
8 41A5047-2
9 41A5034
10 178B34
11 12B776
12 178B35
13 41A5266-1
41A5258-11
114A3108
114A3108SP Owner's manual - Spanish
37
5
PART
NO. DESCRIPTION
4A1008 Master link kit
41C5141-1 Complete trolley assembly
41A5665 Complete rail
144C56 Idler pulley
41A5807 Chain and cable
12D598-1 "U" bracket
NOT SHOWN
183A163 Wear pads
DESCRIPTION
Multi-Function door control panel
3-Button remote control
3V2032 Lithium battery
Remote control visor clip
Emergency release rope and handle
assembly
2-Conductor bell wire, white and
white/red
Door bracket w/clevis pin & fastener
Header bracket w/clevis pin & fastener
Safety sensor kit (receiving and sending
eyes) with 3' (.9 m) 2-conductor bell
wire
Straight door arm section
Hanging bracket
Curved door arm section
Safety sensor brackets (2)
NOT SHOWN
Installation hardware bag
(includes hardware listed on page 7)
Owner's manual
