Product Specifications - Lumencor SPECTRA Light Engine Instruction Manual

7. Product Specifications
The SPECTRA must be operated and stored within the environmental conditions specified.
Specification
Temperature
Operating
Non-operating
Humidity
Operating and non-operating
Altitude
Operating
Non-operating
Dimensions (LxWxH)
Weight
Lifetime
Input Power Requirements
Warm-up Period
Protection
Sound Level
Connectivity
Warranty
SPECTRA, SPECTRA S and SPECTRA X Instruction Manual
Detail
32 to 95° F (0 to 35° C)
-4 to 158° F (-20 to 70° C)
0 to 80% relative humidity, non-condensing
0 to 10,000 feet (3,048 meters)
0 to 20,000 feet (6,096 meters)
11.0 x 7.0 x 4.0 in / 27.9 x 17.8 x 10.2 cm
9 lb / 4.1 kg
> 10,000 hr
24VDC / 5A (SPECTRA X-YYY- Z), 28-30VDC / 7.9A (SPECTRA X-YYY-SZ or
SPECTRAX X-YYY-SZ)
Less than 1 minute
IP Rating of X0
Sound Level at 1 meter < 65db(A)
RS-232, USB, TTL
36 months parts and labor
11
