- Page 1 CAM200 DIAPHRAGM DISPENSE VALVE Version: B12-2112 Rev: C Operation Manual 1 MUSTANG DRIVE COHOES, NY 12047 PHONE: 518-371-2684 FAX: 518-371-2688 info@pva.net www.pva.net...
-
Page 2: Theory Of Operation
Applications can include dispensing dots, beads, or for potting. The CAM200 has one body to house the fluid and piston & lever section. These include: 1) Piston & Lever section (Aluminum top cap with spring loaded lever) 2) Fluid section (Delrin body with Teflon diaphragm) The piston &... - Page 3 Refer to MSDS sheets on material being dispensed for other precautions. Setup The CAM200 does not require an air source for operation but relies only on the operator to depress a lever to actuate the valve. Constant material pressure is applied to the diaphragm of the valve which is held in place with the spring loaded piston.
- Page 4 3) Relieve fluid pressure on the valve by turning off air pressure from the fluid reservoir. Starting Up Valve At the beginning of the day or a shift it is necessary properly set up the CAM200 to resume normal operation. 1) Remove the luer lock plug from the luer lock adapter (9) and discard.
-
Page 5: Operation
Operation Refer to assembly drawing 112-2928 for part reference numbers. 1) Plumb up the valve as outlined above in the Setup procedures. 2) Being sure the valve is not aimed toward anyone, pressurize the fluid delivery system. Note: The fluid pressure must be set to a minimum of 15psi. to flex the diaphragm to the open position. -
Page 6: Spare Parts
Note: Be sure not to over tighten the luer adapter (4). Spare Parts PVA offers standard spare parts kits for all dispensing valves. These kits are stocked for immediate shipment and allow replacement of all wearable parts of the valve. -
Page 8: Troubleshooting
BILL OF MATERIALS FOR CAM200 (B12-2112): Refer to Drawing #: 112-2928 Item Part Number Description Quantity V351 Valve Top Cap V323 Diaphragm V333-NPT Fluid Section 214-14855 Plunger, stainless steel V348 Stroke Adjust Nut V352 Standoff 614-5898-1 Handle V059 Spring V300-UV... - Page 9 Unauthorized repair or modification of the enclosed product, and/or the use of spare parts not directly obtained from PVA (or from factory authorized dealers) will void all warranties.
