- Page 1 WHERE PRECISION DRIVES PRODUCTION MV600 Series Metering Valve Version: 112-10423 OWNER’S MANUAL Rev A Precision Valve & Automation One Mustang Drive Cohoes, NY 12047 www.pva.net ...
- Page 2 MV600 Series Metering Valve PVA This document is based on information available at the time of its publication. While efforts have been made to ensure the contents of this manual are accurate, the information contained herein does not purport to cover all specific details or variations in hardware, or to provide for every possible contingency in connection with installation, operation, or maintenance. Features may be described herein which are not present in all hardware and software systems. Precision Valve and Automation, Inc. assumes no ...
-
Page 3: Table Of Contents
MV600 Series Metering Valve PVA Table of Contents Introduction .................... 4 PVA Contact Information .................. 4 Document History .................... 4 Safety ........................ 5 Personal Protective Equipment ................ 6 Waste Disposal .................... 6 Technical Specifications................ 6 Theory of Operation ................... 7 Setup ...................... 7 Pneumatic Schematic .................. 8 Operation .................... 10 ... -
Page 4: Introduction
MV600 Series Metering Valve PVA Troubleshooting .................. 32 Warranty .................... 33 Table of Figures .................. 34 Introduction Before you operate this system, read the operation and setup manual. This will help you to become familiar with the product and ensure successful operation. If any questions or problems arise, contact PVA’s Technical Support department. PVA Contact Information Main Office PVA One Mustang Drive Cohoes, NY 12047 Tel +1‐518‐371‐2684 ... -
Page 5: Safety
MV600 Series Metering Valve PVA Safety Certain warning symbols are affixed to the machine and correspond to notations in this manual. Before operating the system, identify these warning labels and read the notices described below. Not all labels may be used on any specific system. Always wear approved safety glasses when you operate or work with spray or dispense valves. Before you operate the system, read and understand the manuals provided with the unit. Never put hands or tools in areas with this symbol when the machine is in operation. A dangerous condition may exist. Read and understand the manuals provided with the unit before any repairs or maintenance is done. Only a qualified individual should do service. Use caution when there are pressurized vessels. Find and repair any leaks immediately. Always wear appropriate safety equipment when you work with pressurized vessels or vessels that contain chemicals. Shear hazard from moving parts. Avoid contact. Revision A (2018) 5 of 35 ... -
Page 6: Personal Protective Equipment
MV600 Series Metering Valve PVA Personal Protective Equipment Operators must use eye protection because material contents are under pressure. Always wear gloves when handling materials and solvents. Refer to MSDS sheets on the material being dispensed for other precautions and recommended solvents. Waste Disposal Dispose of all used parts and materials in accordance with local laws and regulations. Technical Specifications Table 1: MV600 Series Technical Specifications Weight 4.6 lbs. (2.08 kg.) Overall Dimensions 10.90”(277mm) x 1.50”(38mm) x 3.20”(81mm) Wetted Components Stainless Steel, Kalrez®, Teflon® Polyurethane Fluid inlet 1/4" MNPT Fluid Outlet Male luer lock adapter Fluid volume range 0.10cc – 0.80cc per cycle Recommended viscosity range 10,000cps – 5,000,000 cps Inlet fluid pressure 30psi – 3,200psi Outlet fluid pressure 4,000psi. Maximum generated on outlet Operating air pressure 80psi. (Can be operated between 50psi – 100psi) Operating air ports 10‐32 female threaded ports (supplied air fittings for 5/32”od tube) Operating equipment 2‐Position 4‐Way air solenoid valve Optional equipment 24vdc Reed switch (Quantity 2) Mounting dimensions Refer to drawing 112‐10423 ... -
Page 7: Theory Of Operation
MV600 Series Metering Valve PVA Theory of Operation The MV600 is a rod displacement style, positive displacement metering head with two integral check valves to control the flow of material into and out of the valve. A spring loaded check valve mounted to the metering cylinder act’s as the inlet check valve and the SB300 series rear closing dispense valve acts as the outlet check valve. The metering chamber houses a rod and cylinder combination to meter a specific amount of material to be dispensed. A micrometer in the upper air section is adjusted to set the travel distance of the rod thus setting the chamber volume that will displace a specific fluid volume during each cycle. During fill, the SB300 dispense valve will stay closed as fluid pressure is used to push the piston upward until it reaches the micrometer “hard stop”. An air port on the metering chamber is available for refill assist to pull fluid into the metering section faster. Once filled, air pressure is simultaneously applied to the SB300 to cycle it open and the air section of the metering chamber to drive the rod down and force fluid out of the valve. A second air port is located on the metering chamber to double the pressure used to drive the rod down to dispense. A stroke adjustment in the air section of the SB300 can be used to control the amount of suck back to prevent dripping and stringing with thicker fluids. Setup The MV600 requires a 2‐position, 4‐way air solenoid valve to actuate the air section. The valve should be operated with clean, dry air between 50‐100psi. Two #10‐32 threaded air ports are located on the air section of the SB300 valve and three #10‐32 ports are located on air section of the metering chamber. The port located on the side of the SB300 is air to close the valve. The port located on the top of the stroke adjustment is air to open the valve. The air supply connected to the stroke adjustment of the SB300 should be tied to the highest and lowest port on the air section of the metering chamber. The middle port of the metering chamber can be tied to the port on the side of the SB300 to provide refill assist. Quick connect air fittings are typically supplied with the MV600 to fit 5/32” tubing. Note that the valve should be normally in the closed position. Flow control air fittings can be used to control the speed of refill and dispense of fluid. Fluid is supplied to the MV600 through the 1/4”mnpt inlet check valve located on the inlet of the metering cylinder. Revision A (2018) 7 of 35... -
Page 8: Pneumatic Schematic
MV600 Series Metering Valve PVA Pneumatic Schematic There are three different options when connecting pneumatic to the MV600 series valve. The SB300 series outlet valve must always be connected to the solenoid but the metering cylinder contains to ports which can be used to drive fluid to dispense and one port which can be used to assist refilling fluid in the metering cylinder. Option 1: Used for highest viscosity fluids. Both dispense ports are connected providing a 40:1 ratio mechanical advantage for dispense pressure. Refill assist port is connected to pull fluid into the metering chamber faster. Table 2: Pneumatic Schematic – Dual Air Dispense & Refill Assist Revision A (2018) 8 of 35 ... - Page 9 MV600 Series Metering Valve PVA Option 2: Used for medium viscosity fluids. One dispense port is connected providing a 20:1 ratio mechanical advantage for dispense pressure. Refill assist port is connected to pull fluid into the metering chamber faster. Table 3: Pneumatic Schematic – Single Air Dispense & Refill Assist Option 3: Used for lower viscosity fluids. One dispense port is connected providing a 20:1 ratio mechanical advantage for dispense pressure. No refill assist is used. Table 4: Pneumatic Schematic – Single Air Dispense & No Refill Assist Revision A (2018) 9 of 35 ...
-
Page 10: Operation
MV600 Series Metering Valve PVA Operation NOTE: Refer to Table 2, 3, or 4 (Section 4.1) NOTE: Use only compatible solvents and materials or the seals and O-rings will be damaged. Connect Pneumatics 1. Connect air lines from solenoid to valve as shown in Table 2, 3, or 4 depending on the type of configuration that fits the application. 2. Supply air pressure to solenoid valve and regulate between 50‐100 psi. (Note: 80psi. optimal air pressure setting) 3. Turn the micrometer of the metering piston counter‐clockwise until the #3 can ... -
Page 11: Valve Settings
MV600 Series Metering Valve PVA Valve Settings 1. Fluid pressure to valve inlet will determine piston refill time. Increasing fluid pressure will allow the metering chamber to fill at a faster rate. 2. Connecting the solenoid to the refill assist port as shown in table 2 or 3 to pull fluid in faster and decrease fill time. 3. Connect the solenoid to both air dispense ports as shown in table 2 in order to build the maximum amount of pressure to dispense fluid and decrease dispense time. 4. Turning the micrometer counter‐clockwise will increase the volume and turning it counter‐clockwise will decrease the fluid volume. Note: After each adjustment, cycle the valve one to dispense and check new volume. Note: Valve should be cycled to the open position when adjusting the micrometer so the piston is not being forced against the micrometer. -
Page 12: Periodic Maintenance
MV600 Series Metering Valve PVA Periodic Maintenance Interval Action Examine the material outlet for contamination and cured Daily material. Clean cured material if necessary. Examine any packing seals for leaking. Examine fluid reservoirs or pumps for signs of cured or dried Weekly material. Necessary Tool Kit PVA offers a standard kit of all tools necessary to maintain valve. Tool Kit part number: B12‐04287 Quantity Part Number Description 2 0266244 8” Adjustable Wrench 1 26569 9/64” Allen Key 1 26571 5/32” Allen Key 2 26563 3/32” Allen Key 1 26559 1/16” Allen Key ... -
Page 13: Spare Parts Kit
MV600 Series Metering Valve PVA Spare Parts Kit PVA offers a standard kit of all wearable items to rebuild the valve. Spare parts kit, part number: 112‐10423‐SP Quantity Part Number Description 1 Lip Seal, Molythane 01525 1 Lip Seal, Molythane 12500187 1 Lip Seal, Molythane 12500250‐250B 1 98410A117 Snap Ring, 0.338”id 1 VLV‐014B O‐Ring, Buna 1 VLV‐008B O‐Ring, Buna 1 VLV‐024B O‐Ring, Buna 1 VLV‐214B O‐Ring, Buna 2 VLV‐016V O‐Ring, Viton 1 VLV‐014V O‐Ring, Viton ... -
Page 14: Routine Cleaning And Disassembly
MV600 Series Metering Valve PVA Routine Cleaning and Disassembly Prior to disassembly, turn off fluid & air pressure to the valve and remove all fluid feed and air lines from the valve. Discard any damaged or worn components and replace from the spare parts kit as necessary. Disassemble Sections For part reference, refer to drawing: 112‐10423 1. Using a 9/64” Allen Key, remove two machine screws (3) and separate the SB300 (2) from the metering cylinder (1). Figure 1: Remove Screws & Separate Sections 2. Using an adjustable wrench, unthread and remove the inlet check valve (4). Figure 2: Remove Check Valve Revision A (2018) 14 of 35 ... -
Page 15: Disassemble Metering Cylinder
MV600 Series Metering Valve PVA 3. Using two adjustable wrenches’, separate the check valve (4) and remove the spring loaded piston assembly. Figure 3: Separate Check Valve Disassemble Metering Cylinder For part reference, refer to drawing: 112‐08449 1. Using a 5/32” Allen Key, remove the four machine screws (17) and separate the upper air body (2) from the cylinder stop (4). Figure 4: Remove Screws & Separate Sections 2. Using a 1/16” Allen Key, loosen the set screw (9) that secures the micrometer (11) in place. Figure 5: Loosen Set Screw Revision A (2018) 15 of 35 ... -
Page 16: Figure 6: Remove Micrometer
MV600 Series Metering Valve PVA 3. Using pliers with soft grip covers unthread and remove the micrometer (11) from the upper air body (2) and remove the O‐Ring (18). Figure 6: Remove Micrometer 4. Pull the piston assembly (1, 3, 4) out of the lower air body (5). Figure 7: Remove Piston 5. Using pliers with soft grip covers hold the upper piston assembly (3) and turn the metering piston (1) by hand separate the assembly from the cylinder stop (4). Figure 8: Separate Piston Assembly 6. Using a pick, remove the O‐ring (19) from the cylinder stop (4) then remove O‐rings (21) from the outside of the cylinder stop and O‐rings (23) from the pistons (1,3). Figure 9: Remove O‐Rings Revision A (2018) 16 of 35 ... -
Page 17: Figure 10: Remove Screws
MV600 Series Metering Valve PVA 7. Using a 5/32” Allek key, remove the four machine screws (16) that connect the fluid body (6) to the metering cylinder (7) lower air body (5). Figure 10: Remove Screws 8. Separate the sections and remove O‐ring (20) from the metering cylinder (7) and O‐ Ring (22) from the fluid body (6). Figure 11: Separate Section & Remove O‐Rings 9. Using the special tool, loosen and remove the seal stop (8). Figure 12: Remove Seal Stop 10. Using a pick, remove the lip seal (10) from the metering cylinder (7). Figure 13: Remove Lip Seal Revision A (2018) 17 of 35 ... -
Page 18: Disassemble Sb300 Section
MV600 Series Metering Valve PVA Disassemble SB300 Section For part reference, refer to drawing: 112‐10424 1. Using an adjustable wrench unthread and remove the luer adapter (25). Figure 14: Remove Luer Adapter 2. Using a 9/64” Allen Key, remove the four machine screws (23) located on the end cap (22). Figure 15: Loosen Screws 3. Pull the end cap (22) away from the valve and remove the O‐Ring (24). Figure 16: Separate Sections Revision A (2018) 18 of 35 ... -
Page 19: Figure 17: Separate Sections
MV600 Series Metering Valve PVA 4. Pull the seal plate (6) away from the valve and remove the O‐Ring (21), lip seal (14), and washer (16). Figure 17: Separate Sections 5. Using a 9/64” Allen Key, remove the four machine screws (9) on the air cap (3). Figure 18: Loosen Screws 6. Pull the air cap (3) away from the air cylinder (2). Figure 19: Separate Sections 7. Using snap ring pliers remove the snap ring (13) from the stroke adjust (7). Figure 20: Remove Snap Ring Revision A (2018) 19 of 35 ... -
Page 20: Figure 21: Separate Stroke Adjust
MV600 Series Metering Valve PVA 8. Unthread and remove the stroke adjust (7) from the air cap (3) and remove two O‐Rings (17, 19). Figure 21: Separate Stroke Adjust 9. Pull the air cylinder (2) away from the separation body (1), completely removing the needle (10). Figure 22: Separate Sections 10. Push the needle & piston assembly (4, 10) out of the air cylinder (2) then remove the spring (11) and O‐ring (18). Figure 23: Separate Piston Assembly 11. To separate the needle (10) and piston (4), use an adjustable wrench and 3/32” Allen key to remove the machine screw (12). Remove O‐ring (20). Figure 24: Separate Piston & Needle Revision A (2018) 20 of 35 ... -
Page 21: Assembly Instructions
MV600 Series Metering Valve PVA 12. Using a 3/32” Allen Key, remove four machine screws (8) that secure the separation body (1) to the fluid body (5). Figure 25: Loosen Screws 13. Pull the separation body (1) away from the fluid body (5). Use a pick to remove the lip seal (15) and remove the O‐ring (21) and washer (16). Figure 26: Separate Sections Assembly Instructions For Assembly of valve, lubricate all O-rings with the lubricant provided in the tool kit, or comparable lubricant. Use removable thread locker supplied in the tool kit, or comparable thread locker on the male thread of the upper piston (3) for assembly to the metering piston (1). -
Page 22: Figure 28: Assemble Seal Stop
MV600 Series Metering Valve PVA 2. Thread the seal stop (8) into the metering cylinder (7) and tighten using the special tool. Figure 28: Assemble Seal Stop 3. Mount O‐ring (22) onto fluid body (6). Figure 29: Mount O‐Ring 4. Mount the fluid body (6) and lower air body (5) to each side of the metering cylinder (7) and assemble using four machine screws (16). Use a 5/32” Allen key to tighten. Note: Be sure fluid inlet and air port are located on same face. Figure 30: Assemble Sections 5. Mount one O‐ring (19) onto the inside grove of the cylinder stop (4) and two O‐ rings (21) onto the outside grooves of the cylinder stop. Figure 31: Assemble O‐Rings Revision A (2018) 22 of 35 ... -
Page 23: Figure 32: Assemble O-Rings
MV600 Series Metering Valve PVA 6. Mount one O‐ring (23) onto the upper Piston (3) and a second O‐ring (23) onto the Metering Piston (1). Figure 32: Assemble O‐Rings 7. Slide the upper piston (3) through the cylinder stop (4). Figure 33: Assemble Piston 8. Apply a small amount of removable thread locker to the male threads of the upper piston (3) and assemble it to the metering piston (1). Use soft grip pliers to hold the upper piston and tighten the metering piston by hand. Figure 34: Assemble Piston 9. Push the piston assembly into the lower section until the cylinder stop (4) sits flush against the lower air body (5). Figure 35: Assemble Sections Revision A (2018) 23 of 35 ... -
Page 24: Figure 36: Assemble Micrometer
MV600 Series Metering Valve PVA 10. Place O‐ring (18) onto the shaft of the micrometer (11) then thread the micrometer into the upper air body (2). Tightening with soft grip pliers. Figure 36: Assemble Micrometer 11. Using a 1/16” Allen key, tighten set screw (9) against the micrometer (11). Figure 37: Tighten Set Screw 12. Mount the upper air body assembly (2) onto the lower section and assemble with four machine screws (17), using a 5/32” Allen key to tighten. Figure 38: Assemble Micrometer 13. Place O‐ring (20) onto the outlet of the metering cylinder groove(7). Figure 39: Assemble O‐Ring Revision A (2018) 24 of 35 ... -
Page 25: Assemble Sb300 Section
MV600 Series Metering Valve PVA Assemble SB300 Section For part reference, refer to drawing: 112‐10424 1. Insert lip seal (15) into separation body (1). Figure 40: Assemble Lip Seal 2. Place a washer (16) on the inside groove of the fluid body (5) then place O‐ring (21) on the outer groove. Figure 41: Assemble O‐Ring & Washer 3. Assemble the separation body (1) onto the fluid body (5) and secure using four machine screws (8). Use a 3/32” Allen key to tighten. Figure 42: Assemble Sections Revision A (2018) 25 of 35 ... -
Page 26: Figure 43: Assemble Piston
MV600 Series Metering Valve PVA 4. Mount an O‐ring (20) onto the piston (4) and assemble the needle (10) to the piston with machine screw (12). Use an adjustable wrench and 3/32” Allen key to tighten. Figure 43: Assemble Piston 5. Insert the spring (11) into the air cylinder (2). Figure 44: Assemble Spring 6. Insert the piston assembly (4, 10) into the air cylinder (2) then place the O‐ring (18) onto the needle (10) and slide it up to the groove of the air cylinder. Figure 45: Assemble Sections 7. Assemble the piston & air cylinder to the lower section of the valve. Figure 46: Assemble Sections Revision A (2018) 26 of 35 ... -
Page 27: Figure 47: Assemble O-Rings
MV600 Series Metering Valve PVA 8. Mount O‐ring (17) onto stroke adjust (7) and mount O‐ring (19) onto air cap (3). Figure 47: Assemble O‐Rings 9. Thread the stroke adjust (7) into the air cap (3) then mount a snap ring (13) onto the stroke adjust using the snap ring pliers. Figure 48: Assemble Stroke Adjust 10. Place the air cap (3) assembly onto the air cylinder (2) then assemble using four machine screws (9), tightening with a 9/64” Allen key. Figure 49: Tighten Screws 11. Place the lip seal (14) into the seal plate (6) with O‐ring facing out. Figure 50: Assemble Lip Seal Revision A (2018) 27 of 35 ... -
Page 28: Figure 51: Assemble Washer & O-Ring
MV600 Series Metering Valve PVA 12. Place the washer (16) into the inside groove of the fluid body (5) then place the O‐ring (21) into the outer groove of the fluid body. Figure 51: Assemble Washer & O‐Ring 13. Press the seal plate (6) onto the fluid body (5). Figure 52: Assemble Seal Plate 14. Place an O‐ring (24) into the groove of the end cap (22). Figure 53: Assemble O‐Ring 15. Mount the end cap (22) onto the seal plate (6) and assemble using four machine screws (23). Use a 9/64” Allen key to tighten. Figure 54: Tighten Screws Revision A (2018) 28 of 35 ... -
Page 29: Assemble Sections
MV600 Series Metering Valve PVA 16. Add Teflon tape to the male threads of the luer adapter (25) then thread the luer adapter onto the end cap (22) using an adjustable wrench to tighten. Figure 55: Assemble Luer Adapter Assemble Sections For part reference, refer to drawing: 112‐10423 1. Add Teflon tape to the male threads of the inlet check valve (4) and thread it into the metering cylinder (1) using an adjustable wrench to tighten. Figure 56: Tighten Check Valve 2. Mount the SB300 section (2) onto the metering cylinder section (1) and assemble with two machine screws (3) tightening with a 9/64” Allen key. Figure 57: Assemble Sections Revision A (2018) 29 of 35 ... -
Page 30: Zero Out Micrometer
MV600 Series Metering Valve PVA Zero out Micrometer Once the valve is assembled it will be necessary to zero out the micrometer. 1. Using the micrometer wrench (A), insert the inside tip of the small end into the orifice of the midsection (D) and rotate it clockwise until the numbered centerline is on a side that can most easily be viewed by the operator. 2. Turn the dial (C) clockwise until the end (F) bottoms out on the valve piston. 3. Using soft tip pliers, hold the knurled end of the dial (C) tightly and loosen the screw (B) using a flat head screw driver. Note: Loosen the screw 3‐4 turns only. It is not necessary to fully remove the screw. 4. Using a soft dead blow hammer, tap the dial (C) of the micrometer adjust to unlock it from the mid section (D). The dial will now spin freely. 5. Rotate the dial (C) to align the zero mark of the dial with the numbered centerline of the midsection (D), press down firmly to secure the dial in place. 6. Hold the dial (C) securely in one hand maintaining alignment with the zero mark and numbered centerline, then carefully tighten the screw (B) using the flat head screw driver to lock the micrometer adjustment. Table 5: Micrometer ... -
Page 31: Optional Accessories
MV600 Series Metering Valve PVA Optional Accessories Options are available with the MV600-0.8 series valve to improve a process. Reed Switch Reed switches can be added to the air portion of the metering cylinder to detect the location of the piston in the up and down position as it reds a magnet on the air piston. The 24vdc reed switch can be adjusted up/down and tightened in place with a small screwdriver. When the reed switch is set to the level of the magnet/piston the LED indicator will turn red. Part Number: D‐A93 Figure 58: Reed Switch Revision A (2018) 31 of 35... - Page 32 MV600 Series Metering Valve PVA Troubleshooting Troubleshooting Possible Cause Corrective Action Problem Air pressure to air section is too Increase air pressure to 60‐100 psi Valve does not cycle low Disassemble and clean the valve Material is cured in the valve Disassemble the valve, lubricate O‐rings were not lubricated the O‐rings and seals, and when valve was assembled assemble the valve again The fluid pressure is too low Increase the fluid pressure Valve does not dispense material Material is cured in the fluid Disassemble and clean the valve section ...
- Page 33 MV600 Series Metering Valve PVA Warranty PVA Warranty Policy PVA warrants the enclosed product against defects in material or workmanship on all components for one year from the date of shipment. The warranty does not extend to components damaged due to misuse, negligence, or installation and operation that are not in accordance with the recommended factory instructions. Unauthorized repair or modification of the enclosed product, and/or the use of spare parts not directly obtained from PVA (or from factory authorized dealers) will void all warranties. All PVA warranties extend only to the original purchaser. Third party warranty claims will not be honored at any time. Prior to returning a product for a warranty claim, a return authorization must be obtained from PVA’s Technical Support department. Authorization will be issued either via the telephone, facsimile, or in writing upon your request. To qualify as a valid warranty claim, the defective product must be returned to the factory during the warranty period. Upon return, PVA will repair (or replace) all components found to be defective in material or workmanship. (Retain this for your records) Product Information: PRODUCT: ______________________________ SERIAL NUMBER: ______________________________ DATE OF PURCHASE: ______________________________ Revision A (2018) 33 of 35...
- Page 34 MV600 Series Metering Valve PVA Table of Figures Figure 1: Remove Screws & Separate Sections .............. 1 4 Figure 2: Remove Check Valve .................. 1 4 Figure 3: Separate Check Valve .................. 1 5 Figure 4: Remove Screws & Separate Sections .............. 1 5 Figure 5: Loosen Set Screw .................... 1 5 Figure 6: Remove Micrometer .................. 1 6 Figure 7: Remove Piston .................... 1 6 Figure 8: Separate Piston Assembly .................. 1 6 ...
- Page 35 MV600 Series Metering Valve PVA Figure 40: Assemble Lip Seal ..................... 2 5 Figure 41: Assemble O‐Ring & Washer ................ 2 5 Figure 42: Assemble Sections ................... 2 5 Figure 43: Assemble Piston .................... 2 6 Figure 44: Assemble Spring .................... 2 6 Figure 45: Assemble Sections ................... 2 6 Figure 46: Assemble Sections ................... 2 6 Figure 47: Assemble O‐Rings .................... 2 7 Figure 48: Assemble Stroke Adjust ................... 2 7 ...
